PHYSICAL VALUES Nissan Quest IV

PHYSICAL VALUES

Terminal No. (Wire color) Description Condition Value + - Signal name Input/Output 1 (O) Ground Battery power supply - Ignition switch OFF 11 - 14 V 2 (G) Ground Ignition power supply - Ignition switch ON 11 - 14 V 4 (SB) Ground Door motor power supply Output Ignition switch ON 9.5 - 13.5 V 5 (BR) Ground LAN signal Input/Output Ignition switch ON 9 (V) Ground ACC power supply - Ignition switch ON 11 - 14 V 10 (W) Ground Front blower motor control signal Output Ignition switch ON Front fan speed: 1st speed (manual) 12 (BR) Ground Blower fan ON signal Output Ignition switch ON Front blower motor: OFF 11 - 14 V Ignition switch ON Front blower motor: ON 0 - 0.5 V 13 (O) Ground A/C ON signal Output Ignition switch ON A/C switch: OFF (A/C indicator: OFF) Ignition switch ON A/C switch: ON (A/C indicator: ON) 0 - 0.5 V 15 (GR) Ground Ionizer ON/OFF control signal Output Ignition switch ON Front blower motor: OFF 9.5 - 13.5 V Ignition switch ON Front blower motor: ON 0 - 0.5 V 17 (L) Ground Engine coolant temperature signal Input Ignition switch ON Engine idling Engine coolant temperature: Below 56°C (133°F) Ignition switch ON Engine idling Engine coolant temperature: Between 56 - 105°C (133 - 221°F) Ignition switch ON Engine idling Engine coolant temperature: Above 105°C (221°F) 18 (L) Ground Sunload sensor signal Input Ignition switch ON 19 (O) Ground Front in-vehicle sensor signal Input Ignition switch ON 20 (R) Ground A/C auto amp. connection recognition signal Output Ignition switch ON 4.8 - 5.2 V 21 (B/W) Ground Ground - Ignition switch ON 0 - 0.1 V 23 (B/W) Ground Ground - Ignition switch ON 0 - 0.1 V 24 (SB) Ground Vehicle speed signal Input Vehicle speed: 40 km/h (25 MPH) NOTE: Waveform varies according to vehicle speed 30 (R) Ground Rear blower motor control signal Output Ignition switch ON Rear fan speed: 1st speed (manual) 32 (BR) Ground Communication signal (A/C auto amp. --> Rear A/C control) Output Ignition switch ON 33 (SB) Ground Communication signal (Rear A/C control --> A/C auto amp.) Input Ignition switch ON 36 (G) Ground Exhaust gas/outside odor detecting sensor signal Input Ignition switch ON NOTE: Waveform varies according to the measurement environment of the vehicle 37 (GR) Ground Intake sensor signal Input Ignition switch ON 38 (P) Ground Rear in-vehicle sensor signal Input Ignition switch ON 39 (LG) Ground Ambient sensor signal Input Ignition switch ON 40 (Y) Ground Sensor ground - Ignition switch ON 0 - 0.1 V

Scheme 171

Scheme 171: PHYSICAL VALUES

Scheme 172

Scheme 172

Scheme 173

Scheme 173

Scheme 174

Scheme 174

Scheme 175

Scheme 175

Scheme 176

Scheme 176

Scheme 177

Scheme 177

Scheme 178

Scheme 178

Scheme 179

Scheme 179

Scheme 180

Scheme 180

Scheme 181
