Engine Cooling System: Diagnosis Nissan Versa I

Cooling Fan 6 illustrations ~520 words

Troubleshooting Chart

SymptomCheck items
Cooling system parts malfunctionPoor heat transferWater pump malfunctionWorn or loose drive belt
Thermostat stuck closedThermostat
Damaged finsDust contamination or paper clogging
Physical damage
Clogged radiator cooling tubeExcess foreign material (rust, dirt, sand, etc.)
Reduced air flowCooling fan does not operateFan assembly
High resistance to fan rotation
Damaged fan blades
Damaged radiator shroud
Improper engine coolant mixture ratioEngine coolant viscosity
Poor engine coolant quality
Insufficient engine coolantEngine coolant leaksCooling hoseLoose clamp
Cracked hose
Water pumpPoor sealing
Radiator capLoose
Poor sealing
RadiatorO-ring for damage, deterioration or improper fitting
Cracked radiator tank
Cracked radiator core
Reservoir tankCracked reservoir tank
Overflowing reservoir tankExhaust gas leaks into cooling systemCylinder head deterioration
Cylinder head gasket deterioration
Except cooling system parts malfunctionOverload on engineAbusive drivingHigh engine RPM under no load
Driving in low gear for extended time
Driving at extremely high speed
Power train system malfunction
Installed improper size wheels and tires
Dragging brakes
Improper ignition timing
Blocked or restricted air flowBlocked bumperInstalled front bumper fascia cover
Blocked radiator grille
Mud contamination or paper clogging
Blocked radiatorBlocked air flow
Blocked condenser
Installed large fog lamp

TROUBLESHOOTING CHART

Scheme 5

Scheme 5: Cooling Circuit

INSPECTION AFTER INSTALLATION

  1. Check for leaks of engine coolant. Refer to " «LEVEL CHECK»(ref-337624-S15551089212009080600000) ".
  2. Start and warm up engine. Visually check if there is no leaks of engine coolant and CVT or A/T fluid if equipped. Refer to " «CVT FLUID»(ref-337628-S15518868582009080600000) " or " «A/T FLUID»(ref-337615-S30547971652009080600000) ".

Scheme 6

Scheme 6: Checking Radiator Cap

Scheme 7

Scheme 7

Scheme 8

Scheme 8
  1. Check valve seat of radiator cap. Check if valve seat is swollen to the extent that the edge of the plunger cannot be seen when watching it vertically from the top. Check if valve seat has no soil and damage.
  2. Pull negative-pressure valve to open it, and make sure that it is completely closed when released. Make sure that there is no dirt or damage on the valve seat of radiator cap negative-pressure valve. Make sure that the valve operates properly in the opening and closing conditions.
  3. Check radiator cap relief pressure using Tool. Tool number: EG17650301 (J-33984-A) Standard: 78 - 98 kPa (0.78 - 0.98 bar, 0.8 - 1.0 kg/cm 2 , 11 - 14 psi) Limit: 59 kPa (0.59 bar, 0.6 kg/cm 2 , 9 psi) When connecting the radiator cap to the tester, apply water or coolant to the cap seal surface. Replace the radiator cap if there is an abnormality in the negative-pressure valve, or if the open-valve pressure is outside of the standard values.
  4. Replace radiator cap if there it does not comply to specifications to the above three checks. CAUTION: When installing radiator cap, thoroughly wipe out the radiator filler neck to remove any waxy residue or foreign material.

INSPECTION AFTER DISASSEMBLY

Inspect cooling fan for crack or unusual bend.

  1. If anything is found, replace cooling fan.

INSPECTION AFTER REMOVAL

  1. Visually check that there is no significant dirt or rusting on water pump body and vane (A).
  2. Make sure that there is no looseness in vane shaft, and that it turns smoothly when rotated by hand.
  3. Replace water pump, if necessary.
  1. Check for leaks of engine coolant. Refer to " «INSPECTION»(ref-337624-S32436696672009080600000) ".
  2. Start and warm up the engine. Visually check if there is no leaks of engine coolant.

Scheme 9

Scheme 9: Components
  1. Place a thread (A) so that it is caught in the valves of thermostat (1). Immerse fully in a container (B) filled with water. Heat while stirring.
  2. The valve opening temperature is the temperature at which the valve opens and falls from the thread.
  3. Continue heating. Check the full open valve lift amount.
  4. After checking the maximum valve lift amount, lower the water temperature and check the valve closing temperature. VALVE OPENING TEMPERATURE SPECIFICATION Items Thermostat Valve opening temperature 80.5 - 83.5°C (177 - 182°F) Maximum valve lift 8 mm/95°C (0.315 in/203°F) Valve closing temperature 77°C (171°F)
  5. If out of the specification, replace thermostat.
  1. Check for leaks of engine coolant. Refer to " «CHECKING COOLING SYSTEM FOR LEAKS»(ref-337624-S01447429422009080600000) ".
  2. Start and warm up the engine. Visually check for engine coolant leaks.

Scheme 10

Scheme 10: Components
  1. Check for leaks of engine coolant. Refer to " «INSPECTION»(ref-337624-S32436696672009080600000) ".
  2. Start and warm up the engine. Visually check if there is no leaks of engine coolant.
