Starting System: Overhaul Nissan Rogue I

DISASSEMBLY

Type: M000TA0271

Scheme 7

Scheme 8

1. Disconnect the battery cable from the negative terminal.
2. Remove "B" terminal nut (A) and "B" terminal harness. -->: Vehicle front
3. Disconnect "S" connector (B).
4. Remove starter motor mounting bolts (C), using power tools.
5. Remove starter motor downward from the vehicle.

Type: M000TA0271

Scheme 9

Scheme 10

1. Disconnect the battery cable from the negative terminal.
2. Remove exhaust front tube. Refer to " «EXPLODED VIEW»(ref-295123-S20064475632008081400000) ".
3. Remove "B" terminal nut (A) and "B" terminal harness. ↓: Vehicle front
4. Disconnect "S" connector (B).
5. Remove starter motor mounting bolts (C), using power tools.
6. Remove starter motor downward from the vehicle.
