Auto Light System: Overview Nissan Titan I

Scheme 59

System Description

Automatically turns on/off the parking lamps and the headlamps in accordance with ambient light.

Timing for when the lamps turn on/off can be selected using four modes.

CAN Communication System Description

Refer to CAN COMMUNICATION

CONSULT-II BASIC OPERATION

Locating Data Link Connector

Scheme 60

Scheme 61

Scheme 62

1. Touch "START (NISSAN BASED VHCL)".
2. Touch "BCM" on "SELECT SYSTEM" screen. If "BCM" is not indicated, go to «CONSULT-II DATA LINK CONNECTOR (PLC) CIRCUIT»(ref-215097-S07434654842006010900000) ".
3. Touch "HEADLAMP" on "SELECT TEST ITEM" screen.

Operation Procedure

1. Touch "HEADLAMP" on "SELECT TEST ITEM" screen.
2. Touch "WORK SUPPORT" on "SELECT DIAG MODE" screen.
3. Touch "CUSTOM A/LIGHT SETTING" or "ILL DELAY SET" on "SELECT WORK ITEM" screen.
4. Touch "START".
5. Touch "MODE 1 - 4" of setting to be changed (CUSTOM A/LIGHT SETTING), Touch "MODE 1-8" of setting to be changed. (ILL DELAY SET)
6. Touch "SETTING CHANGE".
7. The setting will be changed and "CUSTOMIZING COMPLETED" will be displayed.
8. Touch "END".

1. Touch "HEADLAMP" on "SELECT TEST ITEM" screen.
2. Touch "DATA MONITOR" on "SELECT DIAG MODE" screen.
3. Touch either "ALL SIGNALS" or "SELECTION FROM MENU" on the "DATA MONITOR" screen. DATA MONITOR SPECIFICATION All signals Monitors all the signals. Selection from menu Selects and monitors individual signal.
4. Touch "START".
5. When "SELECTION FROM MENU" is selected, touch individual items to be monitored. When "ALL SIGNALS" is selected, all the items will be monitored.
6. Touch "RECORD" while monitoring, then the status of the monitored item can be recorded. To stop recording, touch "STOP".

1. Touch "HEADLAMP" on "SELECT TEST ITEM" screen.
2. Touch "ACTIVE TEST" on "SELECT DIAG MODE" screen.
3. Touch item to be tested and check operation of the selected item.
4. During the operation check, touching "BACK" deactivates the operation.

1. Touch "BCM C/U" on "SELECT TEST ITEM" screen.
2. Touch "SELF-DIAG RESULTS" on "SELECT DIAG MODE" screen.
3. Self-diagnostic results are displayed.

CONSULT-II OPERATION

Scheme 63

Scheme 64

Scheme 65

Scheme 66

1. With the ignition switch OFF, connect CONSULT-II and CONSULT-II CONVERTER to the data link connector, then turn the ignition switch ON.
2. Touch "START (NISSAN BASED VHCL)".
3. Touch "IPDM E/R" on "SELECT SYSTEM" screen. If "IPDM E/R" is not displayed, refer to «CONSULT-II DATA LINK CONNECTOR (PLC) CIRCUIT»(ref-215097-S07434654842006010900000)
4. Select the desired part to be diagnosed on the "SELECT SYSTEM" screen.

1. Touch "DATA MONITOR" on "SELECT DIAG MODE" screen.
2. Touch "ALL SIGNALS", "MAIN SIGNALS" or "SELECT FROM MENU" on the "DATA MONITOR" screen. DATA MONITOR SPECIFICATION ALL SIGNALS All items will be monitored. MAIN SIGNALS Monitor the predetermined item. SELECT FROM MENU Select any item for monitoring.
3. Touch "START".
4. Touch the required monitoring item on "SELECT ITEM MENU". In "ALL SIGNALS", all items are monitored. In "MAIN SIGNALS", predetermined items are monitored.
5. Touch "RECORD" while monitoring to record the status of the item being monitored. To stop recording, touch "STOP".

1. Touch "ACTIVE TEST" on "SELECT DIAG MODE" screen.
2. Touch item to be tested, and check operation.
3. Touch "START".
4. Touch "STOP" while testing to stop the operation.

TEST ITEM SPECIFICATION
