BUZZERS, RELAYS & TIMERS
| Component | Location |
|---|---|
| A/C Condenser Fan Relay | On relay panel, on right front fender. (Scheme 5) |
| A/C Relay (2-Black) | On relay panel, on right front fender, and behind right kick panel. (Scheme 5)& (Scheme 6). |
| A/C Main Relay (Blue) | Under left side of dash, above fuse block. (Scheme 6) |
| Accessory Relay (Blue) | Under left side of dash, above fuse block. (Scheme 6) |
| ASCD Relay (Black) | On relay panel, on right front fender. (Scheme 5) |
| Auto. Trans. Inhibitor Relay (Gray) | On relay panel, on left front fender. (Scheme 5) |
| Bulb Check Relay (Black) | On left kick panel. (Scheme 6) |
| Cooling Fan Relay (Brown) | On relay panel, on left front fender. (Scheme 5)& (Scheme 7). |
| ECCS Relay (Black) | Under left side of dash, above fuse block. (Scheme 6) |
| Horn Relay (Black) | On relay panel, on right front fender. (Scheme 5) |
| Ignition Relay (Blue) | Under left side of dash, above fuse block. (Scheme 6) |
| Man. Trans. Start Relay (Blue) | On relay panel, on left front fender. (Scheme 5) |
| Protection/Safety Relay | On left kick panel. (Scheme 6) |
| Seat Belt & Light Warning Chime | Under right side of dash. (Scheme 6) |
| Sun Roof Relay (Black) | On relay panel, on left front fender. (Scheme 5) |
| Turn Signal/Hazard Flasher | Under left side of dash. (Scheme 6) |
| Vacuum Pump Relay (Black) | On relay panel, on right front fender. (Scheme 5) |
BUZZERS, RELAYS & TIMERS LOCATION
CIRCUIT PROTECTION DEVICES
| Component | Location |
|---|---|
| Circuit Breaker (Black) | On relay panel, on left front fender. (Scheme 5) |
| Fuse Block | Under left side of dash. (Scheme 6) |
| Fusible Links | On left front fender inner panel, near brake master cylinder. |
CIRCUIT PROTECTION DEVICES LOCATION
CONTROL UNITS
| Component | Location |
|---|---|
| ASCD Control Unit | Under center of dash, near steering column. (Scheme 6) |
| ECCS Control Unit | Under driver's seat. (Scheme 8) |
| Transfer Control Unit (4WD) | Under left side of dash, near steering column. (Scheme 6) |
CONTROL UNITS LOCATION
SENSORS & SENDING UNITS
| Component | Location |
|---|---|
| Airflow Meter | On left side of engine compartment. (Scheme 8) |
| Air Temperature Sensor | Under airflow meter. (Scheme 8) |
| Coolant Temperature Sensor | On intake manifold, below plenum chamber. (Scheme 8) |
| Crank Angle Sensor | In distributor. (Scheme 8) |
| Oil Pressure Sender | On rear side of engine block, near alternator. |
| Oxygen Sensor | In exhaust manifold. (Scheme 8) |
| Speed Sensor | In speedometer. |
SENSORS & SENDING UNITS LOCATION
MOTORS
| Component | Location | |
|---|---|---|
| A/C-Heater Blower Motor | Under right side of dash. | |
| Fuel Pump | ||
| 2WD | In fuel line, near fuel tank. (Scheme 8) | |
| 4WD | Under rear of vehicle, in fuel tank. (Scheme 8) | |
MOTORS LOCATION
SOLENOIDS & SOLENOID VALVES
| Component | Location |
|---|---|
| AIV Control Solenoid Valve | On engine valve cover. (Scheme 8) |
| EGR Control Solenoid Valve | On engine valve cover. (Scheme 8) |
| FICD Solenoid Valve | On right side of engine, on plenum chamber. (Scheme 6) |
| Pressure Regulator (PR) Control Solenoid Valve | On right side of engine, on plenum chamber. (Scheme 8) |
SOLENOIDS & SOLENOID VALVES LOCATION
SWITCHES
| Component | Location |
|---|---|
| A/C Switch | In center of dash. (Scheme 7) |
| A/C Dual Pressure Switch | On receiver-drier, near condenser. (Scheme 7) |
| A/C Thermo Switch | Under center of dash, on cooling unit. (Scheme 7) |
| Auto. Trans. Inhibitor Switch | On side of transaxle, linked to control cable. |
| Back-Up Light Switch (M/T) | On left side of transaxle. |
| Brake/Stoplight Switch | On brake pedal bracket. |
| Brake Switch (ASCD) | On brake pedal bracket. |
| Coolant Thermo Switch | In bottom radiator tank. (Scheme 7) |
| Clutch Switch | On clutch pedal bracket. |
| Parking Brake Switch | At rear of parking brake handle. |
SWITCHES LOCATION
MISCELLANEOUS
| Component | Location |
|---|---|
| A/C Resistor | Under center of dash, on cooling unit. (Scheme 7) |
| Air Regulator Valve | On right side of engine, on plenum chamber. (Scheme 8) |
| ASCD Actuator | On center of firewall. (Scheme 5) |
| Idle Air Adjustment (IAA) Unit | On right side of engine, on plenum chamber. (Scheme 8) |
| Intermittent Wiper Amplifier | On left side of firewall. (Scheme 5) |
MISCELLANEOUS LOCATION
COMPONENT LOCATION GRAPHICS
Note. Figures may show multiple component locations. Refer to appropriate table for proper figure references.
