HOW TO READ HARNESS LAYOUT
The following Harness Layouts use a map style grid to help locate connectors on the drawings
- Main Harness
- Engine Room Harness
- Engine Room Harness (Passenger Compartment)
- Engine Control Harness
- Body Harness and Trunk Room Harness
- Room Lamp Harness
To use the grid reference
Scheme 1
- Find the desired connector number on the connector list.
- Find the grid reference.
- On the drawing, find the crossing of the grid reference letter column and number row.
- Find the connector number in the crossing zone.
- Follow the line (if used) to the connector.
Scheme 2
Scheme 3
| B1 | M1 | W/8 | To R1 |
|---|
| C1 | M2 | GR/2 | Diode |
| B3 | M3 | W/1 | Fuse block (J/B) |
| A3 | M4 | W/1 | Fuse block (J/B) |
| D1 | M5 | L/20 | Joint connector-M03 |
| D3 | M6 | W/4 | Dongle unit |
| B2 | M7 | W/16 | Door mirror remote control switch |
| A2 | M8 | W/12 | To D2 |
| A3 | M9 | W/12 | To D1 |
| C2 | M10 | GR/20 | Joint connector-M01 |
| B4 | M11 | W/2 | To B28 |
| F3 | M12 | W/16 | To B29 |
| F3 | M13 | W/24 | To B30 |
| B3 | M14 | BR/6 | Rear window defogger relay |
| B4 | M15 | W/16 | To B23 |
| A4 | M16 | W/24 | To B24 |
| D4 | M17 | B/1 | Parking brake switch |
| A2 | M18 | W/40 | BCM (body control module) (without Intelligent Key system) |
| A2 | M19 | W/15 | BCM (body control module) (without Intelligent Key system) |
| A2 | M20 | B/15 | BCM (body control module) (without Intelligent Key system) |
| C2 | M21 | W/4 | NATS antenna amp. |
| B3 | M22 | W/16 | Data link connector |
| E1 | M23 | W/4 | Remote keyless entry receiver (without Intelligent Key system) |
| C1 | M24 | W/40 | Combination meter (with type B) |
| C2 | M25 | BR/8 | Push-button ignition switch |
| C2 | M26 | W/6 | Ignition switch |
| C2 | M27 | BR/2 | Key switch |
| C3 | M28 | W/16 | Combination switch |
| C3 | M30 | GR/8 | Combination switch |
| C3 | M31 | Y/6 | Combination switch |
| D3 | M33 | B/15 | Front air control |
| B3 | M34 | GR/6 | VDC off switch |
| E4 | M35 | Y/28 | Air bag diagnosis sensor unit |
| D1 | M36 | BR/2 | Front passenger air bag off indicator |
| E4 | M37 | W/8 | A/T shift selector E4 M38 W/8: CVT shift selector |
| B2 | M39 | B/4 | Accessory relay-2 |
| D2 | M40 | W/8 | Audio unit (with mid audio system) |
| C3 | M42 | BR/3 | Thermo control amp. |
| D3 | M43 | W/20 | Audio unit (with base audio system) |
| D2 | M44 | W/16 | Audio unit (with mid audio system) |
| D3 | M45 | W/20 | Audio unit (with mid audio system) |
| E4 | M49 | GR/16 | IPod® connector |
| E5 | M50 | W/24 | IPod® adapter |
| D4 | M51 | O/20 | Joint connector-M02 |
| B3 | M53 | B/8 | EPS control unit |
| B3 | M54 | GR/8 | EPS control unit |
| D2 | M55 | W/4 | Hazard switch |
| B2 | M57 | | Body ground |
| B1 | M61 | | Body ground |
| C1 | M62 | W/2 | Front blower motor |
| B2 | M63 | W/4 | Torque sensor |
| C3 | M64 | W/8 | Steering angle sensor |
| D5 | M66 | B/2 | Console power socket |
| D2 | M68 | GR/10 | AV control unit (with premium audio system) |
| A3 | M69 | SMJ | To E7 |
| E3 | M70 | W/20 | AV control unit |
| D2 | M71 | W/24 | AV control unit |
| E4 | M72 | B/10 | USB interface and AUX jack |
| F2 | M74 | W/4 | To D102 |
| F2 | M75 | Y/4 | To D101 |
| E4 | M76 | B/4 | USB interface and AUX jack |
| E1 | M77 | Y/4 | Front passenger air bag module |
| A4 | M78 | B/2 | To E11 |
| F1 | M79 | | Body ground |
| A3 | M80 | Y/4 | To D3 |
| F2 | M81 | W/12 | To D115 |
| C1 | M82 | W/40 | Combination meter (with type A) |
| D5 | M83 | B/3 | G sensor |
| E2 | M84 | | Body ground |
| E2 | M85 | | Body ground |
| E5 | M89 | B/2 | Inside key antenna (console) |
| F1 | M90 | B/4 | Remote keyless entry receiver (with Intelligent Key system without tire pressure monitoring system) |
| F2 | M92 | W/8 | To D116 |
| A3 | M93 | W/16 | To D16 |
| F1 | M94 | W/4 | Remote keyless entry receiver (with Intelligent Key system with tire pressure monitoring system) |
| C2 | M95 | B/2 | Inside key antenna (instrument center) |
| C3 | M96 | BR/20 | Joint connector-M05 |
| A2 | M97 | B/40 | BCM (body control module) (with Intelligent Key system) |
| A2 | M98 | W/40 | BCM (body control module) (with Intelligent Key system) |
| A2 | M99 | W/15 | BCM (body control module) (with Intelligent Key system) |
| A2 | M100 | B/15 | BCM (body control module) (with Intelligent Key system) |
| C2 | M151 | BR/4 | Front blower motor resistor |
Scheme 4
Scheme 4: ENGINE ROOM HARNESS
| F1 | E1 | GR/5 | Front wiper motor |
|---|
| A5 | E2 | GR/2 | Front washer motor |
| E4 | E3 | GR/4 | Cooling fan motor (single connector cooling fan without A/C) |
| D4 | E4 | Y/2 | Crash zone sensor |
| E4 | E5 | B/2 | Cooling fan motor (dual connector cooling fan) |
| E2 | E8 | W/24 | To F8 |
| D3 | E9 | BR/2 | Fusible link box (battery) |
| E2 | E10 | GR/2 | Fusible link box (battery) |
| G2 | E15 | | Body ground |
| F2 | E16 | B/32 | ECM |
| F4 | E17 | B/3 | Refrigerant pressure sensor |
| C4 | E18 | B/1 | Horn |
| E2 | E19 | W/6 | To F33 |
| C4 | E20 | B/1 | Horn |
| A2 | E24 | | Body ground |
| G3 | E25 | B/3 | Front combination lamp LH |
| A2 | E26 | B/3 | Front combination lamp RH |
| G2 | E27 | B/2 | Front combination lamp LH |
| A3 | E28 | B/2 | Front combination lamp RH |
| F4 | E29 | GR/3 | Front combination lamp LH |
| B4 | E30 | GR/3 | Front combination lamp RH |
| E4 | E31 | GR/4 | Cooling fan motor (single connector cooling fan with A/C) |
| E4 | E32 | W/2 | Cooling fan motor (dual connector cooling fan) |
| B2 | E33 | B/38 | ABS actuator and electric unit (control unit) |
| E1 | E39 | W/3 | Horn relay |
| E2 | E40 | B/2 | Brake fluid level switch |
| C3 | E41 | L/4 | Starter relay |
| E1 | E42 | B/2 | IPDM E/R (intelligent power distribution module engine room) |
| E2 | E43 | B/6 | IPDM E/R (intelligent power distribution module engine room) |
| F2 | E44 | BR/8 | IPDM E/R (intelligent power distribution module engine room) |
| E2 | E45 | BR/12 | IPDM E/R (intelligent power distribution module engine room) |
| F2 | E46 | W/24 | IPDM E/R (intelligent power distribution module engine room) |
| F2 | E47 | W/16 | IPDM E/R (intelligent power distribution module engine room) |
| B4 | E50 | BR/2 | Washer fluid level switch |
| F3 | E51 | B/2 | Front wheel sensor LH |
| C4 | E52 | B/2 | Front wheel sensor RH |
| G4 | E53 | B/2 | Front fog lamp LH |
| B5 | E54 | B/2 | Front fog lamp RH |
| E2 | E55 | GR/12 | To F55 |
| E5 | E56 | B/2 | Pre-wiring for front fog lamps |
| G3 | E62 | L/4 | Cooling fan relay |
| C3 | E63 | GR/4 | Heated oxygen sensor 2 |
| E4 | E70 | BR/3 | Intelligent Key warning buzzer |
Scheme 5
Scheme 5: ENGINE ROOM HARNESS (PASSENGER COMPARTMENT)
| A3 | E7 | SMJ | To M69 |
|---|
| A4 | E11 | B/2 | To M78 |
| D3 | E12 | B/6 | Accelerator pedal position sensor |
| C3 | E13 | W/4 | Stop lamp switch (with A/T or CVT) |
| B3 | E14 | L/12 | Joint connector-E03 |
| A5 | E21 | GR/16 | To B12 |
| B2 | E22 | W/20 | Joint connector-E02 |
| B3 | E23 | B/2 | EPS control unit |
| C3 | E34 | BR/2 | Clutch interlock switch |
| C3 | E36 | BR/2 | Brake pedal position switch |
| A2 | E37 | B/5 | Daytime light relay 1 |
| A2 | E38 | L/4 | Daytime light relay 2 |
| C4 | E57 | B/2 | Stop lamp switch (with M/T) |
| B2 | E58 | L/4 | Front fog lamp relay |
| A3 | E59 | | Body ground |
| A3 | E60 | | Body ground |
| A2 | E61 | | Body ground |
Scheme 6
Scheme 6: ENGINE CONTROL HARNESS
| C3 | F1 | B/3 | Generator |
|---|
| C3 | F2 | /1 | Generator |
| B4 | F3 | B/1 | A/C compressor |
| C4 | F4 | /1 | Generator |
| C4 | F5 | | Engine ground |
| E2 | F6 | GR/2 | Engine coolant temperature sensor |
| D1 | F7 | B/6 | Electric throttle control actuator |
| E1 | F8 | W/24 | To E8 |
| F2 | F9 | GR/4 | Battery current sensor |
| G2 | F10 | GR/32 | ECM |
| G1 | F11 | BR/48 | ECM |
| D2 | F12 | BR/4 | Air fuel ratio (A/F) sensor 1 |
| C3 | F14 | GR/2 | Knock sensor |
| D2 | F15 | B/3 | Crankshaft position sensor (POS) |
| D3 | F16 | | Engine ground |
| C3 | F17 | B/2 | Fuel injector No. 1 (front) |
| C3 | F18 | B/2 | Fuel injector No. 2 (front) |
| D3 | F19 | B/2 | Fuel injector No. 3 (front) |
| D3 | F20 | B/2 | Fuel injector No. 4 (front) |
| D2 | F21 | B/3 | Intake camshaft position sensor |
| C1 | F22 | GR/2 | EVAP canister purge volume control solenoid valve |
| B3 | F23 | GR/2 | Intake valve timing control solenoid valve |
| F4 | F24 | G/3 | Park/neutral position (PNP) switch |
| C4 | F25 | GR/2 | Engine oil temperature sensor |
| C3 | F26 | W/2 | Condenser |
| D3 | F27 | /1 | Starter motor |
| D4 | F28 | /1 | Starter motor |
| D3 | F29 | B/2 | Fuel injector No. 3 (rear) |
| D3 | F30 | B/2 | Fuel injector No. 4 (rear) |
| D1 | F31 | B/6 | Mass air flow sensor |
| B2 | F32 | GR/2 | Exhaust valve timing control solenoid valve |
| F1 | F33 | W/6 | To E19 |
| B2 | F34 | GR/3 | Ignition coil No. 1 (with power transistor) |
| C2 | F35 | GR/3 | Ignition coil No. 2 (with power transistor) |
| C2 | F36 | GR/3 | Ignition coil No. 3 (with power transistor) |
| D2 | F37 | GR/3 | Ignition coil No. 4 (with power transistor) |
| C4 | F38 | B/3 | Engine oil pressure sensor |
| F3 | F39 | /1 | Fusible link box (battery) |
| F3 | F40 | /1 | Fusible link box (battery) |
| F3 | F41 | B/3 | Output speed sensor |
| F2 | F42 | W/12 | IPDM E/R (intelligent power distribution module engine room) |
| F2 | F43 | W/12 | IPDM E/R (intelligent power distribution module engine room) |
| F2 | F44 | B/48 | TCM (transmission control module) (with CVT) |
| F4 | F46 | GR/22 | CVT unit |
| E3 | F48 | B/3 | Secondary speed sensor |
| F3 | F49 | B/10 | Transmission range switch (with A/T) |
| E3 | F50 | B/3 | Primary speed sensor |
| F3 | F52 | B/10 | Transmission range switch (with CVT) |
| C3 | F53 | B/2 | Fuel injector No. 1 (rear) |
| C3 | F54 | B/2 | Fuel injector No. 2 (rear) |
| F1 | F55 | GR/12 | To E55 |
| E2 | F56 | B/3 | Exhaust camshaft position sensor |
| F3 | F57 | B/48 | TCM (transmission control module) (with A/T) |
| F4 | F58 | GR/22 | A/T assembly |
Scheme 7
| B3 | B2 | W/4 | High-mounted stop lamp (with rear spoiler) |
|---|
| B4 | B3 | GR/3 | EVAP control system pressure sensor |
| C2 | B4 | W/8 | To D201 |
| B4 | B5 | B/2 | EVAP canister vent control valve |
| C3 | B6 | W/4 | Rear door switch LH |
| D4 | B7 | | Body ground |
| D2 | B8 | W/4 | Front door switch LH |
| E3 | B9 | Y/22 | Air bag diagnosis sensor unit |
| B4 | B10 | Y/2 | Front LH side air bag module |
| E3 | B11 | W/8 | To D301 |
| E2 | B12 | GR/16 | To E21 |
| E2 | B13 | W/3 | Seat belt buckle switch LH |
| D2 | B14 | Y/2 | Front LH seat belt pre-tensioner |
| C2 | B15 | Y/2 | Side air bag satellite sensor LH |
| F3 | B16 | W/4 | Front door switch RH |
| E4 | B17 | W/4 | Rear door switch RH |
| B3 | B18 | W/4 | High-mounted stop lamp (without rear spoiler) |
| B3 | B19 | | Body ground |
| B5 | B20 | W/3 | Trunk lid switch |
| B5 | B21 | W/2 | Trunk room lamp |
| C4 | B22 | GR/2 | Rear wheel sensor LH |
| E1 | B23 | W/16 | To M15 |
| G3 | B24 | W/24 | To M16 |
| A4 | B25 | B/6 | Rear combination lamp LH |
| B3 | B26 | Y/2 | LH side curtain air bag module |
| C5 | B27 | B/6 | Rear combination lamp RH |
| B3 | B28 | W/2 | To M11 |
| G3 | B29 | W/16 | To M12 |
| E2 | B30 | W/24 | To M13 |
| A4 | B31 | W/4 | To B375 |
| B5 | B32 | W/4 | Rear view camera |
| C5 | B33 | W/32 | Bluetooth® control unit |
| D5 | B34 | W/8 | Bluetooth® control unit |
| D5 | B35 | B/2 | Rear wheel sensor RH |
| F3 | B36 | W/4 | Occupant classification system control unit |
| E3 | B37 | Y/22 | Air bag diagnosis sensor unit |
| E3 | B38 | Y/2 | Front RH side air bag module |
| F3 | B39 | Y/2 | Front RH seat belt pre-tensioner |
| F3 | B40 | Y/2 | Side air bag satellite sensor RH |
| D4 | B41 | Y/2 | RH side curtain air bag module |
| B3 | B42 | B/2 | Rear window defogger |
| A3 | B43 | | Body ground |
| D4 | B44 | GR/5 | Fuel level sensor unit and fuel pump |
| E3 | B45 | W/3 | Seat belt buckle switch RH |
| B3 | B46 | B/1 | Rear window defogger |
| G3 | B48 | L/2 | Inside key antenna (trunk room) |
| G3 | B49 | L/2 | Outside key antenna (rear bumper) |
| F3 | B50 | BR/2 | Trunk room lamp switch |
| G3 | B51 | W/3 | Trunk lid lock assembly |
| Trunk room harness |
| B4 | B375 | W/4 | To B31 |
| A4 | B376 | W/2 | License plate lamp LH |
| B5 | B377 | W/2 | License plate lamp RH |
Scheme 8
Scheme 8: ROOM LAMP HARNESS
| D5 | R1 | W/8 | To M1 |
|---|
| C2 | R2 | W/6 | Map lamp |
| E1 | R7 | W/3 | Interior room lamp |
| D2 | R15 | W/4 | Microphone |
Scheme 9
Scheme 9: FRONT DOOR LH HARNESS
| D1 | W/12 | To M9 |
|---|
| D2 | W/12 | To M8 |
| D3 | Y/4 | To M80 |
| D4 | W/8 | Door mirror LH |
| D6 | GR/2 | Front outside handle LH (outside key antenna) |
| D7 | W/16 | Main power window and door lock/unlock switch |
| D8 | W/3 | Main power window and door lock/unlock switch |
| D9 | B/2 | Front power window motor LH |
| D11 | Y/2 | Front door satellite sensor LH |
| D12 | W/2 | Front door speaker LH |
| D14 | GR/6 | Front door lock actuator LH |
| D15 | BR/3 | Front door lock key cylinder switch LH |
| D16 | W/16 | To M93 |
| D17 | GR/2 | Front outside handle LH (request switch) |
Scheme 10
Scheme 10: FRONT DOOR RH HARNESS
| D101 | Y/4 | To M75 |
|---|
| D102 | W/4 | To M74 |
| D104 | B/2 | Front power window motor RH |
| D105 | W/12 | Power window and door lock/unlock switch RH |
| D106 | GR/2 | Front outside handle RH (outside key antenna) |
| D107 | W/8 | Door mirror RH |
| D111 | Y/2 | Front door satellite sensor RH |
| D112 | W/2 | Front door speaker RH |
| D113 | GR/2 | Front outside handle RH (request switch) |
| D114 | GR/6 | Front door lock actuator RH |
| D115 | W/12 | To M81 |
| D116 | W/8 | To M92 |
Scheme 11
Scheme 11: REAR DOOR LH HARNESS
| D201 | W/8 | To B4 |
|---|
| D203 | W/8 | Rear power window switch LH |
| D204 | B/2 | Rear power window motor LH |
| D205 | GR/6 | Rear door lock actuator LH |
| D207 | W/2 | Rear door speaker LH |
Scheme 12
Scheme 12: REAR DOOR RH HARNESS
| D301 | W/8 | To B11 |
|---|
| D303 | W/8 | Rear power window switch RH |
| D304 | B/2 | Rear power window motor RH |
| D305 | GR/6 | Rear door lock actuator RH |
| D307 | W/2 | Rear door speaker RH |
Scheme 13
Scheme 13: ENGINE COMPARTMENT
Scheme 14
Scheme 14: PASSENGER COMPARTMENT
Scheme 15
Scheme 16
Scheme 16: LUGGAGE COMPARTMENT
HARNESS CONNECTOR (TAB-LOCKING TYPE)
- The tab-locking type connectors help prevent accidental looseness or disconnection.
- The tab-locking type connectors are disconnected by pushing or lifting the locking tab(s). Refer to the figure below.
| CAUTION | Do not pull the harness or wires when disconnecting the connector. |
Scheme 17
HARNESS CONNECTOR (SLIDE-LOCKING TYPE)
- A new style slide-locking type connector is used on certain systems and components, especially those related to OBD.
- The slide-locking type connectors help prevent incomplete locking and accidental looseness or disconnection.
- The slide-locking type connectors are disconnected by pushing or pulling the slider. Refer to the figure below.
| CAUTION | Do not pull the harness or wires when disconnecting the connector. Be careful not to damage the connector support bracket when disconnecting the connector. |
Scheme 18
HARNESS CONNECTOR (LEVER LOCKING TYPE)
- Lever locking type harness connectors are used on certain control units and control modules such as ECM, ABS actuator and electric unit (control unit), etc.
- Lever locking type harness connectors are also used on super multiple junction (SMJ) connectors.
- Always confirm the lever is fully locked in place by moving the lever as far as it will go to ensure full connection.
| CAUTION | Always confirm the lever is fully released (loosened) before attempting to disconnect or connect these connectors to avoid damage to the connector housing or terminals. |
Scheme 19
HARNESS CONNECTOR (DIRECT-CONNECT SRS COMPONENT TYPE)
- SRS direct-connect type harness connectors are used on certain SRS components such as air bag modules and seat belt pre-tensioners.
- Always pull up to release black locking tab prior to removing connector from SRS components.
- Always push down to lock black locking tab after installing connector to SRS components. When locked, the black locking tab is level with the connector housing.
| CAUTION | Do not pull the harness or wires when removing connectors from SRS components. |
Scheme 20
