Scheme 37
DESCRIPTION
With ignition switch except in ON or START position, driver door open, and lighting switch in 1ST or 2ND position, the light reminder warning chime will sound.
- BCM detects ignition switch except in ON or START position, front door switch (driver side) ON, and lighting switch in 1ST or 2ND position. And then transmits buzzer output signal (light reminder warning chime) to combination meter with CAN communication line.
- When combination meter receives buzzer output signal (light reminder warning chime), it sounds the buzzer.
WARNING OPERATION CONDITIONS
If all of the following conditions are fulfilled.
- Lighting switch at 1ST or 2ND position
- Ignition switch except at ON or START
- Front door switch (driver side) ON
LIGHT REMINDER WARNING CHIME : Component Description
| Unit | Description |
|---|---|
| Combination meter | Receives a buzzer output signal from the BCM and sounds the buzzer. |
| BCM | Judges light reminder warning according to the front door switch (driver side) signal from the front door switch (driver side) and the lighting position signal from the combination switch (lighting switch) and transmits the buzzer output signal to the combination meter via CAN communication. |
| Combination switch (Lighting switch) | Transmits the lighting switch position signal to BCM. |
| Front door switch (driver side) | Transmits the front door switch (driver side) signal to BCM. |
LIGHT REMINDER WARNING CHIME DESCRIPTION CHART
Scheme 38
With ignition switch turned ON and driver seat belt unfastened, seat belt warning chime will sound for approximately 6 seconds.
- BCM receives seat belt buckle switch signal from combination meter with CAN communication line.
- BCM detects ignition switch turned ON and seat belt buckle switch (driver side) ON. And then transmits buzzer output signal (seat belt warning chime) to combination meter with CAN communication line.
- When combination meter receives buzzer output signal (seat belt warning chime), it sounds the buzzer.
If all of the following conditions are fulfilled.
- Ignition switch OFF-->ON
- Seat belt buckle switch (driver side) is ON (driver seat belt not fastened)
SEAT BELT REMINDER WARNING CHIME : Component Description
| Unit | Description |
|---|---|
| Combination meter | Receives a buzzer output signal from the BCM and sounds the buzzer. |
| BCM | Judges the seat belt warning condition from the seat belt buckle switch (driver side) signal received from the combination meter and transmits a buzzer output signal to the combination meter via CAN communication line if necessary. |
| Seat belt buckle switch (driver side) | Refer to " DESCRIPTION ". |
SEAT BELT REMINDER WARNING CHIME DESCRIPTION CHART
Scheme 39
Parking brake release warning chime judges the remaining parking brake according to the vehicle speed signal received from the ABS actuator and electric unit (control unit) via CAN communication and the parking brake switch signal from parking brake switch to sound the warning buzzer.
IF all of the following conditions are fulfilled.
- Vehicle speed is 7 km/h (4.3 MPH) or more
- Parking brake switch ON
PARKING BRAKE RELEASE WARNING CHIME : Component Description
| Unit | Description |
|---|---|
| Combination meter | Judges the remaining parking brake according to the vehicle speed signal received from the ABS actuator and electric unit (control unit) via CAN communication and the parking brake switch signal from parking brake switch and sounds the warning buzzer. |
| ABS actuator and electric unit (control unit) | Transmits the vehicle speed signal to the combination meter via CAN communication. |
| Parking brake switch | Refer to " DESCRIPTION ". |
PARKING BRAKE RELEASE WARNING CHIME DESCRIPTION CHART
Scheme 40
With the key inserted into the ignition key cylinder, and the ignition switch except in ON or START position, when driver door open, the key warning chime will sound.
- BCM detects key inserted into the ignition key cylinder, ignition switch except in ON or START position, front door switch (driver side) ON. And then transmits buzzer output signal (Key warning chime) to combination meter with CAN communication line.
- When combination meter receives buzzer output signal (Key warning chime), it sounds the buzzer.
Note. With Intelligent Key system: refer to " KEY REMINDER FUNCTION : SYSTEM DESCRIPTION ".
If all of the following conditions are fulfilled.
- Key inserted into the ignition key cylinder (Key switch signal ON)
- Ignition switch except in ON or START (Ignition switch signal OFF)
- Front door switch (driver side) open [Front door switch (driver side) signal ON]
KEY WARNING CHIME : Component Description
| Unit | Description |
|---|---|
| Combination meter | Received a buzzer output signal from the BCM and sounds the buzzer. |
| BCM | Judges key warning according to the door switch signal from the front door switch (driver side) and the key switch signal from the key switch and transmits the buzzer output signal to the combination meter via CAN communication. |
| Front door switch (driver side) | Transmits the door switch signal to BCM. |
| Key switch | Transmits the key switch signal to BCM and Intelligent Key unit. |
KEY WARNING CHIME DESCRIPTION CHART
- The buzzer for warning chime system is installed in the combination meter.
- The combination meter sounds the alarm buzzer based on the signals transmitted from various units.
Transmits a seat belt buckle switch signal to the combination meter.
Transmits the parking brake switch signal to the combination meter.
The light reminder warning chime does not sound under the following conditions.
- Lighting switch 1ST or 2ND position
- Driver door open
- Ignition switch except ON or START
Seat belt reminder warning chime does not sound.
The parking brake warning chime does not sound at all even though driving the vehicle with the parking brake applied.
The key warning chime does not sound under the following conditions.
- Key inserted into the ignition key cylinder (Key switch signal ON)
- Ignition switch except in ON or START (Ignition switch signal OFF)
- Front door switch (driver side) open. [Front door switch (driver side) signal ON]
