INSTALLATION
Installation is in the reverse order of removal.
| CAUTION | Be careful to tighten starter bolts, "S" terminal nut and "B" terminal nut to the specified torque. Install oil filter. Refer to " REMOVAL AND INSTALLATION ". Clean battery terminals and battery cables to remove corrosion prior to connecting. Ensure the battery cables are tightened to the specified torque. |
Note. Reset electronic systems as necessary.
Scheme 4
Scheme 5
- Disconnect the battery cable from the negative terminal.
- Disconnect "M" terminal of starter motor.
- Test continuity between "S" terminal (A) and switch body. (B): "B" terminal (C): "C" terminal Replace magnetic switch if continuity does not exist.
- Test continuity between "S" terminal (A) and "M" terminal (C). (B): "B" terminal Replace magnetic switch if continuity does not exist.
Scheme 6
- Inspect pinion teeth. Replace pinion if teeth are worn or damaged. (Also check condition of ring gear teeth.)
- Inspect planetary gear teeth. Replace planetary gear if teeth are worn or damaged. (Also check condition of armature shaft gear teeth.)
- Check to see if pinion locks in one direction and rotates smoothly in the opposite direction. Replace pinion assembly if it is locked or rotated in both directions or unusual resistance is evident.
