Accelerator Control System: Removal & Installation Nissan Versa II

Engine Control Systems 1 illustration ~205 words

Removal and Installation

CAUTIONDo not disassemble accelerator pedal assembly. Do not remove accelerator pedal position sensor from accelerator pedal assembly. Avoid impact from dropping etc. during handling. Be careful to keep accelerator pedal assembly away from water.

REMOVAL

  1. Disconnect the battery negative terminal. Refer to " «REMOVAL AND INSTALLATION»(ref-605928-S27864629982014032500000) ".
  2. Disconnect the harness connector from the accelerator pedal position sensor.
  3. Remove the accelerator pedal assembly bolts and the accelerator pedal assembly.

INSTALLATION

Installation is in the reverse order of removal.

Scheme 1

Scheme 1: INSTALLATION
Scheme 1: INSTALLATION
  1. When installing the accelerator pedal assembly, align the locating hook and locating pin holes on the brake pedal bracket. CAUTION: Do not squeeze the locating hook in the break pedal bracket when inserting the locating pin into the hole on the brake pedal bracket side.
  2. After installation, perform inspection of the accelerator pedal assembly.
  3. Check that the accelerator pedal moves smoothly within the specified range. Accelerator pedal travel (A): Refer to " «ACCELERATOR CONTROL»(ref-605957-S35231567262014032500000) ".
  4. Depress and release the accelerator pedal to check that it returns quickly and smoothly to the original released position.
  5. Perform an electrical inspection of accelerator pedal position sensor. Refer to " «COMPONENT INSPECTION»(/nissan/versa/ii-2012-2014/remont/testing-diagnostics/#engine-control-system-diagnostic-codes-symptom-tests) ". CAUTION: Whenever the harness connector of accelerator pedal position sensor is disconnected, perform "ACCELERATOR PEDAL RELEASED POSITION LEARNING". Refer to " «WORK PROCEDURE»(ref-605934-S17108709862014032500000) ". The accelerator pedal should return smoothly without catching to the fully raised position.
