Seat: Removal & Installation Nissan Versa I

Seats 19 illustrations ~816 words

Removal and Installation

CAUTIONWhen removing and installing, use shop cloths to protect parts from damage. Disconnect both battery cables before work.

Scheme 1

Scheme 1: Removal
Scheme 1: Removal

Scheme 2

Scheme 2
Scheme 2
  1. Remove the rear leg covers.
  2. Remove the front leg covers.
  3. Remove the mounting bolts on the back side of the front seat. (TORX bolt: T50)
  4. Remove the mounting bolts on the front side of the front seat. (TORX bolt: T50)
  5. Disconnect the harness connector under the seat and remove harness securing clips. CAUTION: Before removal, be sure to turn ignition switch OFF, disconnect both battery cables, and then wait for at least 3 minutes.
  6. Set seatback in a neutral position, and then remove front seat from the vehicle.

Installation

Install in the reverse order of removal. Be careful of the following three points.

  1. Before the installation, confirm that the inside and outside slide rails are locked at the same positions.
  2. Confirm that the slide rail location pin is set to the hole on the floor.
  3. Clamp the harness in position.
CAUTIONFront passenger seat is equipped with an Occupant Classification System sensor and control module. Do not disassemble front passenger seat cushion assembly or remove the trim as this will affect the Occupant Classification System calibration. During installation, the wire harness clips must be installed in the holes they were originally in. Do not add additional clips.
CAUTIONWhen removing and installing, use shop cloths to protect parts from damage.

Scheme 3

Scheme 3: Removal
Scheme 3: Removal

Scheme 4

Scheme 4
Scheme 4

Scheme 5

Scheme 5
Scheme 5

Scheme 6

Scheme 6
Scheme 6

Scheme 7

Scheme 7
Scheme 7

Scheme 8

Scheme 8
Scheme 8

Scheme 9

Scheme 9
Scheme 9
  1. Pull seat cushion up, and then remove the seat cushion from the seat cushion hook.
  2. Remove the center seatbelt anchor bolt from under the seat.
  3. Remove the seatback mounting bolts from the right rear seat back brackets.
  4. Remove the seatback mounting bolts from the left rear seat back brackets.
  5. Remove the seatback from the vehicle.
  6. Remove the kicking plate rear inner. Refer to " «REMOVAL AND INSTALLATION»(ref-337622-S38699366922009080600000) ".
  7. Remove the bolt under the seatback side.
  8. Pull seatback side up, and then remove seatback side.
  9. Remove the bolts, and then remove rear seatback center bracket.
  10. Remove the bolt, and then remove rear seatback side bracket from the vehicle.
  11. Remove the rear seatback finisher. Refer to " «REMOVAL AND INSTALLATION»(ref-337622-S20706753252009080600000) ".
  12. Remove the bolts, and then remove the rear seat striker.

Installation is the reverse order of removal. Be careful of the following point.

  1. Seatback assembly and rear seatback side bracket installation procedure.
  1. Install the rear seatback side bracket in the vehicle.
  2. Temporarily tighten the seatback assembly and rear seatback side bracket.
  3. Lift to fold up seatback assembly. Be sure to lock seatback assembly to rear seat striker.
  4. Tighten the bolt.

Note. Confirm that side hinge bracket location pin is set to the hole on the seatback backside.

Scheme 10

Scheme 10: Disassembly of Armrest
Scheme 10: Disassembly of Armrest

Scheme 11

Scheme 11
Scheme 11

Scheme 12

Scheme 12
Scheme 12
  1. Fold up the backside of the seatback trim and then remove the armrest nuts.
  2. Push the armrest toward left side while pulling backward to remove.
  3. Remove the rear seat bushing, and then remove the armrest hinge cover by pulling it backward.
CAUTIONWhen removing and installing, use shop cloths to protect parts from damage.

Scheme 13

Scheme 13
Scheme 13

Scheme 14

Scheme 14
Scheme 14

Scheme 15

Scheme 15
Scheme 15
  1. Pull seat cushion up, and then remove the seat cushion from the seat cushion hook. Slide the seat cushion forward.
  2. Remove the center seatbelt anchor bolt (A) from under the seat and slide the seatbelt through the seat cushion trim cover.
  3. Fold the right seatback and remove the seatback mounting bolts (A) from the left rear seat back brackets. Remove the seatback from the vehicle.
  4. Fold the left seatback and remove the seatback mounting bolts (A) from the left rear seat back brackets. Remove the seatback from the vehicle.
  5. Remove the kicking plate rear inner. Refer to " «REMOVAL AND INSTALLATION»(ref-337622-S38699366922009080600000) ".
  6. Remove the bolt under the seatback side.
  7. Pull seatback side up, and then remove seatback side.
  8. Remove the bolts, and then remove rear seatback center bracket.
  9. Remove the bolt, and then remove rear seatback side bracket from the vehicle.
  10. Remove the rear seatback finisher. Refer to " «REMOVAL AND INSTALLATION»(ref-337622-S20706753252009080600000) ".
  11. Remove the bolts, and then remove the rear seat striker.

Installation is the reverse order of removal. Be careful of the following point.

  1. Seatback assembly and rear seatback side bracket installation procedure.
  1. Install the rear seatback side bracket in the vehicle.
  2. Temporarily tighten the seatback assembly and rear seatback side bracket.
  3. Lift to fold up seatback assembly. Be sure to lock seatback assembly to rear seat striker.
  4. Tighten the bolt. NOTE: Confirm that side hinge bracket location pin is set to the hole on the seatback backside.

Scheme 16

Scheme 16: Disassembly of Armrest
Scheme 16: Disassembly of Armrest

Scheme 17

Scheme 17
Scheme 17

Scheme 18

Scheme 18
Scheme 18
  1. Fold down the armrest and remove the armrest bolt cover (A).
  2. Remove the armrest bolt (A).
  3. Push the armrest toward left side while pulling backward to remove.
  4. Remove the rear seat bushing, and then remove the armrest hinge cover by pulling it backward.
CAUTIONWhen removing and installing, use shop cloths to protect parts from damage.

Scheme 19

Scheme 19
Scheme 19
  1. Pull seat cushion up, and then remove the seat cushion from the seat cushion hook. Slide the seat cushion forward.
  2. Remove the center seatbelt anchor bolt (A) from under the seat and slide the seatbelt through the seat cushion trim cover.
  3. Remove the lower seatback bolts and lift seatback to disengage from upper seatback bracket.

Installation is the reverse order of removal.

Remove the rings to separate the trim and pad.

Assembly is the reverse order of disassembly. Be careful of the following one point.

Remove the rings to separate the trim and pad.

Assembly is the reverse order of disassembly.
