BCM : Diagnosis Procedure
- CHECK FUSE AND FUSIBLE LINK Turn ignition switch OFF. Check that the following fuse and fusible link are not blown. FUSE REFERENCE CHART Terminal No. Signal name Fuse and fusible link No. 38 Ignition power supply 1 (10A) 57 Battery power supply 10 (10A) 70 J (50A) Is the fuse fusing? YES: Replace the blown fuse or fusible link after repairing the affected circuit if a fuse or fusible link is blown. NO: GO TO 2.
- CHECK POWER SUPPLY CIRCUIT Disconnect BCM connectors. Check voltage between BCM harness connector and ground. VOLTAGE SPECIFICATION CHART (+) (-) Condition Voltage (Approx.) BCM Connector Terminal M65 38 Ground Ignition switch ON Battery voltage M67 57 Ignition switch OFF 70 Is the inspection result normal? YES: GO TO 3. NO: Repair or replace harness or connector.
- CHECK GROUND CIRCUIT Check continuity between BCM harness connector and ground. CONTINUITY REFERENCE CHART BCM Ground Continuity Connector Terminal M67 67 Existed Is the inspection result normal? YES: INSPECTION END NO: Repair or replace harness or connector.
POWER WINDOW MAIN SWITCH : Diagnosis Procedure
- CHECK POWER SUPPLY CIRCUIT Turn ignition OFF. Disconnect power window main switch connector. Turn ignition switch ON. Check voltage between power window main switch harness connector and ground. VOLTAGE SPECIFICATION CHART (+) (-) Voltage (V) (Approx.) Power window main switch Connector Terminal D5 10 Ground Battery voltage D6 19 (1) (1) With ANTI-PINCH SYSTEM Is the inspection result normal? YES: GO TO 2. NO: GO TO 3 .
- CHECK GROUND CIRCUIT Turn ignition switch OFF. Check continuity between power window main switch harness connector and ground. CONTINUITY REFERENCE CHART Power window main switch Ground Continuity Connector Terminal D6 17 Existed Is the inspection result normal? YES: INSPECTION END NO: Repair or replace harness.
- CHECK HARNESS CONTINUITY Turn ignition switch OFF. Disconnect BCM connector. Check continuity between BCM harness connector and power window main switch harness connector. CONTINUITY REFERENCE CHART BCM Power window main switch Continuity Connector Terminal Connector Terminal M67 68 D5 10 Existed 69 (1) D6 19 (1) (1) With ANTI-PINCH SYSTEM Check continuity between BCM harness connector and ground. CONTINUITY REFERENCE CHART BCM Ground Continuity Connector Terminal M67 68 Not existed 69 (1) (1) With ANTI-PINCH SYSTEM Is the inspection result normal? YES: Replace BCM. Refer to " «REMOVAL AND INSTALLATION»(ref-295115-S20712126632008081400000) ". NO: Repair or replace harness.
FRONT POWER WINDOW SWITCH (PASSENGER SIDE) : Diagnosis Procedure
- CHECK POWER SUPPLY CIRCUIT Turn ignition switch OFF. Disconnect front power window switch (passenger side) connector. Turn ignition switch ON. Check voltage between front power window switch (passenger side) harness connector and ground. VOLTAGE SPECIFICATION CHART (+) (-) Condition Voltage (V) (Approx.) Front power window switch (passenger side) Connector Terminal D45 8 Ground Ignition switch ON Battery voltage Is the inspection result normal? YES: INSPECTION END NO: GO TO 2.
- CHECK HARNESS CONTINUITY Turn ignition switch OFF. Disconnect BCM connector. Check continuity between BCM harness connector and front power window switch (passenger side) harness connector. CONTINUITY REFERENCE CHART BCM Front power window switch (passenger side) Continuity Connector Terminal Connector Terminal M67 68 D45 8 Existed Check continuity between BCM harness connector and ground. CONTINUITY REFERENCE CHART BCM Ground Continuity Connector Terminal M67 68 Not existed Is the inspection result normal? YES: Replace BCM. Refer to " «REMOVAL AND INSTALLATION»(ref-295115-S20712126632008081400000) ". NO: Repair or replace harness.
REAR POWER WINDOW SWITCH : Diagnosis Procedure
- CHECK POWER SUPPLY CIRCUIT Turn ignition switch OFF. Disconnect rear power window switch connector. Turn ignition switch ON. Check voltage between rear power window switch harness connector and ground. VOLTAGE SPECIFICATION CHART (+) (-) Condition Voltage (V) (Approx.) Rear power window switch Connector Terminal LH D83 1 Ground Ignition switch ON Battery voltage RH D103 Is the inspection result normal? YES: INSPECTION END NO: GO TO 2.
- CHECK HARNESS CONTINUITY Turn ignition switch OFF. Disconnect BCM connector. Check continuity between BCM harness connector and rear power window switch harness connector. CONTINUITY REFERENCE CHART BCM Rear power window switch Continuity Connector Terminal Connector Terminal M67 68 LH D83 1 Existed RH D103 Check continuity between BCM harness connector and ground. CONTINUITY REFERENCE CHART BCM Ground Continuity Connector Terminal M67 68 Not existed Is the inspection result normal? YES: Replace BCM. Refer to " «REMOVAL AND INSTALLATION»(ref-295115-S20712126632008081400000) ". NO: Repair or replace harness.
Diagnosis Procedure
- CHECK FRONT POWER WINDOW SWITCH (PASSENGER SIDE) INPUT SIGNAL Turn ignition switch OFF. Disconnect front power window switch (passenger side) connector. Turn ignition switch ON. Check voltage between front power window switch (passenger side) harness connector and ground. CONTINUITY REFERENCE CHART (+) (-) Condition Voltage (V) (Approx.) Front power window switch (passenger side) Connector Terminal D45 12 Ground Power window main switch (passenger side) UP Battery voltage DOWN 0 11 UP 0 DOWN Battery voltage Is the inspection result normal? YES: GO TO 2. NO: GO TO 3 .
- CHECK FRONT POWER WINDOW SWITCH (PASSENGER SIDE) Check front power window switch (passenger side). Refer to " «COMPONENT INSPECTION»(ref-295094-S18814942832008081400000) ". Is the inspection result normal? YES: GO TO 4 . NO: Replace front power window switch (passenger side). Refer to " «REMOVAL AND INSTALLATION»(ref-295094-S03184635162008081400000) ".
- CHECK FRONT WINDOW SWITCH (PASSENGER SIDE) CIRCUIT Turn ignition switch OFF. Disconnect power window main switch connector. Check continuity between power window main switch harness connector and front power window switch (passenger side) harness connector. CONTINUITY REFERENCE CHART Power window main switch Front power window switch (passenger side) Continuity Connector Terminal Connector Terminal D5 16 D45 12 Existed 12 11 Check continuity between power window main switch harness connector and ground. CONTINUITY REFERENCE CHART Power window main switch Ground Continuity Connector Terminal D5 16 Not existed 12 Is the inspection result normal? YES: Replace power window main switch. NO: Repair or replace harness.
- CHECK INTERMITTENT INCIDENT Refer to " «INTERMITTENT INCIDENT»(ref-295085-S23576844552008081400000) ". INSPECTION END
Component Inspection
- CHECK FRONT POWER WINDOW SWITCH (PASSENGER SIDE) Turn ignition OFF. Disconnect front power window switch (passenger side) connector. Check front power window switch (passenger side). CONTINUITY REFERENCE CHART Front power window switch (passenger side) Terminal Front power window switch condition Continuity D45 8 7 UP Existed 11 6 11 6 NEUTRAL 12 7 8 6 DOWN 12 7 Is the inspection result normal? YES: INSPECTION END NO: Replace front power window switch (passenger side). Refer to " «REMOVAL AND INSTALLATION»(ref-295094-S03184635162008081400000) ".
- CHECK REAR POWER WINDOW SWITCH INPUT SIGNAL Turn ignition switch OFF. Disconnect rear power window switch connector. Turn ignition switch ON. Check voltage between rear power window switch harness connector and ground. VOLTAGE SPECIFICATION CHART (+) (-) Condition Voltage (V) (Approx.) Rear power window switch Connector Terminal LH: D83 2 Ground Power window main switch: LH UP Battery voltage DOWN 0 3 UP 0 DOWN Battery voltage RH: D103 2 Power window main switch: RH UP Battery voltage DOWN 0 3 UP 0 DOWN Battery voltage Is the inspection result normal? YES: GO TO 2. NO: GO TO 3 .
- CHECK REAR POWER WINDOW SWITCH Check rear power window switch. Refer to " «COMPONENT INSPECTION»(ref-295094-S40155396402008081400000) ". Is the inspection result normal? YES: GO TO 4 . NO: Replace rear power window switch. Refer to " «REMOVAL AND INSTALLATION»(ref-295094-S03184635162008081400000) ".
- CHECK REAR POWER WINDOW SWITCH CIRCUIT Turn ignition switch OFF. Disconnect power window main switch connector. Check continuity between power window main switch harness connector and rear power window switch harness connector. CONTINUITY REFERENCE CHART Power window main switch Rear power window switch Continuity Connector Terminal Connector Terminal D5 1 LH D83 2 Existed 3 3 5 RH D103 3 7 2 Check continuity between power window main switch harness connector and ground. CONTINUITY REFERENCE CHART Power window main switch Ground Continuity Connector Terminal D5 1 Not existed 3 5 7 Is the inspection result normal? YES: Replace power window main switch. Refer to " «REMOVAL AND INSTALLATION»(ref-295094-S03184635162008081400000) ". NO: Repair or replace harness.
- CHECK INTERMITTENT INCIDENT Refer to " «INTERMITTENT INCIDENT»(ref-295085-S23576844552008081400000) ". INSPECTION END
- CHECK REAR POWER WINDOW SWITCH Turn ignition switch OFF. Disconnect rear power window switch connector. Check rear power window switch. CONTINUITY REFERENCE CHART Rear power window switch Terminal Rear power window switch condition Continuity LH:D83 RH:D103 1 5 UP Existed 3 4 3 4 NEUTRAL 2 5 1 4 DOWN 2 5 Is the inspection result normal? YES: INSPECTION END NO: Replace rear power window switch. Refer to " «REMOVAL AND INSTALLATION»(ref-295094-S03184635162008081400000) ".
DRIVER SIDE : Diagnosis Procedure
- CHECK POWER WINDOW MOTOR (DRIVER SIDE) INPUT SIGNAL Turn ignition switch OFF. Disconnect front power window motor (driver side) connector. Turn ignition switch ON. Check voltage between power window motor (driver side) harness connector and ground. VOLTAGE SPECIFICATION CHART (+) (-) Condition Voltage (V) (Approx.) Power window motor (driver side) Connector Terminal D7 1 Ground Power window main switch UP Battery voltage DOWN 0 2 UP 0 DOWN Battery voltage Is the inspection result normal? YES: GO TO 3 . NO: GO TO 2.
- CHECK POWER WINDOW MOTOR CIRCUIT Turn ignition switch OFF. Disconnect power window main switch connector. Check continuity between power window main switch harness connector and front power window motor (driver side) harness connector. CONTINUITY REFERENCE CHART Power window main switch Front power window motor (driver side) Continuity Connector Terminal Connector Terminal D5 8 D7 2 Existed 11 1 Check continuity between power window main switch harness connector and ground. CONTINUITY REFERENCE CHART Power window main switch Ground Continuity Connector Terminal D5 8 Not existed 11 Is the inspection result normal? YES: Replace power window main switch. Refer to " «REMOVAL AND INSTALLATION»(ref-295094-S03184635162008081400000) ". NO: Repair or replace harness.
- CHECK FRONT POWER WINDOW MOTOR (DRIVER SIDE) Check front power window motor (driver side). Refer to " «DRIVER SIDE : Component Inspection»(ref-295094-S25246332572008081400000) ". Is the inspection result normal? YES: GO TO 4. NO: Replace power window motor (driver side). Refer to " «REMOVAL AND INSTALLATION»(ref-295120-S29146772142008081400000) ".
- CHECK INTERMITTENT INCIDENT Refer to " «INTERMITTENT INCIDENT»(ref-295085-S23576844552008081400000) ". INSPECTION END
DRIVER SIDE : Component Inspection
- CHECK FRONT POWER WINDOW MOTOR (DRIVER SIDE) Turn ignition switch OFF. Disconnect front power window motor (driver side) connector. Check motor operate by connecting the battery voltage directly to front power window motor (driver side) connector. CONNECTOR TERMINAL REFERENCE CHART Front power window motor (driver side) connector Terminal Motor condition (+) (-) D7 1 2 DOWN 2 1 UP Is the inspection result normal? YES: INSPECTION END NO: Replace front power window motor (driver side). Refer to " «REMOVAL AND INSTALLATION»(ref-295120-S29146772142008081400000) ".
PASSENGER SIDE : Diagnosis Procedure
- CHECK FRONT POWER WINDOW MOTOR (PASSENGER SIDE) INPUT SIGNAL Turn ignition switch OFF. Disconnect front power window motor (passenger side) connector. Turn ignition switch ON. Check voltage between front power window motor (passenger side) harness connector and ground. VOLTAGE SPECIFICATION CHART (+) (-) Condition Voltage (V) (Approx.) Front power window motor (passenger side) Connector Terminal D46 2 Ground Front power window switch (passenger side) UP Battery voltage DOWN 0 1 UP 0 DOWN Battery voltage Is the inspection result normal? YES: GO TO 3 . NO: GO TO 2.
- CHECK FRONT POWER WINDOW MOTOR (PASSENGER SIDE) CIRCUIT Turn ignition switch OFF. Disconnect front power window switch (passenger side) connector. Check continuity between front power window switch (passenger side) harness connector and front power window motor (passenger side) harness connector. CONTINUITY REFERENCE CHART Front power window switch (passenger side) Front power window motor (passenger side) Continuity Connector Terminal Connector Terminal D45 6 D46 1 Existed 7 2 Check continuity between front power window switch (passenger side) harness connector and ground. CONTINUITY REFERENCE CHART Front power window switch (passenger side) Ground Continuity Connector Terminal D45 6 Not existed 7 Is the inspection result normal? YES: Replace front power window switch (passenger side). " «REMOVAL AND INSTALLATION»(ref-295094-S03184635162008081400000) ". NO: Repair or replace harness.
- CHECK FRONT POWER WINDOW MOTOR (PASSENGER SIDE) Check front power window motor (passenger side). Refer to " «PASSENGER SIDE : Component Inspection»(ref-295094-S21475230592008081400000) ". Is the inspection result normal? YES: GO TO 4. NO: Replace front power window motor (passenger side). Refer to " «REMOVAL AND INSTALLATION»(ref-295120-S29146772142008081400000) ".
- CHECK INTERMITTENT INCIDENT Refer to " «INTERMITTENT INCIDENT»(ref-295085-S23576844552008081400000) ". INSPECTION END
PASSENGER SIDE : Component Inspection
- CHECK FRONT POWER WINDOW MOTOR (PASSENGER SIDE) Turn ignition switch OFF. Disconnect front power window motor (passenger side) connector. Check motor operate by connecting the battery voltage directly to front power window motor (passenger side) connector. CONNECTOR TERMINAL REFERENCE CHART Front power window motor (passenger side) connector Terminal Motor condition (+) (-) D46 1 2 DOWN 2 1 UP Is the inspection result normal? YES: INSPECTION END NO: Replace front power window motor (passenger side). Refer to " «REMOVAL AND INSTALLATION»(ref-295120-S29146772142008081400000) ".
REAR LH : Diagnosis Procedure
- CHECK REAR POWER WINDOW MOTOR LH INPUT SIGNAL Turn ignition switch OFF. Disconnect rear power window motor LH connector. Turn ignition switch ON. Check voltage between rear power window motor LH harness connector and ground. VOLTAGE SPECIFICATION CHART (+) (-) Condition Voltage (V) (Approx.) Rear power window motor LH Connector Terminal D82 1 Ground Rear power window switch LH UP Battery voltage DOWN 0 3 UP 0 DOWN Battery voltage Is the inspection result normal? YES: GO TO 3 . NO: GO TO 2.
- CHECK REAR POWER WINDOW MOTOR LH CIRCUIT Turn ignition switch OFF. Disconnect rear power window switch LH connector. Check continuity between rear power window switch LH harness connector and rear power window motor LH harness connector. CONTINUITY REFERENCE CHART Rear power window switch LH Rear power window motor LH Continuity Connector Terminal Connector Terminal D83 4 D82 3 Existed 5 1 Check continuity between rear power window switch LH connector and ground. CONTINUITY REFERENCE CHART Rear power window switch LH Ground Continuity Connector Terminal D83 4 Not existed 5 Is the inspection result normal? YES: Replace rear power window switch LH. Refer to " «REMOVAL AND INSTALLATION»(ref-295094-S03184635162008081400000) ". NO: Repair or replace harness.
- CHECK REAR POWER WINDOW MOTOR LH Check rear power window motor LH. Refer to " «REAR LH : Component Inspection»(ref-295094-S20931571792008081400000) ". Is the inspection result normal? YES: GO TO 4. NO: Replace rear power window motor LH. Refer to " «REMOVAL AND INSTALLATION»(ref-295120-S03346978592008081400000) ".
- CHECK INTERMITTENT INCIDENT Refer to " «INTERMITTENT INCIDENT»(ref-295085-S23576844552008081400000) ". INSPECTION END
- CHECK REAR POWER WINDOW MOTOR LH Turn ignition switch OFF. Disconnect rear power window motor LH connector. Check motor operate by connecting the battery voltage directly to rear power window motor LH connector. CONNECTOR TERMINAL REFERENCE CHART Rear power window motor LH connector Terminal Motor condition (+) (-) D82 3 1 DOWN 1 3 UP Is the inspection result normal? YES: INSPECTION END NO: Replace rear power window motor LH. Refer to " «REMOVAL AND INSTALLATION»(ref-295120-S03346978592008081400000) ".
REAR RH : Diagnosis Procedure
- CHECK REAR POWER WINDOW MOTOR RH INPUT SIGNAL Turn ignition switch OFF. Disconnect rear power window motor RH connector. Turn ignition switch ON. Check voltage between rear power window motor RH harness connector and ground. VOLTAGE SPECIFICATION CHART (+) (-) Condition Voltage (V) (Approx.) Rear power window motor RH Connector Terminal D102 1 Ground Rear power window switch RH UP Battery voltage DOWN 0 3 UP 0 DOWN Battery voltage Is the inspection result normal? YES: GO TO 3 . NO: GO TO 2.
- CHECK REAR POWER WINDOW MOTOR RH CIRCUIT Turn ignition switch OFF. Disconnect rear power window switch RH connector. Check continuity between rear power window switch RH harness connector and rear power window motor RH harness connector. CONTINUITY REFERENCE CHART Rear power window switch RH Rear power window motor RH Continuity Connector Terminal Connector Terminal D103 4 D102 3 Existed 5 1 Check continuity between rear power window switch RH harness connector and ground. CONTINUITY REFERENCE CHART Rear power window switch RH Ground Continuity Connector Terminal D103 4 Not existed 5 Is the inspection result normal? YES: Replace rear power window switch RH. Refer to " «REMOVAL AND INSTALLATION»(ref-295094-S03184635162008081400000) ". NO: Repair or replace harness.
- CHECK REAR POWER WINDOW MOTOR RH Check rear power window motor RH. Refer to " «REAR RH : Component Inspection»(ref-295094-S06046152592008081400000) ". Is the inspection result normal? YES: GO TO 4. NO: Replace rear power window motor RH. Refer to " «REMOVAL AND INSTALLATION»(ref-295120-S03346978592008081400000) ".
- CHECK INTERMITTENT INCIDENT Refer to " «INTERMITTENT INCIDENT»(ref-295085-S23576844552008081400000) ". INSPECTION END
- CHECK REAR POWER WINDOW MOTOR RH Turn ignition switch OFF. Disconnect rear power window motor RH connector. Check motor operation by connecting the battery voltage directly to rear power window motor RH connector. CONNECTOR TERMINAL REFERENCE CHART Rear power window motor RH connector Terminal Motor condition (+) (-) D102 3 1 DOWN 1 3 UP Is the inspection result normal? YES: INSPECTION END NO: Replace rear power window motor RH. Refer to " «REMOVAL AND INSTALLATION»(ref-295120-S03346978592008081400000) ".
- CHECK DOOR SWITCH Turn ignition switch OFF. Disconnect door switch connector. Check door switch. CONNECTOR TERMINAL REFERENCE CHART Terminal Condition Continuity Each door 2 Ground Door switch pressed Exists Door switch released Does not exist Back door 3 4 Back door open Exists Back door close Does not exist Is the inspection result normal? YES: Door switch is OK. NO: Replace Door switch . Refer to " «REMOVAL AND INSTALLATION»(ref-295116-S08710407492008081400000) ".
Encoder Circuit Check
Scheme 2
- CHECK ENCODER OPERATION Turn ignition switch ON. Check signal between power window main switch harness connector and ground with oscilloscope. CONNECTOR TERMINAL REFERENCE CHART (+) (-) Signal (Reference value) Power window main switch Connector Terminal D5 9 Ground Refer to following signal 13 Is the inspection result normal? YES: GO TO 7 . NO: GO TO 2.
- CHECK ENCORDER SIGNAL CIRCUIT Turn ignition switch OFF. Disconnect power window main switch connector and front power window motor (driver side) connector. Check continuity between power window main switch harness connector and front power window motor (driver side) harness connector. CONTINUITY REFERENCE CHART Power window main switch Front power window motor (driver side) Continuity Connector Terminal Connector Terminal D5 9 D7 3 Existed 13 5 Check continuity between power window main switch harness connector and ground. CONTINUITY REFERENCE CHART Power window main switch Ground Continuity Connector Terminal D5 9 Not existed 13 Is the inspection result normal? YES: GO TO 3. NO: Repair or replace harness.
- CHECK ENCORDER POWER SUPPLY CIRCUIT Connect power window main switch connector. Turn ignition switch ON. Check voltage between front power window motor (driver side) harness connector and ground. VOLTAGE SPECIFICATION CHART (+) (-) Voltage (V) (Approx.) Front power window motor (driver side) Connector Terminal D7 4 Ground Battery voltage Is the inspection result normal? YES: GO TO 4. NO: GO TO 5 .
- CHECK GROUND CIRCUIT Turn ignition switch OFF. Check continuity between front power window motor (driver side) harness connector and ground. CONTINUITY REFERENCE CHART Front power window motor (driver side) Ground Continuity Connector Terminal D7 6 Existed Is the inspection result normal? YES: GO TO 7 . NO: GO TO 6 .
- CHECK HARNESS CONTINUITY 1 Turn ignition switch OFF. Check continuity between power window main switch harness connector and front power window motor (driver side) harness connector. CONTINUITY REFERENCE CHART Power window main switch Front power window motor (driver side) Continuity Connector Terminal Connector Terminal D5 15 D7 4 Existed Check continuity between power window main switch harness connector and ground. CONTINUITY REFERENCE CHART Power window main switch Ground Continuity Connector Terminal D5 15 Not existed Is the inspection result normal? YES: Replace power window main switch. Refer to " «REMOVAL AND INSTALLATION»(ref-295094-S03184635162008081400000) ". NO: Repair or replace harness.
- CHECK HARNESS CONTINUITY 2 Disconnect power window main switch connector. Check continuity between power window main switch harness connector and front power window motor (driver side) harness connector. CONTINUITY REFERENCE CHART Power window main switch Front power window motor (driver side) Continuity Connector Terminal Connector Terminal D5 2 D7 6 Existed Is the inspection result normal? YES: Replace power window main switch. Refer to " «REMOVAL AND INSTALLATION»(ref-295094-S03184635162008081400000) ". NO: Repair or replace harness.
- CHECK INTERMITTENT INCIDENT Refer to " «INTERMITTENT INCIDENT»(ref-295085-S23576844552008081400000) ". INSPECTION END
VALUES ON THE DIAGNOSIS TOOL
| Monitor Item | Condition | Value/Status |
|---|---|---|
| IGN ON SW | Ignition switch OFF or ACC | Off |
| Ignition switch ON | On | |
| KEY ON SW | Mechanical key is removed from key cylinder | Off |
| Mechanical key is inserted to key cylinder | On | |
| CDL LOCK SW | Door lock/unlock switch does not operate | Off |
| Press door lock/unlock switch to the lock side | On | |
| CDL UNLOCK SW | Door lock/unlock switch does not operate | Off |
| Press door lock/unlock switch to the unlock side | On | |
| DOOR SW-DR | Driver's door closed | Off |
| Driver's door opened | On | |
| DOOR SW-AS | Passenger door closed | Off |
| Passenger door opened | On | |
| DOOR SW-RR | Rear RH door closed | Off |
| Rear RH door opened | On | |
| DOOR SW-RL | Rear LH door closed | Off |
| Rear LH door opened | On | |
| BACK DOOR SW | Back door closed | Off |
| Back door opened | On | |
| KEY CYL LK-SW | Other than driver door key cylinder LOCK position | Off |
| Driver door key cylinder LOCK position | On | |
| KEY CYL UN-SW | Other than driver door key cylinder UNLOCK position | Off |
| Driver door key cylinder UNLOCK position | On | |
| KEYLESS LOCK | "LOCK" button of key fob is not pressed | Off |
| "LOCK" button of key fob is pressed | On | |
| KEYLESS UNLOCK | "UNLOCK" button of key fob is not pressed | Off |
| "UNLOCK" button of key fob is pressed | On | |
| I-KEY LOCK | "LOCK" button of Intelligent Key or door request switch are not pressed | Off |
| "LOCK" button of Intelligent Key or door request switch are pressed | On | |
| I-KEY UNLOCK | "UNLOCK" button of Intelligent Key or door request switch are not pressed | Off |
| "UNLOCK" button of Intelligent Key or door request switch are pressed | On | |
| ACC ON SW | Ignition switch OFF | Off |
| Ignition switch ACC or ON | On | |
| REAR DEF SW | Rear window defogger switch OFF | Off |
| Rear window defogger switch ON | On | |
| LIGHT SW 1ST | Lighting switch OFF | Off |
| Lighting switch 1ST | On | |
| BUCKLE SW | The seat belt (driver side) is unfastened. [Seat belt switch (driver side) OFF] | Off |
| The seat belt (driver side) is fastened. [Seat belt switch (driver side) ON] | On | |
| KEYLESS PANIC | PANIC button of key fob is not pressed | Off |
| PANIC button of key fob is pressed | On | |
| KEYLESS TRUNK | NOTE: The item is indicated, but not monitored. | Off |
| TRNK OPN MNTR | NOTE: The item is indicated, but not monitored. | Off |
| RKE LCK-UNLCK | LOCK/UNLOCK button of key fob is not pressed and held simultaneously | Off |
| LOCK/UNLOCK button of key fob is pressed and held simultaneously | On | |
| RKE KEEP UNLK | UNLOCK button of key fob is not pressed | Off |
| UNLOCK button of key fob is pressed and held | On | |
| HI BEAM SW | Lighting switch OFF | Off |
| Lighting switch HI | On | |
| HEAD LAMP SW 1 | Lighting switch OFF | Off |
| Lighting switch 2ND | On | |
| HEAD LAMP SW 2 | Lighting switch OFF | Off |
| Lighting switch 2ND | On | |
| AUTO LIGHT SW | NOTE: The item is indicated, but not monitored. | Off |
| PASSING SW | Other than lighting switch PASS | Off |
| Lighting switch PASS | On | |
| FR FOG SW | Front fog lamp switch OFF | Off |
| Front fog lamp switch ON | On | |
| RR FOG SW | NOTE: The item is indicated, but not monitored. | Off |
| TURN SIGNAL R | Turn signal switch OFF | Off |
| Turn signal switch RH | On | |
| TURN SIGNAL L | Turn signal switch OFF | Off |
| Turn signal switch LH | On | |
| ENGINE RUN | Engine stopped | Off |
| Engine running | On | |
| PKB SW | Parking brake switch is OFF | Off |
| Parking brake switch is ON | On | |
| CARGO LAMP SW | NOTE: The item is indicated, but not monitored. | Off |
| OPTICAL SENSOR | NOTE: The item is indicated, but not monitored. | 0 V |
| IGN SW CAN | Ignition switch OFF or ACC | Off |
| Ignition switch ON | On | |
| FR WIPER HI | Front wiper switch OFF | Off |
| Front wiper switch HI | On | |
| FR WIPER LOW | Front wiper switch OFF | Off |
| Front wiper switch LO | On | |
| FR WIPER INT | Front wiper switch OFF | Off |
| Front wiper switch INT | On | |
| FR WASHER SW | Front washer switch OFF | Off |
| Front washer switch ON | On | |
| INT VOLUME | Wiper intermittent dial is in a dial position 1 - 7 | 1 - 7 |
| FR WIPER STOP | Any position other than front wiper stop position | Off |
| Front wiper stop position | On | |
| VEHICLE SPEED | While driving | Equivalent to speedometer reading |
| RR WIPER ON | Rear wiper switch OFF | Off |
| Rear wiper switch ON | On | |
| RR WIPER INT | Rear wiper switch OFF | Off |
| Rear wiper switch INT | On | |
| RR WASHER SW | Rear washer switch OFF | Off |
| Rear washer switch ON | On | |
| RR WIPER STOP | Rear wiper stop position | Off |
| Other than rear wiper stop position | On | |
| RR WIPER STP2 | NOTE: The item is indicated, but not monitored. | Off |
| H/L WASH SW | NOTE: The item is indicated, but not monitored. | Off |
| HAZARD SW | Hazard switch OFF | Off |
| Hazard switch ON | On | |
| BRAKE SW | Brake pedal is not depressed | Off |
| Brake pedal is depressed | On | |
| FAN ON SIG | Blower fan motor switch OFF | Off |
| Blower fan motor switch ON (other than OFF) | On | |
| AIR COND SW | Compressor ON is not requested from auto amp. (A/C indicator OFF, blower fan motor switch OFF or etc.) | Off |
| Compressor ON is requested from auto amp. (A/C indicator ON and blower fan motor switch ON). | On | |
| I-KEY TRUNK | NOTE: The item is indicated, but not monitored. | Off |
| I-KEY PW DWN | UNLOCK button of Intelligent Key is not pressed | Off |
| UNLOCK button of Intelligent Key is pressed and held | On | |
| I-KEY PANIC | PANIC button of Intelligent Key is not pressed | Off |
| PANIC button of Intelligent Key is pressed | On | |
| PUSH SW | Return to ignition switch to "LOCK" position | Off |
| Press ignition switch | On | |
| TRNK OPNR SW | When back door opener switch is not pressed | Off |
| When back door opener switch is pressed | On | |
| TRUNK CYL SW | NOTE: The item is indicated, but not monitored. | Off |
| HOOD SW | Close the hood NOTE: Vehicles of except for Mexico are OFF-fixed | Off |
| Open the hood | On | |
| OIL PRESS SW | Ignition switch OFF or ACC Engine running | Off |
| Ignition switch ON | On | |
| AIR PRESS FL | Ignition switch ON (Only when the signal from the transmitter is received) | Air pressure of front LH tire |
| AIR PRESS FR | Ignition switch ON (Only when the signal from the transmitter is received) | Air pressure of front RH tire |
| AIR PRESS RR | Ignition switch ON (Only when the signal from the transmitter is received) | Air pressure of rear RH tire |
| AIR PRESS RL | Ignition switch ON (Only when the signal from the transmitter is received) | Air pressure of rear LH tire |
| ID REGST FL1 | ID of front LH tire transmitter is registered | Done |
| ID of front LH tire transmitter is not registered | Yet | |
| ID REGST FR1 | ID of front RH tire transmitter is registered | Done |
| ID of front RH tire transmitter is not registered | Yet | |
| ID REGST RR1 | ID of rear RH tire transmitter is registered | Done |
| ID of rear RH tire transmitter is not registered | Yet | |
| ID REGST RL1 | ID of rear LH tire transmitter is registered | Done |
| ID of rear LH tire transmitter is not registered | Yet | |
| WARNING LAMP | Tire pressure indicator OFF | Off |
| Tire pressure indicator ON | On | |
| BUZZER | Tire pressure warning alarm is not sounding | Off |
| Tire pressure warning alarm is sounding | On |
| NOTE |
|---|
| The item is indicated, but not monitored. |
| NOTE |
|---|
| The item is indicated, but not monitored. |
| NOTE |
|---|
| The item is indicated, but not monitored. |
| NOTE |
|---|
| The item is indicated, but not monitored. |
| NOTE |
|---|
| The item is indicated, but not monitored. |
| NOTE |
|---|
| The item is indicated, but not monitored. |
| NOTE |
|---|
| The item is indicated, but not monitored. |
| NOTE |
|---|
| The item is indicated, but not monitored. |
| NOTE |
|---|
| The item is indicated, but not monitored. |
| NOTE |
|---|
| The item is indicated, but not monitored. |
| NOTE |
|---|
| Vehicles of except for Mexico are OFF-fixed |
BCM REFERENCE VALUE CHART
Scheme 3
DTC Inspection Priority Chart
| Priority | DTC |
|---|---|
| 1 | U1000: CAN COMM CIRCUIT |
| 2 | C1735: IGN CIRCUIT OPEN |
| 3 | C1704: LOW PRESSURE FL C1705: LOW PRESSURE FR C1706: LOW PRESSURE RR C1707: LOW PRESSURE RL C1708: [NO DATA] FL C1709: [NO DATA] FR C1710: [NO DATA] RR C1711: [NO DATA] RL C1712: [CHECKSUM ERR] FL C1713: [CHECKSUM ERR] FR C1714: [CHECKSUM ERR] RR C1715: [CHECKSUM ERR] RL C1716: [PRESS DATA ERR] FL C1717: [PRESS DATA ERR] FR C1718: [PRESS DATA ERR] RR C1719: [PRESS DATA ERR] RL C1720: [CODE ERR] FL C1721: [CODE ERR] FR C1722: [CODE ERR] RR C1723: [CODE ERR] RL C1724: [BATT VOLT LOW] FL C1725: [BATT VOLT LOW] FR C1726: [BATT VOLT LOW] RR C1727: [BATT VOLT LOW] RL C1729: VHCL SPEED SIG ERR |
DTC INSPECTION PRIORITY CHART
DTC Index
Note. Details of time display
- CRNT: Displays when there is a malfunction now or after returning to the normal condition until turning ignition switch OFF --> ON again.
- 1 - 39: Displayed if any previous malfunction is present when current condition is normal. It increases like 1 --> 2 --> 3...38 --> 39 after returning to the normal condition whenever ignition switch OFF --> ON. The counter remains at 39 even if the number of cycles exceeds it. It is counted from 1 again when turning ignition switch OFF --> ON after returning to the normal condition if the malfunction is detected again.
| DTC | Tire pressure monitor warning lamp ON | Reference |
|---|---|---|
| U1000: CAN COMM CIRCUIT | BCS-35 | |
| C1704: LOW PRESSURE FL | X | COMPONENT DIAGNOSIS |
| C1705: LOW PRESSURE FR | X | |
| C1706: LOW PRESSURE RR | X | |
| C1707: LOW PRESSURE RL | X | |
| C1708: [NO DATA] FL | X | C1708, C1709, C1710, C1711 TRANSMITTER (NO DATA) |
| C1709: [NO DATA] FR | X | |
| C1710: [NO DATA] RR | X | |
| C1711: [NO DATA] RL | X | |
| C1712: [CHECKSUM ERR] FL | X | C1712, C1713, C1714, C1715 TRANSMITTER (CHECKSUM) |
| C1713: [CHECKSUM ERR] FR | X | |
| C1714: [CHECKSUM ERR] RR | X | |
| C1715: [CHECKSUM ERR] RL | X | |
| C1716: [PRESS DATA ERR] FL | X | C1716, C1717, C1718, C1719 TRANSMITTER (PRESS DATA) |
| C1717: [PRESS DATA ERR] FR | X | |
| C1718: [PRESS DATA ERR] RR | X | |
| C1719: [PRESS DATA ERR] RL | X | |
| C1720: [CODE ERR] FL | X | C1720, C1721, C1722, C1723 TRANSMITTER (CODE) |
| C1721: [CODE ERR] FR | X | |
| C1722: [CODE ERR] RR | X | |
| C1723: [CODE ERR] RL | X | |
| C1724: [BATT VOLT LOW] FL | C1724, C1725, C1726, C1727 TRANSMITTER (BATT VOLT) | |
| C1725: [BATT VOLT LOW] FR | ||
| C1726: [BATT VOLT LOW] RR | ||
| C1727: [BATT VOLT LOW] RL | ||
| C1729: VHCL SPEED SIG ERR | X | C1729 VEHICLE SPEED SIG ERR |
| C1735: IGN CIRCUIT OPEN | C1735 IGN CIRCUIT OPEN |
DTC INDEX
Scheme 4
- CHECK BCM POWER SUPPLY AND GROUND CIRCUIT Check BCM power supply and ground circuit. Refer to " «BCM : Diagnosis Procedure»(ref-295094-S20311343472008081400000) ". Is the inspection result normal? YES: GO TO 2. NO: Repair or replace the malfunctioning parts.
- CHECK POWER WINDOW MAIN SWITCH POWER SUPPLY AND GROUND CIRCUIT Check power window main switch power supply and ground circuit. Refer to " «POWER WINDOW MAIN SWITCH : Diagnosis Procedure»(ref-295094-S25942701282008081400000) ". Is the inspection result normal? YES: GO TO 3. NO: Repair or replace the malfunctioning parts.
- CONFIRM THE OPERATION Confirm the operation again. Is the result normal? YES: Check intermittent incident. Refer to " «INTERMITTENT INCIDENT»(ref-295085-S23576844552008081400000) ". NO: GO TO 1 .
- CHECK FRONT POWER WINDOW MOTOR (DRIVER SIDE) Check power window motor. Refer to " «DRIVER SIDE : Component Function Check»(ref-295094-S40355499072008081400000) ". Is the inspection result normal? YES: GO TO 2. NO: Repair or replace the malfunctioning parts.
- CONFIRM THE OPERATION Confirm the operation again. Is the result normal? YES: Check intermittent incident. Refer to " «INTERMITTENT INCIDENT»(ref-295085-S23576844552008081400000) ". NO: GO TO 1 .
WITH BOTH POWER WINDOW MAIN SWITCH AND FRONT PASSENGER SIDE POWER WINDOW SWITCH : Diagnosis Procedure
- CHECK FRONT POWER WINDOW SWITCH (PASSENGER SIDE) Check front power window switch (passenger side). Refer to " «COMPONENT FUNCTION CHECK»(ref-295094-S25751846112008081400000) ". Is the inspection result normal? YES: GO TO 2. NO: Repair or replace the malfunctioning parts
- CHECK FRONT POWER WINDOW MOTOR (PASSENGER SIDE) Check front power window motor (passenger side). Refer to " «PASSENGER SIDE : Component Function Check»(ref-295094-S03437209562008081400000) ". Is the inspection result normal? YES: GO TO 3. NO: Repair or replace the malfunctioning parts.
- CONFIRM THE OPERATION Confirm the operation again. Is the result normal? YES: Check intermittent incident. Refer to " «INTERMITTENT INCIDENT»(ref-295085-S23576844552008081400000) ". NO: GO TO 1 .
WITH FRONT POWER WINDOW SWITCH ONLY : Diagnosis Procedure
- CHECK FRONT POWER WINDOW SWITCH (PASSENGER SIDE) POWER SUPPLY AND GROUND CIRCUIT Check front power window switch (passenger side) power supply and ground circuit. Refer to " «FRONT POWER WINDOW SWITCH (PASSENGER SIDE) : Diagnosis Procedure»(ref-295094-S17326067892008081400000) ". Is the inspection result normal? YES: GO TO 2. NO: Repair or replace the malfunctioning parts.
- CHECK FRONT POWER WINDOW SWITCH (PASSENGER SIDE) Check front power window switch (passenger side). Refer to " «COMPONENT FUNCTION CHECK»(ref-295094-S25751846112008081400000) ". Is the inspection result normal? YES: GO TO 3. NO: Repair or replace the malfunctioning parts
- CONFIRM THE OPERATION Confirm the operation again. Is the result normal? YES: Check intermittent incident. Refer to " «INTERMITTENT INCIDENT»(ref-295085-S23576844552008081400000) ". NO: GO TO 1 .
WITH BOTH POWER WINDOW MAIN SWITCH AND REAR POWER WINDOW SWITCH LH : Diagnosis Procedure
- CHECK REAR POWER WINDOW SWITCH Check rear power window switch. Refer to " «COMPONENT FUNCTION CHECK»(ref-295094-S37399766392008081400000) ". Is the inspection result normal? YES: GO TO 2. NO: Repair or replace the malfunctioning parts.
- CHECK REAR POWER WINDOW MOTOR LH Check rear power window motor LH. Refer to " «REAR LH : Component Function Check»(ref-295094-S07191079362008081400000) ". Is the inspection result normal? YES: GO TO 3. NO: Repair or replace the malfunctioning parts.
- CONFIRM THE OPERATION Confirm the operation again. Is the result normal? YES: Check intermittent incident. Refer to " «INTERMITTENT INCIDENT»(ref-295085-S23576844552008081400000) ". NO: GO TO 1 .
WITH REAR POWER WINDOW SWITCH LH ONLY : Diagnosis Procedure
- CHECK REAR POWER WINDOW SWITCH POWER SUPPLY AND GROUND CIRCUIT Check rear power window switch power supply and ground circuit. Refer to " «REAR POWER WINDOW SWITCH : Diagnosis Procedure»(ref-295094-S18078148292008081400000) ". Is the inspection result normal? YES: GO TO 2. NO: Repair or replace the malfunctioning parts.
- CHECK REAR POWER WINDOW SWITCH Check rear power window switch. Refer to " «COMPONENT FUNCTION CHECK»(ref-295094-S37399766392008081400000) ". Is the inspection result normal? YES: GO TO 3. NO: Repair or replace the malfunctioning parts.
- CONFIRM THE OPERATION Confirm the operation again. Is the result normal? YES: Check intermittent incident. Refer to " «INTERMITTENT INCIDENT»(ref-295085-S23576844552008081400000) ". NO: GO TO 1 .
WITH BOTH POWER WINDOW MAIN SWITCH AND REAR POWER WINDOW SWITCH RH : Diagnosis Procedure
- CHECK REAR POWER WINDOW SWITCH Check rear power window switch. Refer to " «COMPONENT FUNCTION CHECK»(ref-295094-S37399766392008081400000) ". Is the inspection result normal? YES: GO TO 2. NO: Repair or replace the malfunctioning parts.
- CHECK REAR POWER WINDOW MOTOR RH Check rear power window motor RH. Refer to " «REAR RH : Component Function Check»(ref-295094-S36345379722008081400000) ". Is the inspection result normal? YES: GO TO 3. NO: Repair or replace the malfunctioning parts.
- CONFIRM THE OPERATION Confirm the operation again. Is the result normal? YES: Check intermittent incident. Refer to " «INTERMITTENT INCIDENT»(ref-295085-S23576844552008081400000) ". NO: GO TO 1 .
WITH REAR POWER WINDOW SWITCH RH ONLY : Diagnosis Procedure
- CHECK REAR POWER WINDOW SWITCH POWER SUPPLY AND GROUND CIRCUIT Check rear power window switch power supply and ground circuit. Refer to " «REAR POWER WINDOW SWITCH : Diagnosis Procedure»(ref-295094-S18078148292008081400000) ". Is the inspection result normal? YES: GO TO 2. NO: Repair or replace the malfunctioning parts.
- CHECK REAR POWER WINDOW SWITCH Check rear power window switch. Refer to " «COMPONENT FUNCTION CHECK»(ref-295094-S37399766392008081400000) ". Is the inspection result normal? YES: GO TO 3. NO: Repair or replace the malfunctioning parts.
- CONFIRM THE OPERATION Confirm the operation again. Is the result normal? YES: Check intermittent incident. Refer to " «INTERMITTENT INCIDENT»(ref-295085-S23576844552008081400000) ". NO: GO TO 1 .
- PERFORM INITIALIZATION PROCEDURE Initialization procedure is executed and operation is confirmed. Refer to " «ADDITIONAL SERVICE WHEN REMOVING BATTERY NEGATIVE TERMINAL : Special Repair Requirement»(ref-295094-S10890779092008081400000) ". Is the inspection result normal? YES: INSPECTION END NO: GO TO 2.
- CHECK ENCODER CIRCUIT Check encoder circuit. Refer to " «COMPONENT FUNCTION CHECK»(ref-295094-S39372243042008081400000) ". Is the inspection result normal? YES: GO TO 3. NO: Repair or replace the malfunctioning parts.
- CONFIRM THE OPERATION Confirm the operation again. Is the result normal? YES: Check intermittent incident. Refer to " «INTERMITTENT INCIDENT»(ref-295085-S23576844552008081400000) ". NO: GO TO 1 .
- CHECK DOOR SWITCH Check door switch. Refer to " «COMPONENT FUNCTION CHECK»(ref-295094-S38557015272008081400000) ". Is the inspection result normal? YES: GO TO 2. NO: Repair or replace the malfunctioning parts.
- CONFIRM THE OPERATION Confirm the operation again. Is the result normal? YES: Check intermittent incident. Refer to " «INTERMITTENT INCIDENT»(ref-295085-S23576844552008081400000) ". NO: GO TO 1 .
- PERFORM INITIALIZATION PROCEDURE Initialization procedure is executed and operation is confirmed. Refer to " «ADDITIONAL SERVICE WHEN REMOVING BATTERY NEGATIVE TERMINAL : Special Repair Requirement»(ref-295094-S10890779092008081400000) ". Is the inspection result normal? YES: INSPECTION END NO: GO TO 2.
- CHECK ENCODER Check encoder. Refer to " «COMPONENT FUNCTION CHECK»(ref-295094-S39372243042008081400000) ". Is the inspection result normal? YES: GO TO 3. NO: Repair or replace the malfunctioning parts.
- CONFIRM THE OPERATION Confirm the operation again. Is the result normal? YES: Check intermittent incident. Refer to " «INTERMITTENT INCIDENT»(ref-295085-S23576844552008081400000) ". NO: GO TO 1 .
- REPLACE POWER WINDOW MAIN SWITCH Replace power window main switch. Refer to " «REMOVAL AND INSTALLATION»(ref-295094-S03184635162008081400000) ".
