CAN System (Type 9): Overview Nissan Titan I

System Description

CAN (Controller Area Network) is a serial communication line for real time application. It is an on-vehicle multiplex communication line with high data communication speed and excellent error detection ability. Many electronic control units are equipped onto a vehicle, and each control unit shares information and links with other control units during operation (not independent). In CAN communication, control units are connected with 2 communication lines (CAN H line, CAN L line) allowing a high rate of information transmission with less wiring. Each control unit transmits/receives data but selectively reads required data only.

Scheme 424

Scheme 425

Scheme 426

Scheme 427

Scheme 428

Scheme 429

Scheme 430

Scheme 431

1. When there are no indications of "AUTO DRIVE POS.", "BCM" or "IPDM E/R" on "SELECT SYSTEM" display of CONSULT-II, print the "SELECT SYSTEM".
2. Print all the data of "SELF-DIAG RESULTS" for "ENGINE", "AT", "AUTO DRIVE POS.", "BCM", "ALL MODE AWD/4WD", "ABS" and "IPDM E/R" displayed on CONSULT-II.
3. Print all the data of "DATA MONITOR (CAN DIAG SUPPORT MNTR)" for "ENGINE", "A/T" "AUTO DRIVE POS.", "BCM", "ALL MODE AWD/4WD", "ABS" and "IPDM E/R" displayed on CONSULT-II.
4. Attach the printed sheet of "SELECT SYSTEM", "SELF-DIAG RESULTS" and "DATA MONITOR (CAN DIAG SUPPORT MNTR)" onto the check sheet. Refer to , " «CHECK SHEET»(ref-215147-S18460366472006011000000) ".
5. Based on the indications of "SELECT SYSTEM" and the results of "DATA MONITOR (CAN DIAG SUPPORT MNTR)", put marks "v" onto the items with "No indication", "NG", or "UNKWN" in the check sheet table. Refer to , " «CHECK SHEET»(ref-215147-S18460366472006011000000) ",. NOTE: If "NG" is displayed on "CAN COMM" as "DATA MONITOR (CAN DIAG SUPPORT MNTR)" for the diagnosed control unit, replace the control unit. The "DATA MONITOR (CAN DIAG SUPPORT MNTR)" items, which are not in check sheet table, are not related to diagnostic procedure on service manual. So it is not necessary to check the status of the "DATA MONITOR (CAN DIAG SUPPORT MNTR)" items not in check sheet table.
6. Check CAN communication line of the navigation system. Refer to «CAN COMMUNICATION LINE CHECK»(ref-215156-S05431990092006011000000)
7. Attach the CAN DIAG SUPPORT MONITOR check sheet onto the check sheet. Refer to , " «CHECK SHEET»(ref-215147-S18460366472006011000000) ".
8. Mark the "NG" or "UNKWN" item of the check sheet table with "V" from the result of CAN DIAG SUPPORT MONITOR check sheet. Refer to . «CHECK SHEET»(ref-215147-S18460366472006011000000) . NOTE: If "NG" is displayed on "CAN COMM" as "CAN DIAG SUPPORT MONITOR" for the diagnosed control unit, replace the control unit. Refer to «CAN COMMUNICATION LINE CHECK»(ref-215156-S05431990092006011000000)
9. According to the check sheet results (example), start inspection. Refer to , " «CHECK SHEET RESULTS (EXAMPLE)»(ref-215147-S39171222042006011000000) ".
