Driver Assistance System: Maintenance Nissan Quest IV

Cruise Control Systems 4 illustrations ~229 words

System Maintenance

The two side radar for the BSW system are located near the rear bumper.

  1. Always keep the area near the side radar clean.
  2. Do not attach stickers (including transparent material), install accessories or apply additional paint near the side radar.
  3. Do not strike or damage the area around the side radar.

Scheme 17

Scheme 17: Component Parts Location
No.ComponentFunction
1Side radar RHRefer to " SIDE RADAR LH/RH "
2BCMRefer to " BCM " Refer to " BODY CONTROL SYSTEM: COMPONENT PARTS LOCATION " for detailed installation location
3BSW indicator RHRefer to " BSW INDICATOR LH/RH "
4ABS actuator and electric unit (control unit)Refer to " ABS ACTUATOR AND ELECTRIC UNIT (CONTROL UNIT) " Refer to " COMPONENT PARTS LOCATION " for detailed installation location
5TCMRefer to " TCM " Refer to " CVT CONTROL SYSTEM: COMPONENT PARTS LOCATION " for detailed installation location
6ECMRefer to " ECM " Refer to " ENGINE CONTROL SYSTEM: COMPONENT PARTS LOCATION " for detailed installation location
7BSW indicator LHRefer to " BSW INDICATOR LH/RH "
8Side radar LHRefer to " SIDE RADAR LH/RH "
9BSW control moduleRefer to " BSW CONTROL MODULE "
10Combination meterDescription: Refer to " COMBINATION METER " System display and warning: " SYSTEM DISPLAY AND WARNING " Refer to " METER SYSTEM: COMPONENT PARTS LOCATION " for detailed installation location
11BSW switchDescription: Refer to " BSW SWITCH " System display and warning: " SWITCH NAME AND FUNCTION "
12BSW ON indicator (On the BSW switch)Refer to " SYSTEM DISPLAY AND WARNING "

Scheme 18

Scheme 18: BSW Control Module
  1. Controls the BSW system, based on received signals.
  2. Communicates with each control unit via CAN communication.
  3. Connected with the side radar (LH and RH) via BSW communication, BSW control module receives a vehicle detection signal and transmits a BSW indicator signal and a BSW indicator dimmer signal to the side radar.
  4. Receives a BSW switch signal from the BSW switch.
  5. Transmits a buzzer output signal to the combination meter via CAN communication.

Scheme 19

Scheme 19: Side Radar LH/RH
  1. Installed near the rear bumper, the side radar detects vehicles in the adjacent lane.
  2. Connected with the BSW control module via BSW communication, the side radar transmits a vehicle detection signal.
  3. Receives a BSW indicator signal and a BSW indicator dimmer signal from the BSW control module and transmits an indicator operation signal to the BSW indicator LH/RH.

Scheme 20

Scheme 20: BSW Indicator LH/RH
  1. Installed on the door mirror surface, the BSW indicator warns the driver by lighting/blinking.
  2. Receives a BSW indicator operation signal from the side radar LH/RH and blinks or turns ON/OFF the BSW indicator lamp.
