Accelerator Control System: Removal & Installation Nissan Titan I рестайлинг

Engine Control Systems 2 illustrations ~249 words

Removal

  1. Move the accelerator and brake pedals to the front-most position.
  2. Turn the ignition switch OFF and disconnect the negative battery terminal.
  3. Disconnect the adjustable brake pedal cable from the adjustable brake pedal. Unlock, then pull the adjustable brake pedal cable to disconnect it from the adjustable brake pedal.
  4. Disconnect the adjustable pedal electric motor electrical connector.
  5. Disconnect the adjustable pedal electric motor memory electrical connector, if equipped.
  6. Disconnect the accelerator position sensor electrical connector.
  7. Remove the two upper and one lower accelerator pedal nuts.
  8. Remove the adjustable accelerator pedal assembly.
CAUTIONDo not disassemble the accelerator pedal assembly. Do not remove the accelerator pedal position sensor from the accelerator pedal bracket. Do not disassemble the accelerator pedal adjusting mechanism. Avoid damage from dropping the accelerator pedal assembly during handling. Keep the accelerator pedal assembly away from water.

Scheme 1

Scheme 1
Scheme 1

Installation

Installation is in the reverse order of removal.

Inspection After Installation

  1. Check that the accelerator pedal moves smoothly within the specified ranges.
  2. Depress and release the accelerator pedal to check that it returns smoothly to the original released position.
  3. Perform an electrical inspection of the accelerator pedal position sensor. Refer to «VIN REGISTRATION»(/nissan/titan/i-2007-2015/remont/testing-diagnostics/#engine-control-system) .
CAUTIONWhen the harness connector of the accelerator pedal position sensor is disconnected, perform "Accelerator Pedal Released Position Learning". Refer to " ACCELERATOR PEDAL RELEASED POSITION LEARNING ".

Scheme 2

Scheme 2: NON-ADJUSTABLE ACCELERATOR PEDAL ASSEMBLY
Scheme 2: NON-ADJUSTABLE ACCELERATOR PEDAL ASSEMBLY
CAUTIONDo not disassemble the accelerator pedal assembly. Do not remove the accelerator pedal position sensor from the accelerator pedal bracket. Avoid damage from dropping the accelerator pedal assembly during handling. Keep the accelerator pedal assembly away from water.
  1. Turn the ignition switch OFF and disconnect the negative battery terminal.
  2. Disconnect the accelerator position sensor electrical connector.
  3. Remove the two upper and one lower accelerator pedal nuts.
  4. Remove the adjustable accelerator pedal assembly.
CAUTIONDo not disassemble the accelerator pedal assembly. Do not remove the accelerator pedal position sensor from the accelerator pedal bracket. Avoid damage from dropping the accelerator pedal assembly during handling. Keep the accelerator pedal assembly away from water.

Installation is in the reverse order of removal.

Inspection After Installation

  1. Check that the accelerator pedal moves smoothly within the specified range.
  2. Depress and release the accelerator pedal to check that it returns smoothly to the original released position.
  3. Perform an electrical inspection of the accelerator pedal position sensor. Refer to «VIN REGISTRATION»(/nissan/titan/i-2007-2015/remont/testing-diagnostics/#engine-control-system) .
CAUTIONWhen the harness connector of the accelerator pedal position sensor is disconnected, perform "Accelerator Pedal Released Position Learning". Refer to " ACCELERATOR PEDAL RELEASED POSITION LEARNING ".
