Lighting System: Adjustments Nissan Sentra B16 рестайлинг

Aiming Adjustment

The headlamp for Canada is the same as the headlamp for USA. Refer to " AIMING ADJUSTMENT ".

The front fog lamp is a semi-sealed beam type which uses a replaceable halogen bulb. Before performing aiming adjustment, make sure of the following.

1. Keep all tires inflated to correct pressure.
2. Place vehicle on level surface.
3. Set that there is no-load in vehicle other than the driver (or equivalent weight placed in driver's position).

Coolant, engine oil filled up to correct level and full fuel tank.

Adjust aiming in the vertical direction by turning the adjusting screw (A).

Scheme 30

Scheme 31

1. Set the distance (D) between the screen and the center of front fog lamp lens as shown in illustration.
2. Turn front fog lamps to ON.
3. Adjust front fog lamps using adjusting screw so that the top edge of the high intensity zone (C) is as shown in illustration. FRONT FOG LAMPS SPECIFICATIONS Vertical distance from horizontal/vertical center point of fog lamp on screen to top edge of high intensity zone (A) 100 mm (4 in) Horizontal/vertical center point of fog lamp (B) Fog lamp high intensity zone (C) Distance from fog lamp to screen (D) 7.62 mm (25 ft) NOTE: When performing adjustment, if necessary, cover the headlamps and opposite front fog lamp.

Scheme 32

1. Turn lighting switch OFF.
2. Position back the front fender protector. Refer to " «REMOVAL AND INSTALLATION»(ref-367309-S17675621432010072700000) ".
3. Disconnect front fog lamp connector (1).
4. Turn bulb socket (2) counterclockwise unlock and remove it.
5. Remove bulb from its socket.

Scheme 33

1. Remove the fender protector. Refer to «REMOVAL AND INSTALLATION»(ref-367309-S17675621432010072700000) .
2. Disconnect the front fog lamp connector (3) from the fog lamp bulb (1).
3. Remove the front fog lamp screws (A) and remove the front fog lamp (2). As necessary, remove the two staples attaching the base of the fog lamp (2) and discard the staples.
