Automatic Drive Positioner: Diagnosis Nissan Quest IV

Seats 3 illustrations ~8546 words

DTC INDEX

DTCDescription
DTC U1000CAN COMM CIRCUIT
DTC U1010CONTROL UNIT (CAN)
DTC B2112SLIDING MOTOR
DTC B2113RECLINING MOTOR
DTC B2128UART COMMUNICATION LINE
DTC B2130EEPROM

DTC INDEX

Scheme 10

Scheme 10: Precautions for Removing Battery Terminal
Scheme 10: Precautions for Removing Battery Terminal
  1. When removing the 12V battery terminal, turn OFF the ignition switch and wait at least 30 seconds. NOTE: ECU may be active for several tens of seconds after the ignition switch is turned OFF. If the battery terminal is removed before ECU stops, then a DTC detection error or ECU data corruption may occur.
  2. For vehicles with the 2-batteries, be sure to connect the main battery and the sub battery before turning ON the ignition switch. NOTE: If the ignition switch is turned ON with any one of the terminals of main battery and sub battery disconnected, then DTC may be detected.
  3. After installing the 12V battery, always check "Self Diagnosis Result" of all ECUs and erase DTC. NOTE: The removal of 12V battery may cause a DTC detection error.

SELF-DIAGNOSIS RESULTS

Refer to " DTC INDEX ".

ACTIVE TEST

CAUTIONWhen driving vehicle, do not perform active test.
Test itemDescription
SEAT SLIDEActivates/deactivates the sliding motor.
SEAT RECLININGActivates/deactivates the reclining motor.
SEAT LIFTER FRActivates/deactivates the lifting motor (front).
SEAT LIFTER RRActivates/deactivates the lifting motor (rear).
MIRROR MOTOR RHActivates/deactivates the mirror motor (passenger side).
MIRROR MOTOR LHActivates/deactivates the mirror motor (driver side).
MEMORY SW INDCTRTurns ON/OFF the memory indicator.

VALUES ON THE DIAGNOSIS TOOL

Note. The following table includes information (items) inapplicable to this vehicle. For information (items) applicable to this vehicle, refer to CONSULT display items.

Monitor ItemConditionValue/Status
SET SWSet switchPushON
ReleaseOFF
MEMORY SW1Memory switch 1PushON
ReleaseOFF
MEMORY SW2Memory switch 2PushON
ReleaseOFF
SLIDE SW-FRSliding switch (forward)OperateON
ReleaseOFF
SLIDE SW-RRSliding switch (backward)OperateON
ReleaseOFF
RECLN SW-FRReclining switch (forward)OperateON
ReleaseOFF
RECLN SW-RRReclining switch (backward)OperateON
ReleaseOFF
LIFT FR SW-UPLifting switch front (up)OperateON
ReleaseOFF
LIFT FR SW-DNLifting switch front (down)OperateON
ReleaseOFF
LIFT RR SW-UPLifting switch rear (up)OperateON
ReleaseOFF
LIFT RR SW-DNLifting switch rear (down)OperateON
ReleaseOFF
MIR CON SW-UPMirror switchUpON
Other than the aboveOFF
MIR CON SW-DNMirror switchDownON
Other than the aboveOFF
MIR CON SW-RHMirror switchRightON
Other than the aboveOFF
MIR CON SW-LHMirror switchLeftON
Other than the aboveOFF
MIR CHNG SW-RChangeover switchRightON
Other than the aboveOFF
MIR CHNG SW-LChangeover switchLeftON
Other than the aboveOFF
DETENT SWCVT shift selectorP positionOFF
Other than the aboveON
STARTER SWIgnition positionCrankingON
Other than the aboveOFF
SLIDE PULSESeat slidingForwardThe numeral value decreases (1)
BackwardThe numeral value increases (1)
Other than the aboveNo change to numeral value (1)
RECLN PULSESeat recliningForwardThe numeral value decreases (1)
BackwardThe numeral value increases (1)
Other than the aboveNo change to numeral value (1)
LIFT FR PULSESeat lifter (front)UpThe numeral value decreases (1)
DownThe numeral value increases (1)
Other than the aboveNo change to numeral value (1)
LIFT RR PULSESeat lifter (rear)UpThe numeral value decreases (1)
DownThe numeral value increases (1)
Other than the aboveNo change to numeral value (1)
MIR/SEN RH U-DDoor mirror (passenger side)Change between 3.4 (close to peak) 0.6 (close to valley)
MIR/SEN RH R-LDoor mirror (passenger side)Change between 3.4 (close to left edge) 0.6 (close to right edge)
MIR/SEN LH U-DDoor mirror (driver side)Change between 3.4 (close to peak) 0.6 (close to valley)
MIR/SEN LH R-LDoor mirror (driver side)Change between 0.6 (close to left edge) 3.4 (close to right edge)
STEERING STATUSSteering lock unitUnlockNOTE: This item is indicated, but not monitored.
VEHICLE SPEEDThe condition of vehicle speed is displayedKm/h
P RANG SW CANCVT shift selectorP positionON
Other than the aboveOFF
R RANGE (CAN)CVT shift selectorR positionON
Other than the aboveOFF
DOOR SW-FLDriver doorOpenON
CloseOFF
DOOR SW-FRPassenger doorOpenON
CloseOFF
IGN ON SWIgnition switchON positionON
Other than the aboveOFF
ACC ON SWIgnition switchACC or ON positionON
Other than the aboveOFF
KEYLESS IDUNLOCK button of Intelligent Key is pressed1, 2, 3, 4 or 5
KYLS DR UNLKIntelligent Key or driver side door request switchONON
OFFOFF
VHCL SPEED (ABS)Can signal from ABSReceivedON
Not receivedOFF
HANDLEThe BCM for handle position is displayedLHD
RHD
TRANSMISSIONTransmission type is displayedAT or CVT
MT
(1) The value at the position attained when the battery is connected is regarded as 32768.
NOTE
This item is indicated, but not monitored.
(1)The value at the position attained when the battery is connected is regarded as 32768.

Scheme 11

Scheme 11: TERMINAL LAYOUT
Scheme 11: TERMINAL LAYOUT
CONSULT displayTiming (1)ItemRefer to
Current malfunctionPrevious malfunction
CAN COMM CIRCUIT [U1000]01-39CAN communication" DTC LOGIC "
CONTROL UNIT (CAN) [U1010]01-39Control unit" DTC LOGIC "
SEAT SLIDE [B2112]01-39Seat slide motor output" DTC LOGIC "
SEAT RECLINING [B2113]01-39Seat reclining motor output" DTC LOGIC "
UART COMM [B2128]01-39UART communication" DTC LOGIC "
EEPROM [B2130]01-39EEPROM" DTC LOGIC "
(1) 0: Current malfunction is present 1-39: Displayed if any previous malfunction is present when current condition is normal. The numeral value increases by one at each IGN ON to OFF cycle from 1 to 39. The counter remains at 39 even if the number of cycles exceeds it. However, the counter is reset to 1 if any malfunction is detected again, the normal operation is resumed and the ignition switch is turned from OFF to ON.
(1)0: Current malfunction is present

Scheme 12

Scheme 12: TERMINAL LAYOUT
Scheme 12: TERMINAL LAYOUT

DTC DETECTION LOGIC

DTC No.CONSULT display descriptionDTC detecting conditionPossible cause
U1000CAN COMM CIRCUITDriver seat control unit cannot communicate to other control units. When driver seat control unit cannot communicate CAN communication signal continuously for 2 seconds or more.CAN communication system

DTC CONFIRMATION PROCEDURE

  1. STEP 1 Turn ignition switch ON and wait at least 3 seconds. : GO TO 2.
  2. STEP 2 Check "Self diagnostic result" with CONSULT. Is the DTC detected? YES: Refer to " «DIAGNOSIS PROCEDURE»(ref-672616-S35827524132014112400000) ". NO: INSPECTION END

Diagnosis Procedure

Refer to " TROUBLE DIAGNOSIS FLOW CHART ".

DTC No.Trouble diagnosis nameDTC detecting conditionPossible cause
U1010CONTROL UNIT (CAN)When detecting error during the initial diagnosis of CAN controller of driver seat control unit.Driver seat control unit
  1. REPLACE DRIVER SEAT CONTROL UNIT When DTC [U1010] is detected, replace driver seat control unit. : Replace driver seat control unit. Refer to " «REMOVAL AND INSTALLATION»(ref-672616-S21943499772014112400000) ".
DTC No.Trouble diagnosis nameDTC detecting conditionPossible cause
B2112SEAT SLIDEThe driver seat control unit detects the output of sliding motor output terminal for 0.1 second or more even if the sliding switch is not input.Driver seat control unit Slide motor harness is shorted
  1. PERFORM DTC CONFIRMATION PROCEDURE Turn ignition switch ON. Check "Self diagnostic result" with CONSULT. Is the DTC detected? YES: Refer to " «DIAGNOSIS PROCEDURE»(ref-672616-S32435616492014112400000) ". NO: INSPECTION END
  1. CHECK SLIDING MOTOR CIRCUIT (POWER SHORT) Turn ignition switch OFF. Disconnect sliding motor connector and driver seat control unit connector. Check voltage between sliding motor harness connector and ground. (+) (-) Voltage (V) (Approx.) Sliding motor Connector Terminals B561 34 Ground 0 38 Is the inspection result normal? YES: GO TO 2. NO: Repair or replace harness or connector.
  2. CHECK DRIVER SEAT CONTROL UNIT OUTPUT SIGNAL Connect driver seat control unit connector. Check voltage between driver seat control unit harness connector and ground. (+) (-) Voltage (V) Driver seat control unit Connector Terminals B551 34 Ground 0 - 1 38 Is the inspection result normal? YES: GO TO 3. NO: Replace driver seat control unit. Refer to " «REMOVAL AND INSTALLATION»(ref-672616-S21943499772014112400000) ".
  3. CHECK INTERMITTENT INCIDENT Refer to " «INTERMITTENT INCIDENT»(ref-672611-S01525861502014112400000) ". : INSPECTION END
DTC No.Trouble diagnosis nameDTC detecting conditionPossible cause
B2113SEAT RECLININGThe driver seat control unit detects the output of reclining motor output terminal for 0.1 second or more even if the reclining switch is not input.Driver seat control unit Reclining motor harness is shorted
  1. PERFORM DTC CONFIRMATION PROCEDURE Turn ignition switch ON. Check "Self diagnostic result" with CONSULT. Is the DTC detected? YES: Refer to " «DIAGNOSIS PROCEDURE»(ref-672616-S38419027062014112400000) ". NO: INSPECTION END
  1. CHECK RECLINING MOTOR CIRCUIT (POWER SHORT) Turn ignition switch OFF. Disconnect reclining motor connector and driver seat control unit connector. Check voltage between reclining motor harness connector and ground. (+) (-) Voltage (V) (Approx.) Reclining motor Connector Terminals B554 35 Ground 0 39 Is the inspection result normal? YES: GO TO 2. NO: Repair or replace harness or connector.
  2. CHECK DRIVER SEAT CONTROL UNIT OUTPUT SIGNAL Connect driver seat control unit connector. Check voltage between driver seat control unit harness connector and ground. (+) (-) Voltage (V) Driver seat control unit Connector Terminals B551 35 Ground 0 - 1 39 Is the inspection result normal? YES: GO TO 3. NO: Replace driver seat control unit. Refer to " «REMOVAL AND INSTALLATION»(ref-672616-S21943499772014112400000) ".
  3. CHECK INTERMITTENT INCIDENT Refer to " «INTERMITTENT INCIDENT»(ref-672611-S01525861502014112400000) ". : INSPECTION END
DTC No.Trouble diagnosis nameDTC detecting conditionPossible cause
B2128UART COMMThe communication between driver seat control unit and auto drive positioner control unit is interrupted for a period of time.UART communication line (UART communication line is open or shorted) Driver seat control unit Automatic drive positioner control unit
  1. PERFORM DTC CONFIRMATION PROCEDURE Turn ignition switch ON. Check "Self diagnostic result" with CONSULT. Is the DTC detected? YES: Refer to " «DIAGNOSIS PROCEDURE»(ref-672616-S03919858202014112400000) ". NO: INSPECTION END
  1. CHECK UART COMMUNICATION LINE CONTINUITY Turn ignition switch OFF. Disconnect driver seat control unit connector and automatic drive positioner control unit connector. Check continuity between driver seat control unit harness connector and automatic drive positioner control unit harness connector. Driver seat control unit Automatic drive positioner control unit Continuity Connector Terminal Connector Terminal B552 2 M75 8 Existed Check continuity between driver seat control unit harness connector and ground. Driver seat control unit Ground Continuity Connector Terminal B552 2 Not existed Is the inspection result normal? YES: Check intermittent incident. Refer to " «INTERMITTENT INCIDENT»(ref-672611-S01525861502014112400000) ". NO: Repair or replace harness or connector.
DTC No.Trouble diagnosis nameDTC detecting conditionPossible cause
B2130EEPROMDriver seat control unit detected CPU malfunction.Driver seat control unit
  1. PERFORM DTC CONFIRMATION PROCEDURE Turn ignition switch ON. Check "Self diagnostic result" with CONSULT. Is the DTC detected? YES: Refer to " «DIAGNOSIS PROCEDURE»(ref-672616-S33799642762014112400000) ". NO: INSPECTION END
  1. REPLACE DRIVER SEAT CONTROL UNIT Replace driver seat control unit. Refer to " «REMOVAL AND INSTALLATION»(ref-672616-S21943499772014112400000) ". : INSPECTION END

DRIVER SEAT CONTROL UNIT: Diagnosis Procedure

Note. Do not disconnect the battery negative terminal and the driver seat control unit connector until DTC is confirmed with CONSULT.

  1. CHECK FUSIBLE LINK Check that the following fusible link is not fusing. Signal name Fusible link No. Battery power supply L (40 A) Is the inspection result normal? YES: GO TO 2. NO: Replace the blown fuse after repairing affected circuit.
  2. CHECK DRIVER SEAT CONTROL UNIT POWER SUPPLY Turn ignition switch OFF. Disconnect driver seat control unit connector. Check voltage between driver seat control unit harness connector and ground. (+) (-) Voltage (V) Driver seat control unit Connector Terminals B551 33 Ground 9 - 16 Is the inspection result normal? YES: GO TO 3. NO-1: Repair or replace harness between driver seat control unit and fusible link L (40 A). NO-2: Check circuit breaker and replace it if necessary.
  3. CHECK DRIVER SEAT CONTROL UNIT GROUND CIRCUIT Check continuity between the driver seat control unit harness connector and ground. Driver seat control unit Ground Continuity Connector Terminal B551 43 Existed Is the inspection result normal? YES: INSPECTION END NO: Repair or replace harness.

Note. Do not disconnect the battery negative terminal and the driver seat control unit connector until DTC is confirmed with CONSULT.

  1. CHECK FUSIBLE LINK Check that the following fusible link is not fusing. Signal name Fusible link No. Battery power supply L (40 A) Is the inspection result normal? YES: GO TO 2. NO: Replace the blown fuse after repairing the affected circuit.
  2. CHECK AUTOMATIC DRIVE POSITIONER CONTROL UNIT POWER SUPPLY Turn ignition switch OFF. Disconnect automatic drive positioner control unit connector. Check voltage between automatic drive positioner control unit harness connector and ground. (+) (-) Voltage (V) Automatic drive positioner control unit Connector Terminals M104 25 Ground 9 - 16 Is the inspection result normal? YES: GO TO 3. NO-1: Repair or replace harness between driver seat control unit and fusible link L (40 A). NO-2: Check circuit breaker and replace it if necessary.
  3. CHECK AUTOMATIC DRIVE POSITIONER CONTROL UNIT GROUND CIRCUIT Check continuity between the automatic drive positioner control unit harness connector and ground. Automatic drive positioner control unit Ground Continuity Connector Terminal M104 30 Existed Is the inspection result normal? YES: INSPECTION END NO: Repair or replace harness.
  1. CHECK SLIDING SWITCH INPUT SIGNAL Turn ignition switch OFF. Disconnect power seat switch connector. Turn ignition switch ON. Check voltage between power seat switch harness connector and ground. (+) (-) Voltage (V) Power seat switch Connector Terminals B559 8 Ground 9 - 16 24 Is the inspection result normal? YES: GO TO 3 . NO: GO TO 2.
  2. CHECK SLIDING SWITCH CIRCUIT Turn ignition switch OFF. Disconnect driver seat control unit connector. Check continuity between driver seat control unit harness connector and power seat switch harness connector. Driver seat control unit Power seat switch Continuity Connector Terminal Connector Terminal B552 8 B559 8 Existed 24 24 Check continuity between driver seat control unit harness connector and ground. Driver seat control unit Ground Continuity Connector Terminal B552 8 Not existed 24 Is the inspection result normal? YES: Replace driver seat control unit. Refer to " «REMOVAL AND INSTALLATION»(ref-672616-S21943499772014112400000) ". NO: Repair or replace harness or connector.
  3. CHECK SLIDING SWITCH Refer to " «COMPONENT INSPECTION»(ref-672616-S22648232362014112400000) ". Is the inspection result normal? YES: Check intermittent incident. Refer to " «INTERMITTENT INCIDENT»(ref-672611-S01525861502014112400000) ". NO: Replace power seat switch. Refer to " «REMOVAL AND INSTALLATION»(ref-672616-S02058311292014112400000) ".

Component Inspection

  1. CHECK SLIDING SWITCH Turn ignition switch OFF. Disconnect power seat switch (sliding switch) connector. Check continuity between power seat switch (sliding switch) terminals under the following conditions. Power seat switch (Sliding switch) Condition Continuity Terminal 8 43 Sliding switch (backward) Operate Existed Release Not existed 24 Sliding switch (forward) Operate Existed Release Not existed Is the inspection result normal? YES: INSPECTION END NO: Replace power seat switch. Refer to " «REMOVAL AND INSTALLATION»(ref-672616-S02058311292014112400000) ".
  1. CHECK RECLINING SWITCH INPUT SIGNAL Turn ignition switch OFF. Disconnect power seat switch connector. Turn ignition switch ON. Check voltage between power seat switch harness connector and ground. (+) (-) Voltage (V) Power seat switch Connector Terminals B559 9 Ground 9 - 16 25 Is the inspection result normal? YES: GO TO 3 . NO: GO TO 2.
  2. CHECK RECLINING SWITCH CIRCUIT Turn ignition switch OFF. Disconnect driver seat control unit connector. Check continuity between driver seat control unit harness connector and power seat switch harness connector. Driver seat control unit Power seat switch Continuity Connector Terminal Connector Terminal B552 9 B559 9 Existed 25 25 Check continuity between driver seat control unit harness connector and ground. Driver seat control unit Ground Continuity Connector Terminal B552 9 Not existed 25 Is the inspection result normal? YES: Replace driver seat control unit. Refer to " «REMOVAL AND INSTALLATION»(ref-672616-S21943499772014112400000) ". NO: Repair or replace harness or connector.
  3. CHECK RECLINING SWITCH Refer to " «COMPONENT INSPECTION»(ref-672616-S36434866152014112400000) ". Is the inspection result normal? YES: Check intermittent incident. Refer to " «INTERMITTENT INCIDENT»(ref-672611-S01525861502014112400000) ". NO: Replace power seat switch. Refer to " «REMOVAL AND INSTALLATION»(ref-672616-S02058311292014112400000) ".
  1. CHECK RECLINING SWITCH Turn ignition switch OFF. Disconnect power seat switch (reclining switch) connector. Check continuity between power seat switch (reclining switch) terminals under the following conditions. Power seat switch (Reclining switch) Condition Continuity Terminal 9 43 Reclining switch (backward) Operate Existed Release Not existed 25 Reclining switch (forward) Operate Existed Release Not existed Is the inspection result normal? YES: INSPECTION END NO: Replace power seat switch. Refer to " «REMOVAL AND INSTALLATION»(ref-672616-S02058311292014112400000) ".
  1. CHECK LIFTING SWITCH (FRONT) INPUT SIGNAL Turn ignition switch OFF. Disconnect power seat switch connector. Turn ignition switch ON. Check voltage between power seat switch harness connector and ground. (+) (-) Voltage (V) Power seat switch Connector Terminals B559 10 Ground 9 - 16 26 Is the inspection result normal? YES: GO TO 3 . NO: GO TO 2.
  2. CHECK LIFTING SWITCH (FRONT) CIRCUIT Turn ignition switch OFF. Disconnect driver seat control unit connector. Check continuity between driver seat control unit harness connector and power seat switch harness connector. Driver seat control unit Power seat switch Continuity Connector Terminal Connector Terminal B552 10 B559 10 Existed 26 26 Check continuity between driver seat control unit harness connector and ground. Driver seat control unit Ground Continuity Connector Terminal B552 10 Not existed 26 Is the inspection result normal? YES: Replace driver seat control unit. Refer to " «REMOVAL AND INSTALLATION»(ref-672616-S21943499772014112400000) ". NO: Repair or replace harness or connector.
  3. CHECK LIFTING SWITCH (FRONT) Refer to " «COMPONENT INSPECTION»(ref-672616-S14738202742014112400000) ". Is the inspection result normal? YES: Check intermittent incident. Refer to " «INTERMITTENT INCIDENT»(ref-672611-S01525861502014112400000) ". NO: Replace power seat switch. Refer to " «REMOVAL AND INSTALLATION»(ref-672616-S02058311292014112400000) ".
  1. CHECK LIFTING SWITCH (FRONT) Turn ignition switch OFF. Disconnect power seat switch (lifting switch front) connector. Check continuity between power seat switch (lifting switch front) terminals under the following conditions. Power seat switch (lifting switch front) Condition Continuity Terminal 10 43 Lifting switch front (down) Operate Existed Release Not existed 26 Lifting switch front (up) Operate Existed Release Not existed Is the inspection result normal? YES: INSPECTION END NO: Replace power seat switch. Refer to " «REMOVAL AND INSTALLATION»(ref-672616-S02058311292014112400000) ".
  1. CHECK LIFTING SWITCH (REAR) INPUT SIGNAL Turn ignition switch OFF. Disconnect power seat switch connector. Turn ignition switch ON. Check voltage between power seat switch harness connector and ground. (+) (-) Voltage (V) Power seat switch Connector Terminals B559 11 Ground 9 - 16 27 Is the inspection result normal? YES: GO TO 3 . NO: GO TO 2.
  2. CHECK LIFTING SWITCH (REAR) CIRCUIT Turn ignition switch OFF. Disconnect driver seat control unit connector. Check continuity between driver seat control unit harness connector and power seat switch harness connector. Driver seat control unit Power seat switch Continuity Connector Terminal Connector Terminal B552 11 B559 11 Existed 27 27 Check continuity between driver seat control unit harness connector and ground. Driver seat control unit Ground Continuity Connector Terminal B552 11 Not existed 27 Is the inspection result normal? YES: Replace driver seat control unit. Refer to " «REMOVAL AND INSTALLATION»(ref-672616-S21943499772014112400000) ". NO: Repair or replace harness or connector.
  3. CHECK LIFTING SWITCH (REAR) Refer to " «COMPONENT INSPECTION»(ref-672616-S01788745762014112400000) ". Is the inspection result normal? YES: Check intermittent incident. Refer to " «INTERMITTENT INCIDENT»(ref-672611-S01525861502014112400000) ". NO: Replace power seat switch. Refer to " «REMOVAL AND INSTALLATION»(ref-672616-S02058311292014112400000) ".
  1. CHECK LIFTING SWITCH (REAR) Turn ignition switch OFF. Disconnect power seat switch (lifting switch rear) connector. Check continuity between power seat switch (lifting switch rear) terminals under the following conditions. Power seat switch (lifting switch rear) Condition Continuity Terminal 11 43 Lifting switch rear (down) Operate Existed Release Not existed 27 Lifting switch rear (up) Operate Existed Release Not existed Is the inspection result normal? YES: INSPECTION END NO: Replace power seat switch. Refer to " «REMOVAL AND INSTALLATION»(ref-672616-S02058311292014112400000) ".
  1. CHECK SEAT MEMORY SWITCH INPUT SIGNAL Turn ignition switch OFF. Disconnect seat memory switch connector. Turn ignition switch ON. Check voltage between seat memory switch harness connector and ground. (+) (-) Voltage (V) Seat memory switch Connector Terminals D13 1 Ground 4 - 6 2 3 Is the inspection result normal? YES: GO TO 3 . NO: GO TO 2.
  2. CHECK SEAT MEMORY SWITCH CIRCUIT Turn ignition switch OFF. Disconnect driver seat control unit connector. Check continuity between driver seat control unit harness connector and seat memory switch harness connector. Driver seat control unit Seat memory switch Continuity Connector Terminal Connector Terminal B552 6 D13 2 Existed 22 1 28 3 Check continuity between driver seat control unit harness connector and ground. Driver seat control unit Ground Continuity Connector Terminal B552 6 Not existed 22 28 Is the inspection result normal? YES: Replace driver seat control unit. Refer to " «REMOVAL AND INSTALLATION»(ref-672616-S21943499772014112400000) ". NO: Repair or replace harness or connector.
  3. CHECK SEAT MEMORY SWITCH GROUND CIRCUIT Check continuity between seat memory switch harness connector and ground. Seat memory switch Ground Continuity Connector Terminal D13 4 Existed Is the inspection result normal? YES: GO TO 4. NO: Repair or replace harness or connector.
  4. CHECK SEAT MEMORY SWITCH Refer to " «COMPONENT INSPECTION»(ref-672616-S24662670282014112400000) ". Is the inspection result normal? YES: Check intermittent incident. Refer to " «INTERMITTENT INCIDENT»(ref-672611-S01525861502014112400000) ". NO: Replace seat memory switch. Refer to " «REMOVAL AND INSTALLATION»(ref-672616-S06362709872014112400000) ".
  1. CHECK SEAT MEMORY SWITCH Turn ignition switch OFF. Disconnect seat memory switch connector. Check continuity between seat memory switch terminals under the following conditions. Seat memory switch Condition Continuity Terminal 1 4 Memory switch 1 Push Existed Release Not existed 2 Memory switch 2 Push Existed Release Not existed 3 Set switch Push Existed Release Not existed Is the inspection result normal? YES: INSPECTION END NO: Replace seat memory switch. Refer to " «REMOVAL AND INSTALLATION»(ref-672616-S06362709872014112400000) ".

MIRROR SWITCH: Diagnosis Procedure

  1. CHECK MIRROR SWITCH INPUT SIGNAL Turn ignition switch OFF. Disconnect door mirror remote control switch connector. Turn ignition switch ON. Check voltage between door mirror remote control switch harness connector and ground. (+) (-) Voltage (V) Door mirror remote control switch Connector Terminal D14 4 Ground 4 - 6 12 13 15 Is the inspection result normal? YES: GO TO 3 . NO: GO TO 2.
  2. CHECK MIRROR SWITCH CIRCUIT Turn ignition switch OFF. Disconnect automatic drive positioner control unit connector. Check continuity between automatic drive positioner control unit harness connector and door mirror remote control switch harness connector. Automatic drive positioner control unit Door mirror remote control switch Continuity Connector Terminal Connector Terminal M75 3 D14 15 Existed 4 13 15 12 16 4 Check continuity between automatic drive positioner control unit harness connector and ground. Automatic drive positioner control unit Ground Continuity Connector Terminal M75 3 Not existed 4 15 16 Is the inspection result normal? YES: Replace automatic drive positioner control unit. Refer to " «REMOVAL AND INSTALLATION»(ref-672616-S08987302212014112400000) ". NO: Repair or replace harness.
  3. CHECK DOOR MIRROR REMOTE CONTROL SWITCH GROUND CIRCUIT Turn ignition switch OFF. Check continuity between door mirror remote control switch harness connector and ground. Door mirror remote control switch Ground Continuity Connector Terminal D14 7 Existed Is the inspection result normal? YES: GO TO 4. NO: Repair or replace harness.
  4. CHECK MIRROR SWITCH Check door mirror remote control switch. Refer to " «MIRROR SWITCH: COMPONENT INSPECTION»(ref-672616-S17252681552014112400000) ". Is the inspection result normal? YES: Check intermittent incident. Refer to " «INTERMITTENT INCIDENT»(ref-672611-S01525861502014112400000) ". NO: Replace door mirror remote control switch.

MIRROR SWITCH: Component Inspection

  1. CHECK MIRROR SWITCH Turn ignition switch OFF. Disconnect door mirror remote control switch connector. Check continuity between door mirror remote control switch terminals under the following conditions. Door mirror remote control switch Condition Continuity Terminal 4 7 Mirror switch RIGHT Existed Other than the above Not existed 12 DOWN Existed Other than the above Not existed 13 LEFT Existed Other than the above Not existed 15 UP Existed Other than the above Not existed Is the inspection result normal? YES: INSPECTION END NO: Replace door mirror remote control switch.

CHANGEOVER SWITCH: Diagnosis Procedure

  1. CHECK CHANGEOVER SWITCH INPUT SIGNAL Turn ignition switch OFF. Disconnect door mirror remote control switch connector. Turn ignition switch ON. Check voltage between door mirror remote control switch harness connector and ground. (+) (-) Voltage (V) Door mirror remote control switch Connector Terminal D14 10 Ground 4 - 6 11 Is the inspection result normal? YES: GO TO 3 . NO: GO TO 2.
  2. CHECK CHANGEOVER SWITCH CIRCUIT Turn ignition switch OFF. Disconnect automatic drive positioner control unit connector. Check continuity between automatic drive positioner control unit harness connector and door mirror remote control switch harness connector. Automatic drive positioner control unit Door mirror remote control switch Continuity Connector Terminal Connector Terminal M75 2 D14 11 Existed 14 10 Check continuity between automatic drive positioner control unit harness connector and ground. Automatic drive positioner control unit Ground Continuity Connector Terminal M75 2 Not existed 14 Is the inspection result normal? YES: Replace automatic drive positioner control unit. Refer to " «REMOVAL AND INSTALLATION»(ref-672616-S08987302212014112400000) ". NO: Repair or replace harness.
  3. CHECK DOOR MIRROR REMOTE CONTROL SWITCH GROUND CIRCUIT Turn ignition switch OFF. Check continuity between door mirror remote control switch harness connector and ground. Door mirror remote control switch Ground Continuity Connector Terminal D14 7 Existed Is the inspection result normal? YES: GO TO 4. NO: Repair or replace harness.
  4. CHECK CHANGEOVER SWITCH Check door mirror remote control switch. Refer to " «CHANGEOVER SWITCH: COMPONENT INSPECTION»(ref-672616-S39862219032014112400000) ". Is the inspection result normal? YES: Check intermittent incident. Refer to " «INTERMITTENT INCIDENT»(ref-672611-S01525861502014112400000) ". NO: Replace door mirror remote control switch.

CHANGEOVER SWITCH: Component Inspection

  1. CHECK CHANGEOVER SWITCH Turn ignition switch OFF. Disconnect door mirror remote control switch connector. Check continuity between door mirror remote control switch terminals under the following conditions. Door mirror remote control switch Condition Continuity Terminal 10 7 Changeover switch LEFT Existed Other than the above Not existed 11 RIGHT Existed Other than the above Not existed Is the inspection result normal? YES: INSPECTION END NO: Replace door mirror remote control switch.
  1. CHECK POWER SEAT SWITCH GROUND CIRCUIT Turn ignition switch OFF. Disconnect power seat switch connector. Check continuity between power seat switch harness connector and ground. Power seat switch Ground Continuity Connector Terminal B559 43 Existed Is the inspection result normal? YES: Check intermittent incident. Refer to " «INTERMITTENT INCIDENT»(ref-672611-S01525861502014112400000) ". NO: Repair or replace harness or connector.
  1. CHECK SLIDING SENSOR SIGNAL Turn ignition switch ON. Check signal between driver seat control unit harness connector and ground using an oscilloscope. (+) (-) Condition Signal (V) (Reference value) Driver seat control unit Connector Terminals B552 18 Ground Seat sliding Operate Other than the above 0 - 1 or 4 - 6 Is the inspection result normal? YES: Replace driver seat control unit. Refer to " «REMOVAL AND INSTALLATION»(ref-672616-S21943499772014112400000) ". NO: GO TO 2.
  2. CHECK SLIDING SENSOR CIRCUIT Turn ignition switch OFF. Disconnect driver seat control unit connector and sliding sensor connector. Check continuity between driver seat control unit harness connector and sliding sensor harness connector. Driver seat control unit Sliding motor Continuity Connector Terminal Connector Terminal B552 18 B561 18 Existed Check continuity between driver seat control unit harness connector and ground. Driver seat control unit Ground Continuity Connector Terminal B552 18 Not existed Is the inspection result normal? YES: GO TO 3. NO: Repair or replace harness or connector.
  3. CHECK SLIDING SENSOR POWER SUPPLY Connect driver seat control unit connector. Turn ignition switch ON. Check voltage between sliding motor harness connector and ground. (+) (-) Voltage (V) Sliding motor Connector Terminals B561 12 Ground 9 - 16 Is the inspection result normal? YES: GO TO 5 . NO: GO TO 4.
  4. CHECK SLIDING SENSOR POWER SUPPLY CIRCUIT Turn ignition switch OFF. Disconnect driver seat control unit connector. Check continuity between driver seat control unit harness connector and sliding motor harness connector. Driver seat control unit Sliding motor Continuity Connector Terminal Connector Terminal B552 12 B561 12 Existed Check continuity between driver seat control unit harness connector and ground. Driver seat control unit Ground Continuity Connector Terminal B552 12 Not existed Is the inspection result normal? YES: Replace driver seat control unit. Refer to " «REMOVAL AND INSTALLATION»(ref-672616-S21943499772014112400000) ". NO: Repair or replace harness or connector.
  5. CHECK SLIDING SENSOR GROUND CIRCUIT Turn ignition switch OFF. Check continuity between sliding motor harness connector and ground. Sliding motor Ground Continuity Connector Terminal B561 43 Existed Is the inspection result normal? YES: Replace sliding motor. NO: Repair or replace harness or connector.
  1. CHECK RECLINING SENSOR SIGNAL Turn ignition switch ON. Check signal between driver seat control unit harness connector and ground using an oscilloscope. (+) (-) Condition Signal (V) (Reference value) Driver seat control unit Connector Terminals B552 4 Ground Seat reclining Operate Other than the above 0 - 1 or 4 - 6 Is the inspection result normal? YES: Replace driver seat control unit. Refer to " «REMOVAL AND INSTALLATION»(ref-672616-S21943499772014112400000) ". NO: GO TO 2.
  2. CHECK RECLINING SENSOR CIRCUIT Turn ignition switch OFF. Disconnect driver seat control unit connector and reclining motor connector. Check continuity between driver seat control unit harness connector and reclining motor harness connector. Driver seat control unit Reclining motor Continuity Connector Terminal Connector Terminal B552 4 B554 4 Existed Check continuity between driver seat control unit harness connector and ground. Driver seat control unit Ground Continuity Connector Terminal B552 4 Not existed Is the inspection result normal? YES: GO TO 3. NO: Repair or replace harness or connector.
  3. CHECK RECLINING SENSOR POWER SUPPLY Connect driver seat control unit connector. Turn ignition switch ON. Check voltage between reclining motor harness connector and ground. (+) (-) Voltage (V) Reclining motor Connector Terminals B554 12 Ground 9 - 16 Is the inspection result normal? YES: GO TO 5 . NO: GO TO 4.
  4. CHECK RECLINING SENSOR POWER SUPPLY CIRCUIT Turn ignition switch OFF. Disconnect driver seat control unit connector. Check continuity between driver seat control unit harness connector and reclining motor harness connector. Driver seat control unit Reclining motor Continuity Connector Terminal Connector Terminal B552 12 B554 12 Existed Check continuity between driver seat control unit harness connector and ground. Driver seat control unit Ground Continuity Connector Terminal B552 12 Not existed Is the inspection result normal? YES: Replace driver seat control unit. Refer to " «REMOVAL AND INSTALLATION»(ref-672616-S21943499772014112400000) ". NO: Repair or replace harness or connector.
  5. CHECK RECLINING SENSOR GROUND CIRCUIT Turn ignition switch OFF. Check continuity between reclining motor harness connector and ground. Reclining motor Ground Continuity Connector Terminal B554 43 Existed Is the inspection result normal? YES: Replace reclining motor. NO: Repair or replace harness or connector.
  1. CHECK LIFTING SENSOR (FRONT) SIGNAL Turn ignition switch ON. Check signal between driver seat control unit harness connector and ground using an oscilloscope. (+) (-) Condition Signal (V) (Reference value) Driver seat control unit Connector Terminals B552 19 Ground Seat Lifting (front) Operate Other than the above 0 - 1 or 4 - 6 Is the inspection result normal? YES: Replace driver seat control unit. Refer to " «REMOVAL AND INSTALLATION»(ref-672616-S21943499772014112400000) ". NO: GO TO 2.
  2. CHECK LIFTING SENSOR (FRONT) CIRCUIT Turn ignition switch OFF. Disconnect driver seat control unit connector and lifting motor (front) connector. Check continuity between driver seat control unit harness connector and lifting motor (front) harness connector. Driver seat control unit Lifting motor (front) Continuity Connector Terminal Connector Terminal B552 19 B555 19 Existed Check continuity between driver seat control unit harness connector and ground. Driver seat control unit Ground Continuity Connector Terminal B552 19 Not existed Is the inspection result normal? YES: GO TO 3. NO: Repair or replace harness or connector.
  3. CHECK LIFTING SENSOR (FRONT) POWER SUPPLY Connect driver seat control unit connector. Turn ignition switch ON. Check voltage between lifting motor (front) harness connector and ground. (+) (-) Voltage (V) Lifting motor (front) Connector Terminals B555 12 Ground 9 - 16 Is the inspection result normal? YES: GO TO 5 . NO: GO TO 4.
  4. CHECK LIFTING SENSOR (FRONT) POWER SUPPLY CIRCUIT Turn ignition switch OFF. Disconnect driver seat control unit connector. Check continuity between driver seat control unit harness connector and lifting motor (front) harness connector. Driver seat control unit Lifting motor (front) Continuity Connector Terminal Connector Terminal B552 12 B555 12 Existed Check continuity between driver seat control unit harness connector and ground. Driver seat control unit Ground Continuity Connector Terminal B552 12 Not existed Is the inspection result normal? YES: Replace driver seat control unit. Refer to " «REMOVAL AND INSTALLATION»(ref-672616-S21943499772014112400000) ". NO: Repair or replace harness or connector.
  5. CHECK LIFTING SENSOR (FRONT) GROUND CIRCUIT Turn ignition switch OFF. Check continuity between lifting motor (front) harness connector and ground. Lifting motor (front) Ground Continuity Connector Terminal B555 43 Existed Is the inspection result normal? YES: Replace lifting motor (front). NO: Repair or replace harness or connector.
  1. CHECK LIFTING SENSOR (REAR) SIGNAL Turn ignition switch ON. Check signal between driver seat control unit harness connector and ground using an oscilloscope. (+) (-) Condition Signal (V) (Reference value) Driver seat control unit Connector Terminals B552 20 Ground Seat Lifting (rear) Operate Other than the above 0 - 1 or 4 - 6 Is the inspection result normal? YES: Replace driver seat control unit. Refer to " «REMOVAL AND INSTALLATION»(ref-672616-S21943499772014112400000) ". NO: GO TO 2.
  2. CHECK LIFTING SENSOR (REAR) CIRCUIT Turn ignition switch OFF. Disconnect driver seat control unit connector and lifting motor (rear) connector. Check the continuity between driver seat control unit harness connector and lifting motor (rear) harness connector. Driver seat control unit Lifting motor (rear) Continuity Connector Terminal Connector Terminal B552 20 B556 20 Existed Check the continuity between driver seat control unit harness connector and ground. Driver seat control unit Ground Continuity Connector Terminal B552 20 Not existed Is the inspection result normal? YES: GO TO 3. NO: Repair or replace harness or connector.
  3. CHECK LIFTING SENSOR (REAR) POWER SUPPLY Connect driver seat control unit connector. Turn ignition switch ON. Check the voltage between lifting motor (rear) harness connector and ground. (+) (-) Voltage (V) Lifting motor (rear) Connector Terminals B556 12 Ground 9 - 16 Is the inspection result normal? YES: GO TO 5 . NO: GO TO 4.
  4. CHECK LIFTING SENSOR (REAR) POWER SUPPLY CIRCUIT Turn ignition switch OFF. Disconnect driver seat control unit connector. Check the continuity between driver seat control unit harness connector and lifting motor (rear) harness connector. Driver seat control unit Lifting motor (rear) Continuity Connector Terminal Connector Terminal B552 12 B556 12 Existed Check the continuity between driver seat control unit harness connector and ground. Driver seat control unit Ground Continuity Connector Terminal B552 12 Not existed Is the inspection result normal? YES: Replace driver seat control unit. Refer to " «REMOVAL AND INSTALLATION»(ref-672616-S21943499772014112400000) ". NO: Repair or replace harness or connector.
  5. CHECK LIFTING SENSOR (REAR) GROUND CIRCUIT Turn ignition switch OFF. Check the continuity between lifting motor (rear) harness connector and ground. Lifting motor (rear) Ground Continuity Connector Terminal B556 43 Existed Is the inspection result normal? YES: Replace lifting motor (rear). NO: Repair or replace harness or connector.

DRIVER SIDE: Diagnosis Procedure

  1. CHECK DOOR MIRROR (DRIVER SIDE) SENSOR POWER SUPPLY Turn ignition switch OFF. Disconnect door mirror (driver side) connector. Turn ignition switch ON. Check voltage between door mirror (driver side) harness connector and ground. (+) (-) Voltage (V) Door mirror (driver side) Connector Terminals D43 23 Ground 4 - 6 Is the inspection result normal? YES: GO TO 3 . NO: GO TO 2.
  2. CHECK DOOR MIRROR (DRIVER SIDE) SENSOR POWER SUPPLY CIRCUIT Turn ignition switch OFF. Disconnect automatic drive positioner control unit connector. Check continuity between automatic drive positioner control unit harness connector and door mirror (driver side) harness connector. Automatic drive positioner control unit Door mirror (driver side) Continuity Connector Terminal Connector Terminal M75 21 D43 23 Existed Check continuity between automatic drive positioner control unit harness connector and ground. Automatic drive positioner control unit Ground Continuity Connector Terminal M75 21 Not existed Is the inspection result normal? YES: Replace automatic drive positioner control unit. Refer to " «REMOVAL AND INSTALLATION»(ref-672616-S08987302212014112400000) ". NO: Repair or replace harness or connector.
  3. CHECK DOOR MIRROR (DRIVER SIDE) SENSOR GROUND CIRCUIT Turn ignition switch OFF. Disconnect automatic drive positioner control unit connector. Check continuity between automatic drive positioner control unit harness connector and door mirror (driver side) harness connector. Automatic drive positioner control unit Door mirror (driver side) Continuity Connector Terminal Connector Terminal M75 20 D43 24 Existed Check continuity between automatic drive positioner control unit harness connector and ground. Automatic drive positioner control unit Ground Continuity Connector Terminal M75 20 Not existed Is the inspection result normal? YES: GO TO 4. NO: Repair or replace harness or connector.
  4. CHECK DOOR MIRROR (DRIVER SIDE) SENSOR CIRCUIT Check continuity between automatic drive positioner control unit harness connector and door mirror (driver side) harness connector. Automatic drive positioner control unit Door mirror (driver side) Continuity Connector Terminal Connector Terminal M75 6 D43 21 Existed 18 22 Check continuity between automatic drive positioner control unit harness connector and ground. Automatic drive positioner control unit Ground Continuity Connector Terminal M75 6 Not existed 18 Is the inspection result normal? YES: Replace door mirror sensor (built in driver side door mirror). NO: Repair or replace harness or connector.

PASSENGER SIDE: Diagnosis Procedure

  1. CHECK DOOR MIRROR SENSOR (PASSENGER SIDE) POWER SUPPLY Turn ignition switch OFF. Disconnect door mirror (passenger side) connector. Turn ignition switch ON. Check voltage between door mirror (passenger side) harness connector and ground. (+) (-) Voltage (V) Door mirror (passenger side) Connector Terminals D3 23 Ground 4 - 6 Is the inspection result normal? YES: GO TO 3 . NO: GO TO 2.
  2. CHECK DOOR MIRROR (PASSENGER SIDE) SENSOR POWER SUPPLY CIRCUIT Turn ignition switch OFF. Disconnect automatic drive positioner control unit connector. Check continuity between automatic drive positioner control unit harness connector and door mirror (passenger side) harness connector. Automatic drive positioner control unit Door mirror (passenger side) Continuity Connector Terminal Connector Terminal M75 21 D3 23 Existed Check continuity between automatic drive positioner control unit harness connector and ground. Automatic drive positioner control unit Ground Continuity Connector Terminal M75 21 Not existed Is the inspection result normal? YES: Replace automatic drive positioner control unit. Refer to " «REMOVAL AND INSTALLATION»(ref-672616-S08987302212014112400000) ". NO: Repair or replace harness or connector.
  3. CHECK DOOR MIRROR (PASSENGER SIDE) SENSOR GROUND CIRCUIT Turn ignition switch OFF. Disconnect automatic drive positioner control unit connector. Check continuity between automatic drive positioner control unit harness connector and door mirror (passenger side) connector. Automatic drive positioner control unit Door mirror (passenger side) Continuity Connector Terminal Connector Terminal M75 20 D3 24 Existed Check continuity between automatic drive positioner control unit harness connector and ground. Automatic drive positioner control unit Ground Continuity Connector Terminal M75 20 Not existed Is the inspection result normal? YES: GO TO 4. NO: Repair or replace harness or connector.
  4. CHECK DOOR MIRROR (PASSENGER SIDE) SENSOR CIRCUIT Check continuity between automatic drive positioner control unit harness connector and door mirror (passenger side) harness connector. Automatic drive positioner control unit Door mirror (passenger side) Continuity Connector Terminal Connector Terminal M75 5 D3 21 Existed 17 22 Check continuity between automatic drive positioner control unit harness connector and ground. Automatic drive positioner control unit Ground Continuity Connector Terminal M75 5 Not existed 17 Is the inspection result normal? YES: Replace door mirror sensor (built in passenger side door mirror). NO: Repair or replace harness or connector.
  1. CHECK SLIDING MOTOR INPUT SIGNAL Turn ignition switch OFF. Disconnect sliding motor connector. Turn ignition switch ON. Perform " «ACTIVE TEST»(ref-672616-S19256962252014112400000) " ("SEAT SLIDE") with CONSULT. Check voltage between sliding motor harness connector and ground. (+) (-) Condition Voltage (V) Sliding motor Connector Terminals B561 34 Ground SEAT SLIDE OFF 0 - 1 Backward 9 - 16 38 OFF 0 - 1 Forward 9 - 16 Is the inspection result normal? YES: Replace sliding motor (built in seat slide cushion frame). NO: GO TO 2.
  2. CHECK SLIDING MOTOR CIRCUIT Turn ignition switch OFF. Disconnect driver seat control unit connector. Check continuity between driver seat control unit harness connector and sliding motor harness connector. Driver seat control unit Sliding motor Continuity Connector Terminal Connector Terminal B551 34 B561 34 Existed 38 38 Check continuity between driver seat control unit harness connector and ground. Driver seat control unit Ground Continuity Connector Terminal B551 34 Not existed 38 Is the inspection result normal? YES: Replace driver seat control unit. Refer to " «REMOVAL AND INSTALLATION»(ref-672616-S21943499772014112400000) ". NO: Repair or replace harness or connector.
  1. CHECK RECLINING MOTOR INPUT SIGNAL Turn ignition switch OFF. Disconnect reclining motor connector. Turn ignition switch ON. Perform " «ACTIVE TEST»(ref-672616-S19256962252014112400000) " ("SEAT RECLINING") with CONSULT. Check voltage between reclining motor harness connector and ground. (+) (-) Condition Voltage (V) Reclining motor Connector Terminals B554 35 Ground SEAT RECLINING OFF 0 - 1 Forward 9 - 16 39 OFF 0 - 1 Backward 9 - 16 Is the inspection result normal? YES: Replace reclining motor (built in seat back frame). NO: GO TO 2.
  2. CHECK RECLINING MOTOR CIRCUIT Turn ignition switch OFF. Disconnect driver seat control unit connector. Check continuity between driver seat control unit harness connector and reclining motor harness connector. Driver seat control unit Reclining motor Continuity Connector Terminal Connector Terminal B551 35 B554 35 Existed 39 39 Check continuity between driver seat control unit harness connector and ground. Driver seat control unit Ground Continuity Connector Terminal B551 35 Not existed 39 Is the inspection result normal? YES: Replace driver seat control unit. Refer to " «REMOVAL AND INSTALLATION»(ref-672616-S21943499772014112400000) ". NO: Repair or replace harness or connector.
  1. CHECK LIFTING MOTOR (FRONT) INPUT SIGNAL Turn ignition switch OFF. Disconnect lifting motor (front) connector. Turn ignition switch ON. Perform " «ACTIVE TEST»(ref-672616-S19256962252014112400000) " ("SEAT LIFTER FR") with CONSULT. Check voltage between lifting motor (front) harness connector and ground. (+) (-) Condition Voltage (V) Lifting motor (front) Connector Terminals B555 36 Ground SEAT LIFTER FR OFF 0 - 1 Downward 9 - 16 40 OFF 0 - 1 Upward 9 - 16 Is the inspection result normal? YES: Replace lifting motor (front) (built in seat cushion frame). NO: GO TO 2.
  2. CHECK LIFTING MOTOR (FRONT) CIRCUIT Turn ignition switch OFF. Disconnect driver seat control unit connector. Check continuity between driver seat control unit harness connector and lifting motor (front) harness connector. Driver seat control unit Lifting motor (front) Continuity Connector Terminal Connector Terminal B551 36 B555 36 Existed 40 40 Check continuity between driver seat control unit harness connector and ground. Driver seat control unit Ground Continuity Connector Terminal B551 36 Not existed 40 Is the inspection result normal? YES: Replace driver seat control unit. Refer to " «REMOVAL AND INSTALLATION»(ref-672616-S21943499772014112400000) ". NO: Repair or replace harness or connector.
  1. CHECK LIFTING MOTOR (REAR) INPUT SIGNAL Turn ignition switch OFF. Disconnect lifting motor (rear) connector. Turn ignition switch ON. Perform " «ACTIVE TEST»(ref-672616-S19256962252014112400000) " ("SEAT LIFTER RR") with CONSULT. Check voltage between lifting motor (rear) harness connector and ground. (+) (-) Condition Voltage (V) Lifting motor (rear) Connector Terminals B556 41 Ground SEAT LIFTER RR OFF 0 - 1 Upward 9 - 16 42 OFF 0 - 1 Downward 9 - 16 Is the inspection result normal? YES: Replace lifting motor (rear) (built in seat cushion frame). NO: GO TO 2.
  2. CHECK LIFTING MOTOR (REAR) CIRCUIT Turn ignition switch OFF. Disconnect driver seat control unit connector. Check continuity between driver seat control unit harness connector and lifting motor (rear) harness connector. Driver seat control unit Lifting motor (rear) Continuity Connector Terminal Connector Terminal B551 41 B556 41 Existed 42 42 Check continuity between driver seat control unit harness connector and ground. Driver seat control unit Ground Continuity Connector Terminal B551 41 Not existed 42 Is the inspection result normal? YES: Replace driver seat control unit. Refer to " «REMOVAL AND INSTALLATION»(ref-672616-S21943499772014112400000) ". NO: Repair or replace harness or connector.
  1. CHECK DOOR MIRROR MOTOR INPUT SIGNAL Turn ignition switch OFF. Disconnect door mirror connector. Turn ignition switch ON. Check voltage between door mirror harness connector and ground. CONNECTOR PIN REFERENCE (+) (-) Condition Voltage (V) Door mirror Connector Terminals D43 10 Ground Door mirror remote control switch DOWN/RIGHT 9 - 16 Other than the above 0 - 1 11 LEFT 9 - 16 Other than the above 0 - 1 12 UP 9 - 16 Other than the above 0 - 1 CONNECTOR PIN REFERENCE (+) (-) Condition Voltage (V) Door mirror Connector Terminals D3 10 Ground Door mirror remote control switch DOWN/RIGHT 9 - 16 Other than the above 0 - 1 11 LEFT 9 - 16 Other than the above 0 - 1 12 UP 9 - 16 Other than the above 0 - 1 Is the inspection result normal? YES: GO TO 3 . NO: GO TO 2.
  2. CHECK DOOR MIRROR MOTOR CIRCUIT Turn ignition switch OFF. Disconnect automatic drive positioner control unit connector. Check continuity between automatic drive positioner control unit harness connector and door mirror harness connector. CONNECTOR PIN REFERENCE Automatic drive positioner control unit Door mirror Continuity Connector Terminal Connector Terminal M75 12 D43 10 Existed 23 12 24 11 CONNECTOR PIN REFERENCE Automatic drive positioner control unit Door mirror Continuity Connector Terminal Connector Terminal M75 10 D3 12 Existed 11 11 22 10 Check continuity between automatic drive positioner control unit harness connector and ground. CONNECTOR PIN REFERENCE Automatic drive positioner control unit Ground Continuity Connector Terminal M75 12 Not existed 23 24 CONNECTOR PIN REFERENCE Automatic drive positioner control unit Ground Continuity Connector Terminal M75 10 Not existed 11 22 Is the inspection result normal? YES: Replace automatic drive positioner control unit. Refer to " «REMOVAL AND INSTALLATION»(ref-672616-S08987302212014112400000) ". NO: Repair or replace harness or connector.
  3. CHECK DOOR MIRROR MOTOR Check door mirror motor. Refer to " «COMPONENT INSPECTION»(ref-672616-S42711894732014112400000) ". Is the inspection result normal? YES: Check intermittent incident. Refer to " «INTERMITTENT INCIDENT»(ref-672611-S01525861502014112400000) ". NO: Replace door mirror motor.
  1. CHECK DOOR MIRROR MOTOR 1 Check that door mirror motor does not trap foreign objects and does not have any damage. Refer to " «EXPLODED VIEW»(ref-672670-S05932929552014112400000) ". Is the inspection result normal? YES: GO TO 2. NO: Replace door mirror.
  2. CHECK DOOR MIRROR MOTOR 2 Turn ignition switch OFF. Disconnect door mirror connector. Apply 12 V to each power supply terminal of door mirror motor terminals. Door mirror Operational direction Terminal (+) (-) 10 11 RIGHT 11 10 LEFT 12 10 UP 10 12 DOWN Is the inspection result normal? YES: INSPECTION END NO: Replace door mirror motor.
  1. CHECK SEAT MEMORY SWITCH INDICATOR OPERATION Check seat memory switch indicator operation. Which is the malfunctioning indicator? All indicators are NG: GO TO 2. An indicator is NG: GO TO 4 .
  2. CHECK FUSE Turn ignition switch OFF. Check that the following fuse is not fusing. Signal name Fuse No. Battery power supply 10 (10 A) Is the inspection result normal? YES: GO TO 3. NO: Replace the blown fuse after repairing affected circuit.
  3. CHECK SEAT MEMORY SWITCH INDICATOR POWER SUPPLY Check voltage between seat memory switch harness connector and ground. (+) (-) Voltage (V) Seat memory switch Connector Terminals D13 5 Ground Battery voltage Is the inspection result normal? YES: Replace seat memory switch. Refer to " «REMOVAL AND INSTALLATION»(ref-672616-S06362709872014112400000) ". NO: Repair or replace harness between seat memory switch and 10 A fuse [No. 10, located in fuse block (J/B)].
  4. CHECK SEAT MEMORY SWITCH INDICATOR CIRCUIT Turn ignition switch OFF. Disconnect driver seat control unit and seat memory switch connector. Check continuity between driver seat control unit harness connector and seat memory switch harness connector. Driver seat control unit Seat memory switch Continuity Connector Terminal Connector Terminal B552 7 D13 7 Existed 23 6 Check continuity between driver seat control unit harness connector and ground. Driver seat control unit Ground Continuity Connector Terminal B552 7 Not existed 23 Is the inspection result normal? YES: Replace driver seat control unit. Refer to " «REMOVAL AND INSTALLATION»(ref-672616-S21943499772014112400000) ". NO: Repair or replace harness or connector.

ALL COMPONENT: Diagnosis Procedure

  1. CHECK DRIVER SEAT CONTROL UNIT POWER SUPPLY AND GROUND CIRCUIT Check driver seat control unit power supply and ground circuit. Refer to " «DRIVER SEAT CONTROL UNIT: DIAGNOSIS PROCEDURE»(ref-672616-S28568110712014112400000) ". Is the inspection result normal? YES: GO TO 2. NO: Repair or replace the malfunction parts.
  2. CHECK AUTOMATIC DRIVE POSITIONER CONTROL UNIT POWER SUPPLY AND GROUND CIRCUIT Check automatic drive positioner control unit power supply and ground circuit. Refer to " «AUTOMATIC DRIVE POSITIONER CONTROL UNIT: DIAGNOSIS PROCEDURE»(ref-672616-S29857255762014112400000) ". Is the inspection result normal? YES: GO TO 3. NO: Repair or replace the malfunction parts.
  3. CONFIRM THE OPERATION Confirm the operation again. Is the result normal? YES: Check intermittent incident. Refer to " «INTERMITTENT INCIDENT»(ref-672611-S01525861502014112400000) ". NO: GO TO 1 .

POWER SEAT: Diagnosis Procedure

  1. CHECK POWER SEAT SWITCH GROUND CIRCUIT Check power seat switch ground circuit. Refer to " «DIAGNOSIS PROCEDURE»(ref-672616-S09232200482014112400000) ". Is the inspection result normal? YES: GO TO 2. NO: Repair or replace harness or connector.
  2. CONFIRM THE OPERATION Confirm the operation again. Is the result normal? YES: Check intermittent incident. Refer to " «INTERMITTENT INCIDENT»(ref-672611-S01525861502014112400000) ". NO: GO TO 1 .

SEAT SLIDING: Diagnosis Procedure

  1. CHECK SLIDING MECHANISM Check for the following. Mechanism deformation or pinched foreign materials. Interference with other parts because of poor installation. Is the inspection result normal? YES: GO TO 2. NO: Repair or replace the malfunction parts.
  2. CHECK SLIDING SWITCH Check sliding switch. Refer to " «COMPONENT FUNCTION CHECK»(ref-672616-S28712816422014112400000) ". Is the inspection result normal? YES: GO TO 3. NO: Repair or replace the malfunction parts.
  3. CHECK SLIDING MOTOR Check sliding motor. Refer to " «COMPONENT FUNCTION CHECK»(ref-672616-S18324838442014112400000) ". Is the inspection result normal? YES: GO TO 4. NO: Repair or replace the malfunction parts.
  4. CONFIRM THE OPERATION Check the operation again. Is the result normal? YES: Check intermittent incident. Refer to " «INTERMITTENT INCIDENT»(ref-672611-S01525861502014112400000) ". NO: GO TO 1 .

SEAT RECLINING: Diagnosis Procedure

  1. CHECK RECLINING MECHANISM Check for the following. Mechanism deformation or pinched foreign materials. Interference with other parts because of poor installation. Is the inspection result normal? YES: GO TO 2. NO: Repair or replace the malfunction parts.
  2. CHECK RECLINING SWITCH Check reclining switch. Refer to " «COMPONENT FUNCTION CHECK»(ref-672616-S33046632742014112400000) ". Is the inspection result normal? YES: GO TO 3. NO: Repair or replace the malfunction parts.
  3. CHECK RECLINING MOTOR Check reclining motor. Refer to " «COMPONENT FUNCTION CHECK»(ref-672616-S14703115912014112400000) ". Is the inspection result normal? YES: GO TO 4. NO: Repair or replace the malfunction parts.
  4. CONFIRM THE OPERATION Check the operation again. Is the result normal? YES: Check intermittent incident. Refer to " «INTERMITTENT INCIDENT»(ref-672611-S01525861502014112400000) ". NO: GO TO 1 .

SEAT LIFTING (FRONT): Diagnosis Procedure

  1. CHECK LIFTING (FRONT) MECHANISM Check for the following. Mechanism deformation or pinched foreign materials. Interference with other parts because of poor installation. Is the inspection result normal? YES: GO TO 2. NO: Repair or replace the malfunction parts.
  2. CHECK LIFTING SWITCH (FRONT) Check lifting switch (front). Refer to " «COMPONENT FUNCTION CHECK»(ref-672616-S03080736602014112400000) ". Is the inspection result normal? YES: GO TO 3. NO: Repair or replace the malfunction parts.
  3. CHECK LIFTING MOTOR (FRONT) Check lifting motor (front). Refer to " «COMPONENT FUNCTION CHECK»(ref-672616-S00185036722014112400000) ". Is the inspection result normal? YES: GO TO 4. NO: Repair or replace the malfunction parts.
  4. CONFIRM THE OPERATION Check the operation again. Is the result normal? YES: Check intermittent incident. Refer to " «INTERMITTENT INCIDENT»(ref-672611-S01525861502014112400000) ". NO: GO TO 1 .

SEAT LIFTING (REAR): Diagnosis Procedure

  1. CHECK LIFTING (REAR) MECHANISM Check for the following. Mechanism deformation or pinched foreign materials. Interference with other parts because of poor installation. Is the inspection result normal? YES: GO TO 2. NO: Repair or replace the malfunction parts.
  2. CHECK LIFTING SWITCH (REAR) Check lifting switch (rear). Refer to " «COMPONENT FUNCTION CHECK»(ref-672616-S16615198502014112400000) ". Is the inspection result normal? YES: GO TO 3. NO: Repair or replace the malfunction parts.
  3. CHECK LIFTING MOTOR (REAR) Check lifting motor (rear). Refer to " «COMPONENT FUNCTION CHECK»(ref-672616-S21247230812014112400000) ". Is the inspection result normal? YES: GO TO 4. NO: Repair or replace the malfunction parts.
  4. CONFIRM THE OPERATION Check the operation again. Is the result normal? YES: Check intermittent incident. Refer to " «INTERMITTENT INCIDENT»(ref-672611-S01525861502014112400000) ". NO: GO TO 1 .

DOOR MIRROR: Diagnosis Procedure

  1. CHECK DOOR MIRROR MECHANISM Check for the following. Mechanism deformation or pinched foreign materials. Interference with other parts because of poor installation. Is the inspection result normal? YES: GO TO 2. NO: Repair or replace the malfunction parts.
  2. CHECK DOOR MIRROR REMOTE CONTROL SWITCH Check door mirror remote control switch. Refer to following. Mirror switch: Refer to " «MIRROR SWITCH: COMPONENT FUNCTION CHECK»(ref-672616-S07796827912014112400000) ". Changeover switch: Refer to " «CHANGEOVER SWITCH: COMPONENT FUNCTION CHECK»(ref-672616-S30984696512014112400000) ". Is the inspection result normal? YES: GO TO 3. NO: Repair or replace the malfunction parts.
  3. CHECK DOOR MIRROR MOTOR Check door mirror motor. Refer to " «COMPONENT FUNCTION CHECK»(ref-672616-S33988320312014112400000) ". Is the inspection result normal? YES: GO TO 4. NO: Repair or replace the malfunction parts.
  4. CONFIRM THE OPERATION Check the operation again. Is the result normal? YES: Check intermittent incident. Refer to " «INTERMITTENT INCIDENT»(ref-672611-S01525861502014112400000) ". NO: GO TO 1 .
  1. CHECK MANUAL OPERATION Check manual operation. Is the inspection result normal? YES: GO TO 2. NO: Repair or replace the malfunction parts.
  2. PERFORM INITIALIZATION AND MEMORY STORING PROCEDURE Perform initialization procedure. Refer to " «WORK PROCEDURE»(ref-672616-S26569532322014112400000) ". Perform memory storing procedure. Refer to " «WORK PROCEDURE»(ref-672616-S26583873992014112400000) ". Check memory function. Refer to " «MEMORY FUNCTION: SYSTEM DESCRIPTION»(ref-672616-S10479292722014112400000) ". Is the inspection result normal? YES: Memory function is normal. NO: GO TO 3.
  3. CHECK SEAT MEMORY SWITCH Check seat memory switch. Refer to " «COMPONENT FUNCTION CHECK»(ref-672616-S33383468212014112400000) ". Is the inspection result normal? YES: GO TO 4. NO: Replace seat memory switch.
  4. CONFIRM THE OPERATION Confirm the operation again. Is the result normal? YES: Check intermittent incident. Refer to " «INTERMITTENT INCIDENT»(ref-672611-S01525861502014112400000) ". NO: GO TO 1 .
  1. CHECK MANUAL OPERATION Check manual operation. Is the inspection result normal? YES: GO TO 2. NO: Refer to " «SEAT SLIDING: DIAGNOSIS PROCEDURE»(ref-672616-S08061756792014112400000) "
  2. CHECK SLIDING SENSOR Check sliding sensor. Refer to " «COMPONENT FUNCTION CHECK»(ref-672616-S24209854722014112400000) ". Is the inspection result normal? YES: GO TO 3. NO: Repair or replace the malfunction parts.
  3. CONFIRM THE OPERATION Check the operation again. Is the result normal? YES: Check intermittent incident. Refer to " «INTERMITTENT INCIDENT»(ref-672611-S01525861502014112400000) ". NO: GO TO 1 .
  1. CHECK MANUAL OPERATION Check manual operation. Is the inspection result normal? YES: GO TO 2. NO: Refer to " «SEAT RECLINING: DIAGNOSIS PROCEDURE»(ref-672616-S37890190872014112400000) "
  2. CHECK RECLINING SENSOR Check reclining sensor. Refer to " «COMPONENT FUNCTION CHECK»(ref-672616-S17526699442014112400000) ". Is the inspection result normal? YES: GO TO 3. NO: Repair or replace the malfunction parts.
  3. CONFIRM THE OPERATION Check the operation again. Is the result normal? YES: Check intermittent incident. Refer to " «INTERMITTENT INCIDENT»(ref-672611-S01525861502014112400000) ". NO: GO TO 1 .
  1. CHECK MANUAL OPERATION Check manual operation. Is the inspection result normal? YES: GO TO 2. NO: Refer to " «SEAT LIFTING (FRONT): DIAGNOSIS PROCEDURE»(ref-672616-S33425902502014112400000) "
  2. CHECK LIFTING SENSOR (FRONT) Check lifting sensor (front). Refer to " «COMPONENT FUNCTION CHECK»(ref-672616-S20987715972014112400000) ". Is the inspection result normal? YES: GO TO 3. NO: Repair or replace the malfunction parts.
  3. CONFIRM THE OPERATION Check the operation again. Is the result normal? YES: Check intermittent incident. Refer to " «INTERMITTENT INCIDENT»(ref-672611-S01525861502014112400000) ". NO: GO TO 1 .
  1. CHECK MANUAL OPERATION Check manual operation. Is the inspection result normal? YES: GO TO 2. NO: Refer to " «SEAT LIFTING (REAR): DIAGNOSIS PROCEDURE»(ref-672616-S41463809952014112400000) "
  2. CHECK LIFTING SENSOR (REAR) Check lifting sensor (rear). Refer to " «COMPONENT FUNCTION CHECK»(ref-672616-S31608216812014112400000) ". Is the inspection result normal? YES: GO TO 3. NO: Repair or replace the malfunction parts.
  3. CONFIRM THE OPERATION Check the operation again. Is the result normal? YES: Check intermittent incident. Refer to " «INTERMITTENT INCIDENT»(ref-672611-S01525861502014112400000) ". NO: GO TO 1 .
  1. CHECK MANUAL OPERATION Check manual operation. Is the inspection result normal? YES: GO TO 2. NO: Refer to " «DOOR MIRROR: DIAGNOSIS PROCEDURE»(ref-672616-S05542247942014112400000) "
  2. CHECK MIRROR SENSOR Check mirror sensor. Refer to following. Driver side: " «DRIVER SIDE: COMPONENT FUNCTION CHECK»(ref-672616-S33547115372014112400000) ". Passenger side: " «PASSENGER SIDE: COMPONENT FUNCTION CHECK»(ref-672616-S03678665302014112400000) ". Is the inspection result normal? YES: GO TO 3. NO: Repair or replace the malfunction parts.
  3. CONFIRM THE OPERATION Check the operation again. Is the result normal? YES: Check intermittent incident. Refer to " «INTERMITTENT INCIDENT»(ref-672611-S01525861502014112400000) ". NO: GO TO 1 .
  1. CHECK SYSTEM SETTING Check system setting. Refer to " «WORK PROCEDURE»(ref-672616-S16803466342014112400000) ". Check the operation. Is the inspection result normal? YES: INSPECTION END NO: GO TO 2.
  2. PERFORM SYSTEM INITIALIZATION Perform system initialization. Refer to " «WORK PROCEDURE»(ref-672616-S26569532322014112400000) ". Check the operation. Is the inspection result normal? YES: INSPECTION END NO: GO TO 3.
  3. CHECK FRONT DOOR SWITCH (DRIVER SIDE) Check front door switch (driver side). Refer to " «COMPONENT FUNCTION CHECK»(ref-672619-S04685371062014112400000) ". Is the inspection result normal? YES: GO TO 4. NO: Repair or replace the malfunction parts.
  4. CONFIRM THE OPERATION Confirm the operation again. Is the result normal? YES: Check intermittent incident. Refer to " «INTERMITTENT INCIDENT»(ref-672611-S01525861502014112400000) ". NO: GO TO 1 .
  1. PERFORM INTELLIGENT KEY INTERLOCK STORING PROCEDURE Perform Intelligent Key interlock storing procedure. Refer to " «WORK PROCEDURE»(ref-672616-S21398108452014112400000) ". Check the operation. Is the inspection result normal? YES: INSPECTION END NO: GO TO 2.
  2. CHECK DOOR LOCK FUNCTION Check door lock function. Refer to " «DIAGNOSIS AND REPAIR WORK FLOW»(ref-672619-S05299461892014112400000) ". Is the inspection result normal? YES: GO TO 3. NO: Repair or replace the malfunction parts.
  3. CONFIRM THE OPERATION Confirm the operation again. Is the result normal? YES: Check the intermittent incident. Refer to " «INTERMITTENT INCIDENT»(ref-672611-S01525861502014112400000) ". NO: GO TO 1 .
  1. CHECK SEAT MEMORY SWITCH INDICATOR Check seat memory switch indicator. Refer to " «COMPONENT FUNCTION CHECK»(ref-672616-S12185305632014112400000) ". Is the inspection result normal? YES: GO TO 2. NO: Repair or replace the malfunction parts.
  2. CONFIRM THE OPERATION Confirm the operation again. Is the result normal? YES: Check intermittent incident. Refer to " «INTERMITTENT INCIDENT»(ref-672611-S01525861502014112400000) ". NO: GO TO 1 .

More articles — Automatic Drive Positioner
