WIPER BLADE POSITION ADJUSTMENT
Clearance between the end of cowl top cover/front fender cover and the top of front wiper blade center.
Scheme 5
Standard clearance
- D: 35.0 ± 7.5 mm (1.378 ± 0.295 in)
- P: 37.2 ± 7.5 mm (0.295 ± 0.295 in)
Scheme 6
- Lift up front wiper arm, and set to the position where wiper arm can be locked back.
- Remove lock lever (A) of front wiper blade (1). Pull front wiper blade in the direction indicated by the arrow as shown in the figure below to remove front wiper blade from front wiper arm (2). CAUTION: Wrap wiper arm using a shop cloth so that wiper blade does not damage windshield glass.
REAR WIPER BLADE POSITION ADJUSTMENT
Set the wiper blade top on the defrosting wire (A) (clearance between the end of back door glass and the top of wiper blade center).
Standard clearance
- Rear wiper blade
- Back door window glass
- Back door panel
- Back door trim
Scheme 7
- A: Rear defogger wire print
- L: 50.2 ± 7.5 mm (1.976 ± 0.295 in)
Scheme 8
- Lift up and hold rear wiper arm. Remove rear wiper blade (1) from rear wiper arm (2) while rotating rear wiper blade (1) in the direction indicated by the arrow as shown in the figure below. CAUTION: Wrap wiper arm using a shop cloth so that wiper blade does not damage back door window glass.
ADJUSTMENT
FRONT WASHER NOZZLE SPRAY POSITION ADJUSTMENT
Adjust spray positions to match the positions shown in the figure below.
Scheme 9
| Unit: mm (in) | ||||||||
|---|---|---|---|---|---|---|---|---|
| Driver side | Passenger side | |||||||
| A | B | C | D | E | F | G | H | |
| X | 578 (22.76) | 381 (15.00) | 181 (7.13) | 129 (5.08) | 88 (3.46) | 169 (6.65) | 366 (14.41) | 484 (19.06) |
| Y | 638 (14.49) | 62 (2.44) | 56 (2.20) | 703 (27.68) | 674 (26.54) | 49 (1.93) | 61 (2.40) | 504 (19.84) |
Check that washer fluid is splayed on 70% or more the splay area (shaded area in figure ) when spraying washer fluid. If the spray area deviates from the specification, adjust the washer nozzle.
| CAUTION | Use washer nozzle adjuster (A) for nozzle (1) insert adjustment if the jet a is outside the angle. Never use needle or small pin. |
Scheme 10
Note. If wax or dust gets into the nozzle, remove wax or dust with a needle or small pin.
REAR WASHER NOZZLE SPRAY POSITION ADJUSTMENT
Adjust spray positions to match the positions shown in the figure below.
Scheme 11
| Unit: mm (in) | ||
|---|---|---|
| H: Height | L: Length | Ø: Spray position area |
| 3.0 (0.118) | 115.0 (4.528) | 30 (1.181) |
Insert a needle or similar object (A) into the spray opening (1) and move up/down and left/right to adjust the spray position.
Scheme 12
Note. If wax or dust gets into the nozzle, remove wax or dust with a needle or small pin.
