Parts Requiring Angle Tightening
- Use the Tool for the final tightening of the following engine parts: Tool number: KV10112100 (BT-8653-A) Camshaft sprocket (INT) bolt Cylinder head bolts Main bearing cap bolts Connecting rod cap bolts Crankshaft pulley bolt (The angle wrench is not required as bolt flange is provided with notches for angle tightening)
- Do not use a torque value for final tightening.
- Ensure thread and seat surfaces are clean and coated with engine oil.
GENERAL SPECIFICATIONS
| Cylinder arrangement | In-line 4 | |
|---|---|---|
| Displacement | Cm 3 (cu in) | 2, 488 (151.82) |
| Bore and stroke | Mm (in) | 89.0 x 100.0 (3.504 x 3.940) |
| Valve arrangement | DOHC | |
| Firing order | 1-3-4-2 | |
| Number of piston rings | Compression | 2 |
| Oil | 1 | |
| Compression ratio | 9.6 | |
| Compression pressure kPa (kg/cm 2 , psi)/250 RPM | Standard | 1, 412 (14.4, 204.7) |
| Minimum | 1, 216 (12.4, 176.3) | |
| Differential limit between cylinders | 100 (1.0, 14.5) | |
Unit: degree Valve timing <==: Intake valve <==: Exhaust valve a b c d e f Except for California 220 232 12 (-28) ATDC 64 (24) ABDC 10 30 For California 224 236 8 (-32) ATDC 64 (24) ABDC 8 36 (): Valve timing control "ON"
