Fail Safe Nissan Rogue I facelift

Security Control System 4 illustrations

Fail Safe

Display contents of CONSULT-IIIFail-safeCancellation
B2013: STRG COMM 1Inhibits steering look unlockingErase DTC
B2552: INTELLIGENT KEYInhibits steering look unlocking Inhibits engine cranking (BCM) Fuel cut (ECM)Erase DTC
B2590: NATS MALFUNCTIONInhibits steering look unlocking Inhibits engine cranking (BCM) Fuel cut (ECM)Erase DTC

FAIL SAFE CHART

Terminal No. (Wire color)DescriptionConditionValue (Approx.)
+Signal nameInput/Output
1 (R)GroundBattery power supplyInputIgnition switch OFFBattery voltage
2 (G)GroundBattery power supplyInputIgnition switch OFFBattery voltage
3 (O)GroundStarter relay power supplyOutputWhen engine is clankingBattery voltage
When engine is not clanking0 V
4 (W)GroundCooling fan relay-1 power supplyOutputCooling fan operationOFF0 V
MID or HIBattery voltage
5 (R)GroundIgnition switch STARTInputIgnition switch OFF, ACC or ON0 V
Ignition switch STARTBattery voltage
6 (BR)GroundBattery power supply (Cooling fan relay)InputIgnition switch OFFBattery voltage
7 (P)GroundCooling fan motor-2 (HI) groundCooling fan operationOFFBattery voltage
HI0 V
8 (G)GroundCooling fan relay-2 power supplyOutputCooling fan operationOFF0 V
HIBattery voltage
11 (B)GroundGroundIgnition switch ON0 V
12 (O)GroundRear window defogger relay power supplyOutputIgnition switch ONRear window defogger switch OFF0 V
Rear window defogger switch ONBattery voltage
15 (1) (SB)GroundDaytime running light relay controlOutputDaytime running light systemNot operatedBattery voltage
Operated0 V
16 (2) (Y)GroundFront fog lamp (LH)OutputLighting switch 2NDFront fog lamp switch OFF0 V
Front fog lamp switch ONBattery voltage
17 (2) (W)GroundFront fog lamp (RH)OutputLighting switch 2NDFront fog lamp switch OFF0 V
Front fog lamp switch ONBattery voltage
18 (L)GroundHeadlamp LO (LH)OutputLighting switch OFF0 V
Lighting switch 2NDBattery voltage
20 (SB)GroundHeadlamp LO (RH)OutputLighting switch OFF0 V
Lighting switch 2NDBattery voltage
21 (G)GroundHeadlamp HI (LH)OutputLighting switch OFF0 V
Lighting switch 2ND and HI Lighting switch PASSBattery voltage
Daytime running light system Operated (1)7.0 V
22 (LG)GroundHeadlamp HI (RH)OutputLighting switch OFF0 V
Lighting switch 2ND and HI Lighting switch PASSBattery voltage
Daytime running light system Operated (1)7.0 V
23 (W)GroundOil pressure switchInputIgnition switch ONEngine stopped0 V
Engine runningBattery voltage
24 (Y)GroundFront wiper auto stopInputIgnition switch ONFront wiper stop position0 V
Any position other than front wiper stop positionBattery voltage
25 (B)GroundGroundIgnition switch ON0 V
26 (P)CAN-LInput/Output
27 (L)CAN-HInput/Output
31 (LG)GroundCooling fan relay-4 controlOutputCooling fan operationOFFBattery voltage
LO0 - 1.0 V
32 (V)GroundThrottle control motor relay controlInputAfter passing approximately 2 seconds or more after turning the ignition switch from ON to OFFBattery voltage
Ignition switch ON For approximately 2 seconds after turning ignition switch from ON to OFF0 - 1.0 V
33 (GR)GroundFuel pump relay controlInputIgnition switch OFF0 V
Ignition switch ONEngine stoppedBattery voltage
Engine running0.8 V
34 (3) (W)GroundHood switchInputClose the hoodBattery voltage
Open the hood0 V
37 (R)GroundTail, license plate lamps and illuminationsOutputLighting switch OFF0 V
Lighting switch 1STBattery voltage
38 (R)GroundParking lamp (LH)OutputLighting switch OFF0 V
Lighting switch 1STBattery voltage
39 (GR)GroundParking lamp (RH)OutputLighting switch OFF0 V
Lighting switch 1STBattery voltage
40 (BR)GroundIgnition relay power supplyOutputIgnition switch OFF or ACC0 V
Ignition switch ONBattery voltage
41 (O)GroundIgnition relay power supplyOutputIgnition switch OFF or ACC0 V
Ignition switch ONBattery voltage
42 (L)GroundFront wiper HIOutputIgnition switch ONFront wiper switch OFF0 V
Front wiper switch HIBattery voltage
43 (G)GroundFront wiper LOOutputIgnition switch ONFront wiper switch OFF0 V
Front wiper switch LOBattery voltage
45 (Y)GroundStarter relay power supplyInputIgnition switch ONSelector lever "P" or "N"Battery voltage
Selector lever in any position other than "P" or "N"0 V
46 (W)GroundFuel pump relay power supplyOutputIgnition switch OFF or ACC After passing approximately 1 second or more after turning the ignition switch ON0 V
For approximately 1 second after turning the ignition switch ON Engine runningBattery voltage
47 (BR)GroundECM relay power supplyOutputAfter passing approximately 4 seconds or more after turning the ignition switch from ON to OFF0 V
Ignition switch ON For approximately 4 seconds after turning ignition switch from ON to OFFBattery voltage
48 (R)GroundECM relay power supplyOutputAfter passing approximately 4 seconds or more after turning the ignition switch from ON to OFF0 V
Ignition switch ON For approximately 4 seconds after turning ignition switch from ON to OFFBattery voltage
50 (G)GroundCooling fan relay-5 controlOutputCooling fan operationOFFBattery voltage
MID or HI0 - 1.0 V
51 (L)GroundECM relay controlOutputAfter passing approximately 4 seconds or more after turning the ignition switch from ON to OFFBattery voltage
Ignition switch ON For approximately 4 seconds after turning ignition switch from ON to OFF0 - 1.0 V
52 (P)GroundThrottle control motor relay power supplyOutputAfter passing approximately 2 seconds or more after turning the ignition switch from ON to OFF0 V
Ignition switch ON For approximately 2 seconds after turning ignition switch from ON to OFFBattery voltage
55 (O)GroundA/C relay power supplyOutputEngine stopped0 V
Engine runningA/C switch OFF0 V
A/C switch ON (A/C compressor is operating)Battery voltage
56 (SB)GroundIgnition switch ONInputIgnition switch OFF or ACC0 V
Ignition switch ONBattery voltage
57 (V)GroundHorn relay controlOutputThe horn is not activatedBattery voltage
The horn is activated0 V
58 (LG)GroundIgnition relay power supplyOutputIgnition switch OFF or ACC0 V
Ignition switch ONBattery voltage
59 (BR)GroundIgnition relay power supplyOutputIgnition switch OFF or ACC0 V
Ignition switch ONBattery voltage
60 (SB)GroundIgnition relay power supplyOutputIgnition switch OFF or ACC0 V
Ignition switch ONBattery voltage
61 (R)GroundECM power supplyOutputIgnition switch OFFBattery voltage
(1) With daytime running light system (2) With front fog lamp system (3) For Mexico
(1)With daytime running light system
(2)With front fog lamp system
(3)For Mexico

IPDM E/R (INTELLIGENT POWER DISTRIBUTION MODULE ENGINE ROOM) CONNECTOR TERMINALS REFERENCE CHART

Scheme 95

Scheme 95: Wiring Diagram - IPDM E/R
Scheme 95: Wiring Diagram - IPDM E/R

Scheme 96

Scheme 96
Scheme 96

Scheme 97

Scheme 97
Scheme 97

Scheme 98

Scheme 98
Scheme 98
