CHECK OF CAN SYSTEM TYPE (HOW TO USE CAN SYSTEM TYPE SPECIFICATION CHART)
Determine CAN system type based on vehicle equipment. Then choose the correct diagnosis sheet.
Note. There are two styles for CAN system type specification charts. Depending on the number of available system types, either style A or style B may be used.
CAN System Type Specification Chart (Style A)
Note. CAN system type is easily checked with the vehicle equipment identification information shown in the illustration.
Scheme 1
CAN System Type Specification Chart (Style B)
Note. CAN system type is easily checked with the vehicle equipment identification information shown in the illustration.
Scheme 2
CAN System Specification Chart
Determine CAN system type from the following specification chart. Then choose the correct diagnosis sheet.
Note. Refer to " TROUBLE DIAGNOSIS PROCEDURE " for how to use CAN system specification chart.
| Body type | Truck | ||||||||
|---|---|---|---|---|---|---|---|---|---|
| Axle | 2WD | 4WD | |||||||
| Engine | VK56DE | ||||||||
| Transmission | A/T | ||||||||
| Brake control | VDC | ||||||||
| Electronic locking rear differential | X | X | X | ||||||
| Automatic drive positioner | X | X | X | X | X | X | |||
| Navigation system | X | X | X | ||||||
| CAN system type | 1 | 2 | 3 | 4 | 5 | 6 | 7 | 8 | 9 |
| Diagnosis sheet | DIAGNOSIS SHEET (CAN TYPE 1) | DIAGNOSIS SHEET (CAN TYPE 2) | DIAGNOSIS SHEET (CAN TYPE 3) | DIAGNOSIS SHEET (CAN TYPE 4) | DIAGNOSIS SHEET (CAN TYPE 5) | DIAGNOSIS SHEET (CAN TYPE 6) | DIAGNOSIS SHEET (CAN TYPE 7) | DIAGNOSIS SHEET (CAN TYPE 8) | DIAGNOSIS SHEET (CAN TYPE 9) |
| X: Applicable | |||||||||
CAN SYSTEM SPECIFICATION CHART
