Automatic Drive Positioner: Removal & Installation Nissan Quest IV

INSTALLATION

Install in the reverse order of removal.

Note. After installing the driver seat, perform additional service when replacing control unit. Refer to " DESCRIPTION ".

Scheme 13

1. Remove instrument lower panel RH. Refer to " «REMOVAL AND INSTALLATION»(ref-672652-S11949434712014112400000) ".
2. Remove screw (A), and then remove automatic drive positioner control unit (2) from bracket (1).

Install in the reverse order of removal.

Note. After installing the driver seat, perform additional service when replacing control unit. Refer to " DESCRIPTION ".

Scheme 14

1. Remove front door finisher. Refer to " «REMOVAL AND INSTALLATION»(ref-672656-S07016970752014112400000) ".
2. Press pawls and remove seat memory switch (1) from switch finisher (1) using remover tool (A).

Install in the reverse order of removal.

Scheme 15

1. Remove seat cushion outer finisher. Refer to " «SEAT CUSHION: DISASSEMBLY AND ASSEMBLY»(ref-672657-S17056719872014112400000) ".
2. Remove screws (A), and then remove power seat switch (2) from seat cushion outer finisher (1).

Install in the reverse order of removal.
