Timer Control Modules Nissan Stanza II

Body, Cab Control Systems 2 illustrations ~1695 words

DESCRIPTION

Time Control Module, located in driver side kick panel, operates many systems in vehicle as follows

Intermittent Wiper Control

Regulates intermittent time from approximately 3 to 12 seconds depending on the intermittent wiper volume setting.

Washer & Wiper Combination Control

Wiper is operated in conjunction with washer switch.

Interior Lamp Timer

Fades out interior lamp when driver's side door is opened and closed.

Illumination Control

Regulates brightness of illumination in 16 stages depending on interior illumination control switch setting.

Door Key Hole Illumination

Illuminates for about 7 seconds when driver door outside handle is pulled.

Light Warning Chime Timer

When driver's door is opened with light switch on and ignition switch off, warning chime sounds.

Seat Belt Warning Lamp Timer

Seat belt warning lamp blinks for about 7 seconds when ignition switch in turned on.

Seat Belt Warning Chime Timer

Sounds warning chime for about 7 seconds if ignition switch is turned on when seat belt switch is on (seat belt unfastened).

Clock

Generates clock pulses and drives clock.

INPUT/OUTPUT SIGNAL TABLE. Scheme 1

Scheme 1: INPUT/OUTPUT SIGNAL TABLE
Scheme 1: INPUT/OUTPUT SIGNAL TABLE

PREPARATION

Remove driver's side dash cover. Remove time control unit from bracket with harness connected.

Note. For system schematic and terminal identification (Scheme 2)

Power Supply Circuit Check

  1. Connect ohmmeter from harness side. Check continuity between terminal 2 and ground. Continuity should exist.
  2. Connect voltmeter from harness side. Connect negative probe to terminal 2 of connector. Connect positive terminal of voltmeter to terminal 1. With ignition switch in OFF, ACC and ON, battery voltage should be present. If voltage is not as specified, check power supply circuits to time control unit.
  3. Connect negative probe to terminal 2 of connector. Connect positive terminal of voltmeter to terminal 20. With ignition switch in OFF and ACC, no voltage should be present. If ignition switch in ON, battery voltage should be present. If voltages are not as specified, check power supply circuits to time control unit.
  4. Connect negative probe to terminal 2 of connector. Connect positive terminal of voltmeter to terminal 26. With ignition switch in OFF, no voltage should be present. If ignition switch in ACC and ON, battery voltage should be present. If voltages are not as specified, check power supply circuits to time control unit.

INTERMITTENT WIPER DOES NOT OPERATE

  1. Perform POWER SUPPLY CIRCUIT CHECK under PRELIMINARY CHECK. Check TCU output for wiper relay circuit. Turn wiper switch to INT. Turn ignition switch to ACC. Measure voltage between terminals 15 and 2 of TCU harness connector. Voltage should vary between 12V and 0V every 3 to 12 seconds. If output is not as specified, go to step 2). If output is okay, check wiper relay operation. If relay is okay, check harness between TCU and wiper relay. If relay is not okay, replace relay.
  2. Check wiper switch circuit. Turn wiper switch to INT. Turn ignition switch to OFF. Measure voltage between terminals 12 and 2 of TCU harness connector. Voltage should be 0V with wiper switch in INT, and 12V with wiper switch OFF. If voltage is as specified, replace TCU. If voltage is not as specified, check harness between TCU and wiper switch. If harness is okay, replace wiper switch.

INTERMITTNET TIME OF WIPER CANNOT BE ADJUSTED

Check intermittent wiper volume circuit. Turn ignition switch OFF. Connect ohmmeter between terminals 16 and 2 of TCU harness connector. Resistance should be approximately 15 Ohms at "<<<" position and 1.8k Ohms at "<" position. If resistance is as specified, replace TCU. If resistance is not as specified, check harness between TCU and wiper volume switch. If harness is okay, replace wiper switch.

WIPER AND WASHER ACTIVATE INDIVIDUALLY BUT NOT TOGETHER

  1. Check washer switch circuit. Turn ignition switch to ACC or ON position. Connect voltmeter between terminals 14 and 2 of TCU harness connector. Pull washer switch ON. In wash position, voltage should be 0V. In neutral position, voltage should be 12V. If voltage is as specified, go to step 2). If voltage is not as specified, check harness between TCU and washer switch.
  2. Check TCU output to wiper motor. Connect voltmeter between terminals 15 and 2 of TCU harness connector. Pull washer switch ON. Voltage should be 0V for approximately 2.5 seconds after releasing switch, then return to 12V. If voltage is okay, replace wiper relay. If voltage is not okay, replace TCU.

INTERIOR LAMP DOES NOT FADE OUT AFTER DRIVER'S DOOR IS CLOSED

  1. Perform POWER SUPPLY CIRCUIT CHECK under PRELIMINARY CHECK. Check driver's door switch. Turn ignition switch OFF. Open driver's door. Connect a voltmeter between terminals 21 and 2 of TCU harness connector. When door is open, voltage should be 0V. When door is closed, voltage should be 12V. If voltage is as specified, go to step 2). If voltage is not as specified, check harness between TCU and driver's door switch and driver's door switch.
  2. Check TCU output for interior lamp circuit. Turn ignition OFF. Connect voltmeter between terminals 22 and 2 of TCU harness connector. Voltage should be 0V when door is open and rise from 0V to 12V once door is closed. If voltage is as specified, check harness between TCU and interior lamp. If voltage is not as specified, replace TCU.

ILLUMINATION CONTROL SYSTEM DOES NOT ACTUATE

  1. Check TCU output for light switch circuit. Turn ignition switch OFF and light switch ON. Connect voltmeter between terminals 9 and 2 of TCU harness connector. Voltage should be 12V. If voltage is as specified, go to step 2). If voltage is not as specified, check harness between TCU and light switch.
  2. Check illumination circuit. Turn ignition switch OFF and light switch OFF. Connect voltmeter between terminals 9 and 25 of TCU harness connector. Voltage should be 0V. If voltage is as specified, go to step 3). If voltage is not as specified, check for loose harness connector.
  3. Check illumination control circuit. With ignition switch OFF, connect ohmmeter between terminals 24 and 2 of TCU harness connector. With illumination control switch at DARK, resistance should be 0 Ohms. If illumination control switch at BRIGHT, resistance should not be 0 Ohms. Connect ohmmeter between terminals 23 and 2 of TCU harness connector. With illumination control switch at DARK, resistance should not be 0 Ohms. If illumination control switch at BRIGHT, resistance should be 0 Ohms. If resistance is as specified, replace TCU. If resistance is not as specified, check illumination control switch.

DOOR KEY HOLE ILLUMINATION DOES NOT COME ON.

  1. Perform POWER SUPPLY CIRCUIT CHECK under PRELIMINARY CHECK. Check key hole illumination circuit. Turn ignition OFF. Pull outside driver's door handle. Connect voltmeter between terminals 11 and 2 of TCU harness connector. Voltmeter should read 6.2V for approximately 7 seconds after door is pulled, then read 9.4V. If voltage is not as specified, go to step 2). If voltage is as specifed, check key hole illumination and diode. If okay, check harness between TCU and key hole illumination.
  2. Check door handle switch circuit. Turn ignition switch OFF. Connect voltmeter between terminals 8 and 2 of TCU harness connector. Pull driver's side outside door handle. Voltage should be 0V immediately after driver's door handle is released, then rise to 12V. If voltage is as specified, replace TCU. If voltage is not as specified, check door handle switch and harness between TCU and door handle switch.

LIGHT WARNING CHIME DOES NOT ACTIVATE

  1. Check if other warning chimes operate. If other chimes operate, go to step 3). If other chimes do not operate, perform POWER SUPPLY CIRCUIT CHECK under PRELIMINARY CHECK.
  2. Check TCU output to chime circuit. Turn ignition switch OFF. Connect voltmeter between terminals 10 and 2 of TCU harness connector. Voltage should be approximately 12V with driver's door closed, and swing from 0V to 12V when driver's door is opened. If voltage is not as specified, go to step 3). If voltage is as specified, check chime and harness between TCU and chime.
  3. Check TCU output for light switch circuit. Turn ignition switch OFF and light switch ON. Connect voltmeter between terminals 9 and 2 of TCU harness connector. Voltage should be 12V. If voltage is as specified, replace TCU. If voltage is not as specified, check harness between TCU and light switch.

SEAT BELT WARNING CHIME DOES NOT ACTIVATE

  1. Check if other warning chimes operate. If other chimes operate, go to step 3). If other chimes do not operate, perform POWER SUPPLY CIRCUIT CHECK under PRELIMINARY CHECK.
  2. Check TCU output to chime circuit. Turn ignition switch OFF. Connect voltmeter between terminals 10 and 2 of TCU harness connector. Voltage should be approximately 12V with driver's door closed, and swing from 0V to 12V when driver's door is opened. If voltage is not as specified, go to step 3). If voltage is as specified, check chime and harness between TCU and chime.
  3. Check seat belt switch circuit. Turn ignition switch OFF. Unfasten driver's seat belt. Connect ohmmeter between terminals 17 and 2 of TCU harness connector. Resistance should be 0 Ohms. Fasten driver's seat belt. Continuity should exist. If resistance is as specified, replace TCU. If resistance is not as specified, check harness between TCU and seat belt switch.

SEAT BELT WARNING LAMP DOES NOT GO OFF OR COME ON

Perform POWER SUPPLY CIRCUIT CHECK under PRELIMINARY CHECK. Check TCU output for belt warning lamp circuit. Unfasten seat belt. Connect voltmeter between terminals 19 and 2 of TCU harness connector. Voltmeter should swing from 0V to 12V for about 7 seconds after ignition switch is turned ON. If voltage is as specified, check warning lamp and harness between TCU and warning lamp. If voltage is not as specified, replace TCU.

CLOCK DOES NOT ACTIVATE

Perform POWER SUPPLY CIRCUIT CHECK under PRELIMINARY CHECK. Check TCU output for clock circuit. For analog clock equipped equipped models, connect voltmeter between terminals 5 and 4 of TCU harness connector. When ignition switch is turned OFF, voltage should swing from 0V to 12V. For digital clock equipped models, connect voltmeter between terminals 2 and 4 of TCU harness connector. When ignition switch is turned OFF, voltage should be 6V. If voltage is not as specified, replace TCU. If voltage is as specified, check clock, and harness between TCU and clock.

Scheme 2

Scheme 2: WIRING DIAGRAM
