DESCRIPTION & OPERATION
| CAUTION | When battery is disconnected, vehicle computer and memory systems may lose memory data. Driveability problems may exist until computer systems have completed a relearn cycle. See COMPUTER RELEARN PROCEDURES article in GENERAL INFORMATION before disconnecting battery. |
The outside mirror will only operate when the ignition switch is in the "ACC" or "ON" position.
Push the right or left end of the switch to select the right or left side mirror, then adjust using the control lever. (Scheme 1)
Scheme 1
COMPONENT LOCATIONS
| Component | Location |
|---|---|
| Body Ground M40 | Behind right side of dash, near glove box |
| Body Ground M120 | Left rear roof pillar, near rear window |
| Fuse/Relay Block | Under lower left side of dash. (Scheme 2) |
COMPONENT LOCATIONS
Locating Passenger Compartment Electrical Components. Scheme 2
Scheme 3
PRELIMINARY INSPECTION
Verify customer complaint by operating suspected system. Visually inspect for obvious signs of mechanical and electrical damage. Inspect for blown fuses. Inspect for loose or corroded connections, damaged wiring harnesses and/or switches. Check for a broken or partially broken wire inside insulation, which could cause system malfunction but prove good in a continuity/voltage check with system disconnected. Ensure any aftermarket electronic equipment is properly installed. If fault is found, repair as necessary.
COMPONENT TESTS
Component testing procedure is included in wiring diagram, see WIRING DIAGRAMS .
CONNECTOR IDENTIFICATION
For power mirror connector identification (Scheme 4)
Scheme 4
