INSPECTION AFTER INSTALLATION
- Check that the accelerator pedal moves smoothly within the specified ranges. Adjustable accelerator pedal-total pedal applied stroke : 48.3 mm (1.90 in) Adjustable accelerator pedal-total pedal adjustment travel: 73.2 mm (2.88 in)
- Depress and release the accelerator pedal to check that it returns smoothly to the original released position.
- Perform an electrical inspection of the accelerator pedal position sensor. Refer to «DTC P2138 APP SENSOR»(ref-169472-S22358144512004120900000) in ENGINE CONTROL SYSTEM - Titan article.
| CAUTION | When the harness connector of the accelerator pedal position sensor is disconnected, perform "Accelerator Pedal Released Position Learning" . Refer to ACCELERATOR PEDAL RELEASED POSITION LEARNING in BASIC DIAGNOSTIC PROCEDURES - TITAN article. |
Scheme 1029
Scheme 1029: NON-ADJUSTABLE ACCELERATOR PEDAL ASSEMBLY
| CAUTION | Do not disassemble the accelerator pedal assembly. Do not remove the accelerator pedal position sensor from the accelerator pedal bracket. Avoid damage from dropping the accelerator pedal assembly during handling. Keep the accelerator pedal assembly away from water. |
- Check that the accelerator pedal moves smoothly within the specified range. Non-adjustable accelerator pedal-total pedal applied stroke : 48 mm (1.89 in)
- Depress and release the accelerator pedal to check that it returns smoothly to the original released position.
- Perform an electrical inspection of the accelerator pedal position sensor. Refer to «DTC P2138 APP SENSOR»(ref-169472-S22358144512004120900000) in ENGINE CONTROL SYSTEM - Titan article.
| CAUTION | When the harness connector of the accelerator pedal position sensor is disconnected, perform "Accelerator Pedal Released Position Learning" . Refer to ACCELERATOR PEDAL RELEASED POSITION LEARNING in BASIC DIAGNOSTIC PROCEDURES - TITAN article. |
Scheme 1030
Scheme 1030: Accelerator Pedal Stroke And Travel
