Engine Mechanical: Overview Nissan Quest IV

Mechanical 1 illustration ~319 words

Scheme 6

Scheme 6: Precautions for Removing Battery Terminal
  1. When removing the 12V battery terminal, turn OFF the ignition switch and wait at least 30 seconds. NOTE: ECU may be active for several tens of seconds after the ignition switch is turned OFF. If the battery terminal is removed before ECU stops, then a DTC detection error or ECU data corruption may occur.
  2. For vehicles with 2 batteries, be sure to connect the main battery and the sub battery before turning ON the ignition switch. NOTE: If the ignition switch is turned ON with any one of the terminals of main battery and sub battery disconnected, then DTC may be detected.
  3. After installing the 12V battery, always check "Self Diagnosis Result" of all ECUs and erase DTC. NOTE: The removal of 12V battery may cause a DTC detection error.

OPERATION PROCEDURE

  1. Connect both battery cables. NOTE: Supply power using jumper cables if battery is discharged.
  2. Turn the ignition switch to ACC position. (At this time, the steering lock will be released.)
  3. Disconnect both battery cables. The steering lock will remain released with both battery cables disconnected and the steering wheel can be turned.
  4. Perform the necessary repair operation.
  5. When the repair work is completed, re-connect both battery cables. With the brake pedal released, turn the ignition switch from ACC position to ON position, then to LOCK position. (The steering wheel will lock when the ignition switch is turned to LOCK position.)
  6. Perform self-diagnosis check of all control units using CONSULT.

Description

Selection pointsSelection partsSelection itemsSelection methods
Between cylinder block and crankshaftMain bearingMain bearing grade (bearing thickness)Determined by match of cylinder block bearing housing grade (inner diameter of housing) and crankshaft journal grade (outer diameter of journal)
Between crankshaft and connecting rodConnecting rod bearingConnecting rod bearing grade (bearing thickness)Combining service grades for connecting rod big end diameter and crankshaft pin outer diameter determine connecting rod bearing selection.
Between cylinder block and pistonPiston and piston pin assembly (Piston is available together with piston pin as assembly.)Piston grade (piston skirt diameter)Piston grade = cylinder bore grade (inner diameter of bore)
Between piston and connecting rod (1)
(1) For the service parts, the grade for fitting cannot be selected between piston pin and connecting rod. (Only "0" grade is available.) The information at the shipment from the plant is described as a reference.
(1)For the service parts, the grade for fitting cannot be selected between piston pin and connecting rod. (Only "0" grade is available.) The information at the shipment from the plant is described as a reference.
  1. The identification grade stamped on each part is the grade for the dimension measured in new condition. This grade cannot apply to reused parts.
  2. For reused or repaired parts, measure the dimension accurately. Determine the grade by comparing the measurement with the values of each selection table.
  3. For details of the measurement method of each part, the reuse standards and the selection method of the selective fitting parts, refer to the text.
