Maintenance: Other Nissan Titan I рестайлинг

Precaution for Supplemental Restraint System (SRS) "AIR BAG" and "SEAT BELT PRE-TENSIONER"

The Supplemental Restraint System such as "AIR BAG" and "SEAT BELT PRE-TENSIONER", used along with a front seat belt, helps to reduce the risk or severity of injury to the driver and front passenger for certain types of collision. This system includes seat belt switch inputs and dual stage front air bag modules. The SRS system uses the seat belt switches to determine the front air bag deployment, and may only deploy one front air bag, depending on the severity of a collision and whether the front occupants are belted or unbelted.

Information necessary to service the system safely is included in the SRS AIRBAG and SEAT BELTS articles.

PRECAUTIONS WHEN USING POWER TOOLS (AIR OR ELECTRIC) AND HAMMERS

Special Service Tool

The actual shapes of the Kent-Moore tools may differ from those of the special service tools illustrated here.

SPECIAL SERVICE TOOL DESCRIPTION CHART Tool number (Kent-Moore No.) Tool name Description KV10115801 (J-38956) Oil filter cap wrench Removing and installing oil filter a: 64.3 mm (2.531 in) KV991J0010 (J-23688) Engine coolant refractometer Checking concentration of ethylene glycol in engine coolant KV991J0070 (J-45695) Coolant refill tool Filling cooling system

Scheme 14

Commercial Service Tool

COMMERCIAL SERVICE TOOL DESCRIPTION CHART (Kent-Moore No.) Tool name Description Power tool Loosening bolts and nuts Spark plug wrench Removing and installing spark plug

Scheme 15

General maintenance includes those items which should be checked during the normal day-to-day operation of the vehicle. They are essential if the vehicle is to continue operating properly. The owner can perform these checks and inspections or have their NISSAN dealers perform them.

OUTSIDE THE VEHICLE

The maintenance items listed here should be performed from time to time, unless otherwise specified.

MAINTENANCE ITEMS CHART

INSIDE THE VEHICLE

The maintenance items listed here should be checked on a regular basis, such as when performing periodic maintenance, cleaning the vehicle, etc.

INSIDE THE VEHICLE REFERENCE CHART

UNDER THE HOOD AND VEHICLE

The maintenance items listed here should be checked periodically (e.g. each time you check the engine oil or refuel).

UNDER THE HOOD AND VEHICLE REFERENCE CHART

Two different maintenance schedules are provided, and should be used, depending upon the conditions in which the vehicle is mainly operated. After 60,000 miles (96,000 km) or 48 months, continue the periodic maintenance at the same mileage or time intervals, whichever comes first.

PERIODIC MAINTENANCE REFERENCE CHART

Maintenance for off-road driving (4WD only)

After driving the vehicle off-road through sand, mud, or water; more frequent maintenance may be required for the following items

↑ Brake pads and rotors

↑ Brake lines and hoses

↑ Rear final drive oil, transmission fluid, and transfer fluid

↑ Steering linkage

↑ Drive shafts

↑ Engine air cleaner filter

EMISSION CONTROL SYSTEM MAINTENANCE REFERENCE CHART

MAINTENANCE OPERATION CHART

CHASSIS AND BODY MAINTENANCE CHART

MAINTENANCE OPERATION CHART

EMISSION CONTROL SYSTEM MAINTENANCE REFERENCE CHART

CHASSIS AND BODY MAINTENANCE REFERENCE CHART

Engine Oil Recommendation

NISSAN recommends the use of an energy conserving oil in order to improve fuel economy. Select only engine oils that meet the American Petroleum Institute (API) certification and International Lubricant Standardization and Approval Committee (ILSAC) certification and SAE viscosity standard (2). These oils have the API certification mark (1) on the front of the container. Oils which do not have the specified quality label should not be used as they could cause engine damage.

Scheme 16

ANTI-FREEZE COOLANT MIXTURE RATIO

The engine cooling system is filled at the factory with a high-quality, long life, year-round, anti-freeze coolant solution. The anti-freeze solution contains rust and corrosion inhibitors. Therefore, additional cooling system additives are not necessary.

ANTI-FREEZE COOLANT MIXTURE RATIO REFERENCE CHART

Scheme 17

1. Remove air duct and resonator assembly when inspecting drive belt.
2. Make sure that indicator (single line notch) of each auto tensioner is within the allowable working range (between three line notches). NOTE: Check the drive belt auto tensioner indication when the engine is cold. The indicator notch is located on the moving side of the drive belt auto tensioner.
3. Visually check entire belt for wear, damage or cracks.
4. If the indicator is out of allowable working range or belt is damaged, replace the belt. Refer to «ENGINE MAINTENANCE»(ref-396290-S25315798992011050400000) .

DRIVE BELT TENSION

There is no manual drive belt tension adjustment. The drive belt tension is automatically adjusted by the drive belt auto tensioner.

Changing Engine Coolant

Scheme 18

Scheme 19

Scheme 20

1. Turn ignition switch ON and set temperature control lever all the way to HOT position or the highest temperature position. Wait 10 seconds and turn ignition switch OFF.
2. Remove the engine under cover or skid plate. Refer to " «REMOVAL AND INSTALLATION»(ref-396300-S26721633592011050400000) ".
3. Open the radiator drain plug at the bottom of the radiator, and remove the radiator filler cap. This is the only step required when partially draining the cooling system (radiator only). CAUTION: Do not to allow the coolant to contact the drive belts.
4. When draining all of the coolant in the system for engine removal or repair, it is necessary to drain the cylinder block. Remove the RH cylinder block drain plug to drain the right bank and the oil cooler hose to drain the left bank as shown in illustration(s).
5. Remove the reservoir tank to drain the engine coolant, then clean the reservoir tank before installing it.
6. Check the drained coolant for contaminants such as rust, corrosion or discoloration. If the coolant is contaminated, flush the engine cooling system. Refer to " «CHANGING ENGINE COOLANT»(ref-396290-S39690432462011050400000) ".

Scheme 21

Scheme 22

1. Close the radiator drain plug. Install the reservoir tank, cylinder block drain plug, and the oil cooler hose, if removed for a total system drain or for engine removal or repair. The radiator must be completely empty of coolant and water. Apply sealant to the threads of the cylinder block drain plug. Use Genuine High Performance Thread Sealant or equivalent. Refer to " «RECOMMENDED CHEMICAL PRODUCTS AND SEALANTS»(ref-396282-S42091394092011050400000) ". Radiator drain plug : Refer to «ON-VEHICLE REPAIR»(ref-396293-S04333105012011050400000) . RH cylinder block drain plug : Refer to «ENGINE MAINTENANCE»(ref-396290-S25315798992011050400000) .
2. Set the vehicle heater controls to the full HOT and heater ON position. Turn the vehicle ignition ON with the engine OFF as necessary to activate the heater mode.
3. Remove the vented reservoir cap and replace it with a non-vented reservoir cap before filling the cooling system.
4. Install the Tool by installing the radiator cap adapter onto the radiator neck opening. Then attach the gauge body assembly with the refill tube and the venturi assembly to the radiator cap adapter. Tool number : KV991J0070 (J-45695)
5. Insert the refill hose into the coolant mixture container that is placed at floor level. Make sure the ball valve is in the closed position. Use Genuine NISSAN Long Life Anti-freeze coolant or equivalent, mixed 50/50 with distilled water or demineralized water. Refer to " «FLUIDS AND LUBRICANTS»(ref-396290-S39429400472011050400000) ". Cooling system capacity (with reservoir) : Refer to " «STANDARD AND LIMIT»(ref-396293-S40825831272011050400000) ".
6. Install an air hose to the venturi assembly, the air pressure must be within specification. Compressed air supply pressure : 549 - 824 kPa (5.6 - 8.4 kg/cm 2 , 80 - 119 psi) CAUTION: The compressed air supply must be equipped with an air dryer.
7. The vacuum gauge will begin to rise and there will be an audible hissing noise. During this process open the ball valve on the refill hose slightly. Coolant will be visible rising in the refill hose. Once the refill hose is full of coolant, close the ball valve. This will purge any air trapped in the refill hose.
8. Continue to draw the vacuum until the gauge reaches 28 inches of vacuum. The gauge may not reach 28 inches in high altitude locations, refer to the vacuum specifications based on the altitude above sea level. Altitude above sea level Vacuum gauge reading 0 - 100 m (328 ft) : 28 inches of vacuum 300 m (984 ft) : 27 inches of vacuum 500 m (1,641 ft) : 26 inches of vacuum 1,000 m (3,281 ft) : 24 - 25 inches of vacuum
9. When the vacuum gauge has reached the specified amount, disconnect the air hose and wait 20 seconds to see if the system loses any vacuum. If the vacuum level drops, perform any necessary repairs to the system and repeat steps 6 - 8 to bring the vacuum to the specified amount. Recheck for any leaks.
10. Place the coolant container (with the refill hose inserted) at the same level as the top of the radiator. Then open the ball valve on the refill hose so the coolant will be drawn up to fill the cooling system. The cooling system is full when the vacuum gauge reads zero. CAUTION: Do not allow the coolant container to get too low when filling, to avoid air from being drawn into the cooling system.
11. Remove the Tool from the radiator neck opening and install the radiator cap.
12. Remove the non-vented reservoir cap.
13. Fill the cooling system reservoir tank to the specified level. Run the engine to warm up the cooling system and top up the system as necessary before installing the vented reservoir cap.

Checking Fuel Line

Inspect fuel lines, fuel filler cap and fuel tank for improper attachment, leaks, cracks, damage, loose connections, chafing or deterioration.

If necessary, repair or replace damaged parts.

Scheme 23

Changing Fuel Filter

The fuel filter is part of the fuel level sensor unit, fuel filter and fuel pump assembly. Refer to FUEL LEVEL SENSOR UNIT, FUEL FILTER AND FUEL PUMP ASSEMBLY .

Scheme 24

Changing Engine Oil

Scheme 25

1. Remove engine under cover or skid plate. Refer to " «REMOVAL AND INSTALLATION»(ref-396300-S26721633592011050400000) ".
2. Warm up engine, and check for oil leakage from engine components. Refer to " «INSPECTION»(ref-396316-S08981481972011050400000) ".
3. Stop engine and wait for 10 minutes.
4. Loosen oil filler cap, then remove drain plug.
5. Drain engine oil.
6. Install drain plug with new washer. CAUTION: Be sure to clean drain plug and install with new washer. Oil pan drain plug : 34.3 N.m (3.5 kg-m, 25 ft-lb)
7. Refill with new engine oil. Refer to " «FLUIDS AND LUBRICANTS»(ref-396290-S39429400472011050400000) ". Engine oil capacity (Approximate): Unit: l (US qt, Imp qt) ENGINE OIL CAPACITY REFERENCE CHART Drain and refill With oil filter change 6.5 (6 7/8, 5 3/4) Without oil filter change 6.2 (6 1/2, 5 1/2) Dry engine (engine overhaul) 7.6 (8, 6 3/4) CAUTION: The refill capacity depends on the engine oil temperature and drain time. Use these specifications for reference only. Always use the oil level gauge to determine when the proper amount of engine oil is in the engine.
8. Warm up engine and check area around drain plug and oil filter for oil leakage.
9. Stop engine and wait for 10 minutes.
10. Check engine oil level. Refer to " «INSPECTION»(ref-396316-S08981481972011050400000) ".

Scheme 26

1. Drain the engine oil. Refer to " «CHANGING ENGINE OIL»(ref-396316-S23820009292011050400000) ".
2. Remove the oil filter using Tool. Tool number : KV10115801 (J-38956) WARNING: Be careful not to get burned when the engine and engine oil are hot.

Scheme 27

Scheme 28

1. Remove foreign materials adhering to the oil filter installation surface.
2. Apply engine oil to the oil seal circumference of the new oil filter.
3. Screw the oil filter manually until it touches the installation surface, then tighten it by 2/3 turn. Or tighten to specification. Oil filter : 17.7 N.m (1.8 kg-m, 13 ft-lb)
4. Refill the engine with new engine oil. Refer to " «CHANGING ENGINE OIL»(ref-396316-S23820009292011050400000) ".
5. Inspect the engine for oil leakage. Follow the "INSPECTION AFTER INSTALLATION" procedure.

Checking EVAP Vapor Line

1. Visually inspect the EVAP vapor lines for improper attachment, cracks, damage, loose connections, chafing, or deterioration.
2. Inspect the vacuum relief valve of the fuel tank filler cap for clogging and sticking. Refer to " «HOW TO DETECT FUEL VAPOR LEAKAGE»(ref-396286-S11713587662011050400000) ".

Scheme 29

Scheme 30

Scheme 31

1. Remove the two lower glove box hinge pins to remove the glove box from the instrument panel and let it hang from the cord.
2. Remove the screw and remove the in-cabin microfilter cover.
3. Remove the in-cabin microfilters from the heater and cooling unit assembly housing.
4. Insert the first new in-cabin microfilter into the heater and cooling unit assembly housing and slide it over to the right. Insert the second new in-cabin microfilter into the heater and cooling unit assembly housing. NOTE: The in-cabin microfilters are marked with air flow arrows. The end of the microfilter with the arrow should face the rear of the vehicle. The arrows should point downward.
5. Install the in-cabin microfilter cover.
6. Install the lower glove box in the instrument panel and secure it with the two hinge pins.

Checking Exhaust System

Check exhaust pipes, muffler and mounting for improper attachment, leaks, cracks, damage or deterioration.

1. If anything is found, repair or replace damaged parts.

Scheme 32

Checking Propeller Shaft

Check the front and rear propeller shafts for damage, dents, and cracks. Check the joints for looseness and any damage. Repair or replace as necessary.

DIFFERENTIAL GEAR OIL LEAKAGE AND LEVEL

1. Make sure that differential gear oil is not leaking from the front final drive assembly or around it.
2. Check the differential gear oil level from the filler plug hole as shown in illustration. CAUTION: Do not start engine while checking differential gear oil level.
3. Install the filler plug with sealant applied on the threads to the front final drive assembly. Tighten to the specified torque. Refer to " «DISASSEMBLY AND ASSEMBLY»(ref-396313-S00732660712011050400000) ". Use High Performance Thread Sealant or equivalent. Refer to " «RECOMMENDED CHEMICAL PRODUCTS AND SEALANTS»(ref-396282-S42091394092011050400000) ".

1. Make sure that differential gear oil is not leaking from the rear final drive assembly or around it.
2. Check the differential gear oil level from the filler plug hole as shown in illustration. CAUTION: Do not start engine while checking differential gear oil level.
3. Install the filler plug with sealant applied on the threads to the rear final drive assembly. Tighten to the specified torque. Refer to " «DISASSEMBLY AND ASSEMBLY»(ref-396326-S09069238642011050400000) " (without ELD) or " «DISASSEMBLY AND ASSEMBLY»(ref-396303-S24230191972011050400000) " (with ELD). Use High Performance Thread Sealant or equivalent. Refer to " «RECOMMENDED CHEMICAL PRODUCTS AND SEALANTS»(ref-396282-S42091394092011050400000) ".

BALANCING WHEELS (ADHESIVE WEIGHT TYPE)

Preparation Before Adjustment

Remove inner and outer balance weights from the road wheel using releasing agent, remove double-faced adhesive tape from the road wheel.

Wheel Balance Adjustment

1. If a balancer machine has an adhesive weight mode setting, select the adhesive weight mode setting and skip Step 2. below. If a balancer machine only has the clip-on (rim flange) weight mode setting, follow Step 2. to calculate the correct size adhesive weight.

Scheme 33

Scheme 34

Scheme 35

1. Set road wheel on balancer machine using the center hole as a guide. Start the balancer machine.
2. For tire balance machines that only have a clip-on (rim flange) weight mode setting, follow this step to calculate the correct size adhesive weight to use. When inner and outer imbalance values are shown in illustration on the balancer machine indicator, multiply outer imbalance value by 5/3 (1.67) to determine balance weight that should be used. Select the outer balance weight with a value closest to the calculated value above and install in to the designated outer position of, or at the designated angle in relation to the road wheel. Indicated unbalance value x 5/3 = balance weight to be installed Calculation example: 23 g (0.81 oz) x 5/3 (1.67) = 38.33 g (1.35 oz) --> 40 g (1.41 oz) balance weight (closer to calculated balance weight value) NOTE: Note that balance weight value must be closer to the calculated balance weight value. Example: 37.4 --> 35 g (1.23 oz) 37.5 --> 40 g (1.41 oz)
3. Install balance weight in the position shown in illustration. CAUTION: Do not install the inner balance weight before installing the outer balance weight. Before installing the balance weight, be sure to clean the mating surface of the road wheel. When installing balance weight (1) to road wheel, set it into the grooved area (A) on the inner wall of the road wheel as shown in illustration so that the balance weight center (B) is aligned with the balancer machine indication position (angle) (C). CAUTION: Always use genuine NISSAN adhesive balance weights. Balance weights are non-reusable; always replace with new ones. Do not install more than three sheets of balance weight.
4. If calculated balance weight value exceeds 50 g (1.76 oz), install two balance weight sheets in line with each other as shown in illustration. CAUTION: Do not install one balance weight sheet on top another.
5. Start balancer machine again.
6. Install balance weight on inner side of road wheel in the balancer machine indication position (angle). CAUTION: Do not install more than two balance weight.
7. Start balancer machine. Make sure that inner and outer residual unbalance values are 5 g (0.17 oz) each or below.
8. If either residual unbalance value exceeds 5 g (0.17 oz), repeat installation procedures. WHEEL BALANCE REFERENCE CHART Wheel balance Dynamic (At flange) Static (At flange) Maximum allowable unbalance Refer to " «INSPECTION»(ref-396315-S08574009712011050400000) ".

Scheme 36

1. Follow the maintenance schedule for tire rotation service intervals. Refer to " «SCHEDULE 1»(ref-396290-S10659361092011050400000) ".
2. When installing the wheel, tighten wheel nuts to the specified torque. CAUTION: Do not include the T-type spare tire when rotating the tires. When installing wheels, tighten them diagonally by dividing the work two to three times in order to prevent the wheels from developing any distortion. Be careful not to tighten wheel nut at torque exceeding the criteria for preventing strain of disc rotor. Use NISSAN genuine wheel nuts for aluminum wheels. Wheel nut tightening torque : 133 N.m (14 kg-m, 98 ft-lb)
3. Perform the ID registration, after tire rotation. Refer to " «ID REGISTRATION PROCEDURE»(ref-396315-S07238595872011050400000) ".

LEVEL CHECK

1. Make sure the fluid level in reservoir tank is between MAX and MIN lines as shown in illustration.
2. Visually check around reservoir tank for fluid leaks.
3. If fluid level is excessively low, check brake system for leaks.
4. If brake warning lamp remains illuminated after parking brake pedal is released, check brake system for fluid leaks.

Scheme 37

Checking Brake Line and Cables

1. Check the brake lines and hoses for cracks, deterioration, and other damage. Replace any damaged parts. CAUTION: If brake fluid leaks are visible around the brake line joints, retighten the joint, or replace damaged parts as necessary.
2. Check for brake fluid leaks by fully depressing brake pedal while engine is running.

Scheme 38

ROTOR

Check the rotor condition for wear or damage. Refer to " DISC ROTOR : INSPECTION " (front disc rotor), " DISC ROTOR : INSPECTION " (rear disc rotor).

Scheme 39

CALIPER

Check the caliper for leaks, repair as necessary.

Scheme 40

PAD

Check the pads for wear or damage. Refer to " BRAKE PAD : INSPECTION " (front disc pad), " BRAKE PAD : INSPECTION " (rear disc pad).

Scheme 41

STEERING GEAR

1. Check the steering gear housing for looseness, damage, and oil leakage as shown in illustration.
2. Check the steering column connections for looseness.

Scheme 42

STEERING LINKAGE

1. Check the ball joint, dust cover and other component parts for looseness, wear, damage, and grease leakage.

CHECKING LINES

1. Check lines for improper attachment, leaks, cracks, damage, loose connections, chafing, and deterioration.

FRONT AND REAR AXLE AND SUSPENSION PARTS

Check front and rear axle and suspension parts for excessive play, cracks, wear or other damage.

Scheme 43

1. Shake each wheel to check for excessive play.
2. Rotate each wheel to check for abnormal noise.
3. Check the axle and suspension nuts and bolts for looseness.
4. Check the strut and shock absorber for oil leakage or other damage.
5. Check the suspension ball joints for grease leakage and ball joint dust cover for cracks or other damage.

PROPELLER SHAFT

Inspect the propeller shaft tube for dents or cracks. If damaged, replace the propeller shaft assembly.

Scheme 44

Note. Lubricate the locations shown in illustration with a suitable multi-purpose grease. Refer to " FLUIDS AND LUBRICANTS "

Checking Seat Belts, Buckles, Retractors, Anchors and Adjusters

Check the seat belt buckles, webbing, retractors, anchors and adjusters. Replace any seat belt assembly as necessary. Refer to " SEAT BELT INSPECTION ".

1. Check the seat belt anchors for loose mounting bolts, damage, or excessive wear.
2. Check the seat belt webbing for any damage, cuts, fraying, or excessive wear.
3. Check the retractor for smooth operation.
4. Check the function of the buckles by inserting the seat belt tongue and checking for proper engagement of the buckle and press the button on the buckle to check for proper release of the seat belt tongue.
