FLUID LEVEL
With the engine stopped, check that the fluid level is between MIN and MAX of the reservoir cap level gauge when the fluid temperature is in COLD state.
COLD: Fluid temperature 0 - 30°C (32 - 86°F)
Recommended fluid: Refer to " RECOMMENDED FLUIDS AND LUBRICANTS ".
Fluid capacity: Refer to " GENERAL SPECIFICATIONS ".
Scheme 47
| CAUTION | The fluid level should not exceed the MAX line. Excessive fluid causes fluid leakage from the cap. Never reuse drained power steering fluid. Always use the specified fluid. Refer to " RECOMMENDED FLUIDS AND LUBRICANTS ". |
FLUID LEAKAGE
Check hydraulic connections for fluid leakage, cracks, damage, looseness, or wear.
Scheme 48
- Run the engine at idle and adjust the reservoir tank oil temperature to room temperature [recommended oil temperature: approximately 20°C (68°F)].
- Turn steering wheel several times from full left stop to full right stop.
- Hold steering wheel at each lock position for five seconds and carefully check for fluid leakage. CAUTION: Never hold the steering wheel in a locked position for more than 10 seconds. (There is the possibility that power steering oil pump assembly may be damaged.)
- If fluid leaks from the joint, loosen the joint part and retighten it, being careful not to damage it. CAUTION: For tightening torque and non reusable parts, refer to " «EXPLODED VIEW»(ref-672626-S11815896182014112400000) ".
- If fluid leakage from oil pump is noticed, check oil pump. Refer to " «INSPECTION»(ref-672626-S28700671942014112400000) ".
- Check steering gear boots for accumulation of fluid leaked from steering gear.
