Wheel Alignment Specifications & Procedures Nissan Stanza II

Wheel Alignment 5 illustrations ~247 words

SENTRA

Note. On Sentra, caster and kingpin inclination are preset at factory and cannot be adjusted.

If camber is not within specification, adjust by turning the adjusting pin (Scheme 1)

  1. Remove the adjusting pin. Adjusting pin is factory installed with the flat portion facing down.
  2. Install adjusting pin with the flat portion facing up.
  3. Turn the adjusting pin to adjust, Camber changes about 15' with each graduation of the adjusting pin. (Scheme 2)
  4. Tighten to the specified torque.

Adjusting Pin Location (Sentra). Scheme 1

Scheme 1: Adjusting Pin Location (Sentra)
Scheme 1: Adjusting Pin Location (Sentra)

Camber Adjusting Pin Graduations (Sentra). Scheme 2

Scheme 2: Camber Adjusting Pin Graduations (Sentra)
Scheme 2: Camber Adjusting Pin Graduations (Sentra)

Camber and Caster adjustments. To adjust caster, place shims from one side to the other. To adjust camber, move shims equally. Scheme 3

Scheme 3: Camber and Caster adjustments. To adjust caster, place shims from one side to the other. To adjust camber, move shims equally.
Scheme 3: Camber and Caster adjustments. To adjust caster, place shims from one side to the other. To adjust camber, move shims equally.

Toe adjustment (Except Pickup). To adjust, turn eccentric to desired setting. Scheme 4

Scheme 4: Toe adjustment (Except Pickup). To adjust, turn eccentric to desired setting.
Scheme 4: Toe adjustment (Except Pickup). To adjust, turn eccentric to desired setting.

TOE-IN ALIGNMENT (PICKUP)

Adjust toe-in by varying the lenght of the steering tie-rods. Adjust toe-in by turning the left and right tie-rod tubes an equal amount. Make sure the tie-rods are screwed into the tie-rod tube more than 1.38" (35 mm).

Once adjusted, make sure that the tie-rods are the same lenght. (Scheme 5)

Toe In Alignment Procedure (Pickup). Scheme 5

Scheme 5: Toe In Alignment Procedure (Pickup)
Scheme 5: Toe In Alignment Procedure (Pickup)
ApplicationSpecification
Front
Camber in Degrees
Fraction5/16 +/- 3/4
Decimal.31 +/- .75
Caster in Degrees
Fraction2 +/- 3/4
Decimal2.0 +/- .75
Toe-In in Inches
Fraction3/32 +/- 3/64
Decimal.09 +/- .05
Toe-In in Degrees
Fraction1/5 +/- 3/32
Decimal.20 +/- .09
Toe-Out in Turns
Inner35 1/2 +/- 1 1/2°
Outer29 +/- 2°
Steering Axis Inclination (SAI)(1)
Rear
Camber in Degrees
Fraction1/4 +/- 3/4
Decimal.25 +/- .75
Caster in Degrees
FractionN/A
DecimalN/A
Toe-In in Inches
FractionN/A
DecimalN/A
Toe-In in Degrees
FractionN/A
DecimalN/A
Toe-Out in Turns
InnerN/A
OuterN/A
Steering Axis Inclination (SAI)N/A
(1) Information not available.
(1)Information not available.

WHEEL ALIGNMENT SPECIFICATIONS (MAXIMA)

ApplicationSpecification
Rear
Camber in Degrees
Fraction7/16 +/- 3/4
Decimal.43 +/- .75
Caster in Degrees
FractionN/A
DecimalN/A
Toe-In in Inches
FractionN/A
DecimalN/A
Toe-In in Degrees
FractionN/A
DecimalN/A
Toe-Out in Turns
InnerN/A
OuterN/A
Steering Axis Inclination (SAI)N/A

WHEEL ALIGNMENT SPECIFICATIONS (MAXIMA WAGON)

ApplicationSpecification
Front
Camber in Degrees
Fraction7/13 +/- 1/2
Decimal.44 +/- .5
Caster in Degrees
Fraction11/62 +/- 1/2
Decimal.34 +/- .5
Toe-In in Inches
Fraction1/8 +/- 1/62
Decimal.13 +/- .03
Toe-In in Degrees
Fraction1/4 +/- 1/13
Decimal.25 +/- .13
Toe-Out in Turns
Inner22°
Outer20°
Steering Axis Inclination (SAI)7 15/16°

WHEEL ALIGNMENT SPECIFICATIONS (PICKUP - 2WD)

ApplicationSpecification
Front
Camber in Degrees
Fraction5/8 +/- 1/2
Decimal.63 +/- .5
Caster in Degrees
Fraction1 11/62 +/- 1/2
Decimal1.34 +/- .5
Toe-In in Inches
Fraction5/34 +/- 1/62
Decimal.08 +/- .03
Toe-In in Degrees
Fraction5/62 +/- 1/13
Decimal.16 +/- .06
Toe-Out in Turns
Inner22°
Outer20°
Steering Axis Inclination (SAI)6 3/4°

WHEEL ALIGNMENT SPECIFICATIONS (PICKUP - 4WD)

ApplicationSpecification
Front
Camber in Degrees
Fraction5/16 +/- 3/4
Decimal.313 +/- .75
Caster in Degrees
Fraction1 5/8 +/- 3/4
Decimal1.625 +/- .75
Toe-In in Inches
Fraction7/32 +/- 1/32
Decimal.22 +/- .03
Toe-In in Degrees
Fraction7/16 +/- 1/16
Decimal.44 +/- .06
Toe-Out in Turns
Inner20°
Outer17 1/2°
Steering Axis Inclination (SAI)12 3/4°
Rear
Camber in Degrees
FractionN/A
DecimalN/A
Caster in Degrees
FractionN/A
DecimalN/A
Toe-In in Inches
Fraction0 +/- 5/16
Decimal0.0 +/- .31
Toe-In in Degrees
Fraction0 +/- 5/8
Decimal0.0 +/- .63
Toe-Out in Turns
InnerN/A
OuterN/A
Steering Axis Inclination (SAI)N/A

WHEEL ALIGNMENT SPECIFICATIONS (PULSAR NX)

ApplicationSpecification
Front
Camber in Degrees
Fraction5/16 +/- 3/4
Decimal.31 +/- .75
Caster in Degrees
Fraction1 1/2 +/- 3/4
Decimal1.5 +/- .75
Toe-In in Inches
Fraction7/32 +/- 1/32
Decimal.22 +/- .03
Toe-In in Degrees
Fraction7/16 +/- 1/16
Decimal.44 +/- .06
Toe-Out in Turns
Inner20°
Outer17 1/2°
Steering Axis Inclination (SAI)12 3/4°
Rear
Camber in Degrees
Fraction1 +/- 3/4
Decimal1.0 +/- .75
Caster in Degrees
FractionN/A
DecimalN/A
Toe-In in Inches
Fraction0 +/- 5/16
Decimal0.0 +/- .31
Toe-In in Degrees
Fraction0 +/- 5/8
Decimal0.0 +/- .63
Toe-Out in Turns
InnerN/A
OuterN/A
Steering Axis Inclination (SAI)N/A

WHEEL ALIGNMENT SPECIFICATIONS (SENTRA)

ApplicationSpecification
Front
Camber in Degrees
Fraction5/16 +/- 3/4
Decimal.313 +/- .75
Caster in Degrees
Fraction1 7/16 +/- 3/4
Decimal1.43 +/- .75
Toe-In in Inches
Fraction1/16 +/- 1/32
Decimal.06 +/- .03
Toe-In in Degrees
Fraction1/8 +/- 1/16
Decimal.13 +/- .06
Toe-Out in Turns
Inner20°
Outer18 1/2°
Steering Axis Inclination (SAI)14 5/8°
Rear
Camber in Degrees
Fraction3/4 +/- 3/4
Decimal.75 +/- .75
Caster in Degrees
FractionN/A
DecimalN/A
Toe-In in Inches
FractionN/A
DecimalN/A
Toe-In in Degrees
FractionN/A
DecimalN/A
Toe-Out in Turns
InnerN/A
OuterN/A
Steering Axis Inclination (SAI)N/A

WHEEL ALIGNMENT SPECIFICATIONS (STANZA)

ApplicationSpecification
Front
Camber in Degrees
Fraction1/2 +/- 3/4
Decimal.5 +/- .75
Caster in Degrees
Fraction1 1/2 +/- 3/4
Decimal1.5 +/- .75
Toe-In in Inches
Fraction1/16 +/- 3/32
Decimal.06 +/- .09
Toe-In in Degrees
Fraction1/8 +/- 3/16
Decimal.13 +/- .19
Toe-Out in Turns
Inner21 1/2°
Outer20°
Steering Axis Inclination (SAI)11 1/4°

WHEEL ALIGNMENT SPECIFICATIONS (STANZA WAGON)

ApplicationSpecification
Front
Camber in Degrees
Fraction1/4 +/- 3/4
Decimal.25 +/- .75
Caster in Degrees
Fraction1 3/16 +/- 3/4
Decimal1.18 +/- .75
Toe-In in Inches
Fraction3/16 +/- 3/16
Decimal.19 +/- .19
Toe-In in Degrees
Fraction3/8 +/- 3/8
Decimal.13 +/- .13
Toe-Out in Turns
InnerN/A
OuterN/A
Steering Axis Inclination (SAI)N/A
Rear
Camber in Degrees
Fraction3/4 +/- 3/4
Decimal.75 +/- .75
Caster in Degrees
Fraction1 1/2 +/- 3/4
Decimal1.5 +/- .75
Toe-In in Inches
FractionN/A
DecimalN/A
Toe-In in Degrees
FractionN/A
DecimalN/A
Toe-Out in Turns
InnerN/A
OuterN/A
Steering Axis Inclination (SAI)N/A

WHEEL ALIGNMENT SPECIFICATIONS (STANZA WAGON - 4WD)

ApplicationSpecification
Front
Camber in Degrees
Fraction5/16 +/- 3/4
Decimal.31 +/- .75
Caster in Degrees
Fraction3 1/2 +/- 3/4
Decimal3.5 +/- .75
Toe-In in Inches
Fraction1/64 +/- 1/32
Decimal.02 +/- .03
Toe-In in Degrees
Fraction1/32 +/- 1/16
Decimal.03 +/- .06
Toe-Out in Turns
Inner20°
Outer18 3/4°
Steering Axis Inclination (SAI)11 15/16°
Rear
Camber in Degrees
Fraction1/2 +/- 3/4
Decimal.5 +/- .75
Caster in Degrees
FractionN/A
DecimalN/A
Toe-In in Inches
FractionN/A
DecimalN/A
Toe-In in Degrees
FractionN/A
DecimalN/A
Toe-Out in Turns
InnerN/A
OuterN/A
Steering Axis Inclination (SAI)N/A

WHEEL ALIGNMENT SPECIFICATIONS (200SX)

ApplicationSpecification
Front
Camber in Degrees
Fraction5/32 +/- 3/4
Decimal.15 +/- .75
Caster in Degrees
Fraction6 9/16 +/- 3/4
Decimal6.56 +/- .75
Toe-In in Inches
Fraction1/16 +/- 1/16
Decimal.06 +/- .06
Toe-In in Degrees
Fraction1/8 +/- 1/8
Decimal.13 +/- .13
Toe-Out in Turns
Inner22 1/2°
Outer20°
Steering Axis Inclination (SAI)13 11/32°
Rear (Scheme 4)
Camber in Degrees
Fraction1 5/32 +/- 3/4
Decimal1.16 +/- .75
Caster in Degrees
FractionN/A
DecimalN/A
Toe-In in Inches
FractionN/A
DecimalN/A
Toe-In in Degrees
FractionN/A
DecimalN/A
Toe-Out in Turns
InnerN/A
OuterN/A
Steering Axis Inclination (SAI)N/A
Rear
Camber in Degrees
Fraction1 +/- 3/4
Decimal1.0 +/- .75
Caster in Degrees
FractionN/A
DecimalN/A
Toe-In in Inches
FractionN/A
DecimalN/A
Toe-In in Degrees
FractionN/A
DecimalN/A
Toe-Out in Turns
InnerN/A
OuterN/A
Steering Axis Inclination (SAI)N/A

WHEEL ALIGNMENT SPECIFICATIONS (300ZX)
