Automatic Air Conditioner: Removal & Installation Nissan Quest III

Oil Adjusting Procedure for Components Replacement Except Compressor

After replacing any of the following major components, add the correct amount of oil to the system.

Amount of oil to be added

OIL ADJUSTING PROCEDURE FOR COMPONENTS

Scheme 93

1. Before connecting recovery/recycling equipment to vehicle, check recovery/recycling equipment gauges. No refrigerant pressure should be displayed. If NG, recover refrigerant from equipment lines.
2. Connect recovery/recycling equipment to vehicle. Confirm refrigerant purity in supply tank using recovery/recycling equipment and refrigerant identifier. If NG, refer to " «CONTAMINATED REFRIGERANT»(ref-259754-S36132520102007080400000) ".
3. Confirm refrigerant purity in vehicle A/C system using recovery/recycling equipment and refrigerant identifier. If NG, refer to " «CONTAMINATED REFRIGERANT»(ref-259754-S36132520102007080400000) ".
4. Discharge refrigerant into the refrigerant recovery/recycling equipment. Measure oil discharged into the recovery/recycling equipment.
5. Drain the oil from the "old" (removed) compressor into a graduated container and recover the amount of oil drained.
6. Drain the oil from the "new" compressor into a separate, clean container.
7. Measure an amount of new oil installed equal to amount drained from "old" compressor. Add this oil to "new" compressor through the suction port opening.
8. Measure an amount of new oil equal to the amount recovered during discharging. Add this oil to "new" compressor through the suction port opening.
9. If the liquid tank also needs to be replaced, add an additional 5 m l (0.2 US fl oz, 0.2 Imp fl oz) of oil at this time.

Installation

Installation is the reverse order of removal.

Scheme 94

1. Remove the rear air control from the headlining, located over the sliding door, RH.
2. Disconnect the rear air control electrical connector and remove the rear air control.

Installation is in the reverse order of removal.

Scheme 95

1. Disconnect the ambient sensor connector. NOTE: The ambient sensor is located behind the front bumper opening, in front of the condenser.
2. Release the ambient sensor clip and then remove the ambient sensor.

Installation is in the reverse order of removal.

Scheme 96

1. Remove the center console. Refer to «INSTRUMENT LOWER PANEL LH»(ref-239968-S28037059862006080400000) .
2. Remove the two screws and remove the in-vehicle sensor.

Installation is in the reverse order of removal.

Removal and Installation

The optical sensor is located in the top center of the defrost grille. Refer to OPTICAL SENSOR .

Scheme 97

REMOVAL

1. Remove the instrument lower panel RH and glove box. Refer to «GLOVE BOX»(ref-239968-S18686098772006080300000) .
2. Disconnect the intake sensor electrical connector.
3. Twist the intake sensor to remove the intake sensor from the front heater and cooling unit assembly.

Installation is in the reverse order of removal.

1. Remove the combination meter. Refer to «COMBINATION METER»(ref-239957-S05097777122006080300000) .
2. Remove the defroster duct. Refer to " «DEFROSTER DUCT»(ref-259754-S27832534312007080400000) ".
3. Remove the front blower motor.

Installation is in the reverse order of removal.

Scheme 98

Scheme 99

1. Remove the rear lower finisher assembly. Refer to «RIGHT SIDE AND REAR»(ref-239945-S00724663092006080400000) .
2. Disconnect the blower motor electrical connector.
3. Remove the three screws and remove the blower motor.

Installation is in the reverse order of removal.

REPLACEMENT TIMING

Replacement of the two in-cabin microfilters is recommended on a regular interval depending on the driving conditions. Refer to PERIODIC MAINTENANCE . It may also be necessary to replace the two in-cabin microfilters as part of a component replacement if the in-cabin microfilters are damaged.

Scheme 100

1. Remove the glove box assembly. Refer to «GLOVE BOX»(ref-239968-S30333788222006080400000) .
2. Remove the three screws and remove the in-cabin microfilter cover.
3. Remove the in-cabin microfilters from the front heater and cooling unit assembly.
4. Install the in-cabin microfilters, replacing the two in-cabin microfilters with new filters, into the front heater and cooling unit assembly. CAUTION: When installing the two new in-cabin microfilters make sure that the filters are facing in the direction indicated by the direction arrow for the air flow. The direction arrow is printed on the side of the in-cabin microfilters.
5. Install the in-cabin microfilter cover.
6. Install the glove box assembly. Refer to «GLOVE BOX»(ref-239968-S30333788222006080400000) .

Scheme 101

Scheme 102

1. Discharge the refrigerant from the A/C system. Refer to " «DISCHARGING REFRIGERANT»(ref-259754-S32806319792007080400000) ".
2. Drain the coolant from the engine cooling system. Refer to «DRAINING ENGINE COOLANT»(ref-239943-S00213979352006080300000) .
3. Remove the cowl top extension. Refer to «REMOVAL AND INSTALLATION»(ref-239945-S24732396862006080300000) .
4. Remove the exhaust system. Refer to «REMOVAL AND INSTALLATION»(ref-239947-S37880455882006080300000) .
5. Disconnect the front heater hoses from the front heater core.
6. Disconnect the high/low pressure pipe from the front expansion valve.
7. Move the two front seats to the rearmost position on the seat track.
8. Remove the instrument panel and console panel. Refer to «REMOVAL AND INSTALLATION»(ref-239968-S00271703642006080300000) .
9. Remove the steering column. Refer to «REMOVAL AND INSTALLATION»(ref-239953-S15823187362006080400000) .
10. Disconnect the instrument panel wire harness at the RH and LH in-line connector brackets, and the fuse block (J/B) electrical connectors. Refer to «HARNESS LAYOUT»(ref-239939-S16441752452006080300000) .
11. Disconnect the steering member from each side of the vehicle body.
12. Remove the front heater and cooling unit assembly with it attached to the steering member, from the vehicle. CAUTION: Use care not to damage the seats and interior trim panels when removing the front heater and cooling unit assembly with it attached to the steering member.
13. Remove the front heater and cooling unit assembly from the steering member.

Installation is in the reverse order of removal.

Note. Fill the engine cooling system with the specified coolant mixture. Refer to REFILLING ENGINE COOLANT . Recharge the A/C system. Refer to " EVACUATING SYSTEM AND CHARGING REFRIGERANT ".

Scheme 103

1. Discharge the refrigerant from the A/C system. Refer to " «DISCHARGING REFRIGERANT»(ref-259754-S32806319792007080400000) ".
2. Drain the coolant from the engine cooling system. Refer to «DRAINING ENGINE COOLANT»(ref-239943-S00213979352006080300000) .
3. Disconnect the rear heater core hoses from the rear heater core.
4. Disconnect the rear A/C pipes from the rear expansion valve.
5. Remove the rear RH interior trim panel. Refer to «REMOVAL AND INSTALLATION»(ref-239945-S08042342842006080300000) .
6. Disconnect the following electrical connectors: Rear blower motor Rear blower motor resistor Rear air mix door motor
7. Disconnect the ducts from the rear heater and cooling unit assembly.
8. Remove the rear heater and cooling unit assembly.

Installation is in the reverse order of removal.

Note. Fill the engine cooling system with the specified coolant mixture. Refer to DRAINING ENGINE COOLANT . Recharge the A/C system. Refer to " EVACUATING SYSTEM AND CHARGING REFRIGERANT ".

Scheme 104

Scheme 105

Scheme 106

Scheme 107

1. Remove the front heater and cooling unit assembly. Refer to " «FRONT HEATER AND COOLING UNIT ASSEMBLY»(ref-259754-S37931413032007080400000) ".
2. Remove the blower motor side cover.
3. Remove the front blower motor.
4. Remove heater core and evaporator case bottom cover.
5. Remove the blower motor case.
6. Remove the front heater core. NOTE: If the in-cabin microfilters are contaminated from coolant leaking from the heater core, replace the in-cabin microfilters with new ones before installing the new front heater core.

Installation is in the reverse order of removal.

Scheme 108

Scheme 109

1. Partially drain the engine cooling system. Refer to «DRAINING ENGINE COOLANT»(ref-239943-S00213979352006080300000) .
2. Remove the rear lower finisher assembly. Refer to «REMOVAL AND INSTALLATION»(ref-239945-S08042342842006080300000) .
3. Disconnect the rear heater core hoses from the rear heater core.
4. Remove the rear heater core bracket.
5. Remove the rear heater core.

Installation is in the reverse order of removal.

Scheme 110

1. Remove the cowl top. Refer to «COWL TOP»(ref-239945-S11576092792006080400000) .
2. Partially drain the engine cooling system. Refer to «DRAINING ENGINE COOLANT»(ref-239943-S00213979352006080300000) .
3. Unclip the heater pump from the cowl top extension.
4. Disconnect the heater pump electrical connector and the two heater hoses, then remove the heater pump. CAUTION: Do not disassemble the heater pump, replace the heater pump as an assembly.

Installation is in the reverse order of removal.

Scheme 111

1. Remove the front heater and cooling unit assembly. Refer to " «FRONT HEATER AND COOLING UNIT ASSEMBLY»(ref-259754-S37931413032007080400000) ".
2. Remove the steering member from the front heater and cooling unit assembly.
3. Disconnect the defroster door motor electrical connector.
4. Remove the two screws and remove the defroster door motor.

Installation is in the reverse order of removal.

Scheme 112

Scheme 113

Scheme 114

1. Remove the instrument lower panel LH. Refer to «REMOVAL»(ref-239968-S35835752552006080300000) .
2. Remove the center console. Refer to «REMOVAL AND INSTALLATION»(ref-239968-S00271703642006080300000) .
3. Disconnect the intake door motor electrical connector.
4. Remove the three screws and remove the intake door motor.

Installation is in the reverse order of removal.

1. Remove the front heater and cooling unit assembly. Refer to " «FRONT HEATER AND COOLING UNIT ASSEMBLY»(ref-259754-S37931413032007080400000) ".
2. Remove the steering member from the front heater and cooling unit assembly.
3. Disconnect the intake door motor electrical connector.
4. Remove the three screws and remove the intake door motor.

Installation is in the reverse order of removal.

Scheme 115

Scheme 116

1. Remove the instrument lower panel RH and glove box. Refer to «GLOVE BOX»(ref-239968-S30333788222006080400000) .
2. Remove the center console. Refer to «REMOVAL AND INSTALLATION»(ref-239968-S00271703642006080300000) .
3. Disconnect the mode door motor electrical connector.
4. Remove the three screws and remove the mode door motor.

Installation is in the reverse order of removal.

Scheme 117

Scheme 118

Scheme 119

1. Remove the instrument lower panel LH. Refer to «REMOVAL»(ref-239968-S35835752552006080300000) .
2. Remove the center console. Refer to «REMOVAL AND INSTALLATION»(ref-239968-S00271703642006080300000) .
3. Disconnect the air mix door motor electrical connector.
4. Remove the three screws and remove the air mix door motor.

Installation is in the reverse order of removal.

1. Remove the front heater and cooling unit assembly. Refer to " «FRONT HEATER AND COOLING UNIT ASSEMBLY»(ref-259754-S37931413032007080400000) ".
2. Remove the steering member from the front heater and cooling unit assembly.
3. Disconnect the air mix door motor electrical connector.
4. Remove the three screws and remove the air mix door motor.

Installation is in the reverse order of removal.

Scheme 120

1. Remove the rear lower finisher assembly. Refer to «RIGHT SIDE AND REAR»(ref-239945-S00724663092006080400000) .
2. Disconnect the rear air mix door motor electrical connector.
3. Remove the three screws and remove the rear air mix door motor.

Installation is in the reverse order of removal.

Scheme 121

1. Remove the instrument lower panel RH and glove box. Refer to «GLOVE BOX»(ref-239968-S30333788222006080400000) .
2. Remove the center console. Refer to «REMOVAL AND INSTALLATION»(ref-239968-S00271703642006080300000) .
3. Disconnect the variable blower control electrical connector.
4. Remove the two screws and remove the variable blower control.

Installation is in the reverse order of removal.

Scheme 122

1. Remove the rear lower finisher assembly. Refer to «RIGHT SIDE AND REAR»(ref-239945-S00724663092006080400000) .
2. Disconnect the rear blower motor resistor electrical connector.
3. Remove the two screws and remove the rear blower motor resistor.

Installation is in the reverse order of removal.

Scheme 123

Ducts - Rear Heater and Cooling Unit Assembly

Scheme 124

Scheme 125

1. Remove the front heater and cooling unit assembly. Refer to " «FRONT HEATER AND COOLING UNIT ASSEMBLY»(ref-259754-S37931413032007080400000) ".
2. Remove the defroster nozzle.

Installation is in the reverse order of removal.

1. Remove the front heater and cooling unit assembly. Refer to " «FRONT HEATER AND COOLING UNIT ASSEMBLY»(ref-259754-S37931413032007080400000) ".
2. Remove the defroster nozzle.
3. Remove the fresh air duct.

Installation is in the reverse order of removal.

1. Remove the combination meter. Refer to «COMBINATION METER»(ref-239957-S05097777122006080300000) .
2. Remove the defroster duct.

Installation is in the reverse order of removal.

1. Remove the instrument panel. Refer to «REMOVAL AND INSTALLATION»(ref-239968-S00271703642006080300000) .
2. Remove the RH or LH side demister duct.

Installation is in the reverse order of removal.

1. Remove the instrument panel. Refer to «REMOVAL AND INSTALLATION»(ref-239968-S00271703642006080300000) .
2. Remove the RH, center, and LH ventilator duct.

Installation is in the reverse order of removal.

1. Remove the front heater and cooling unit assembly. Refer to " «FRONT HEATER AND COOLING UNIT ASSEMBLY»(ref-259754-S37931413032007080400000) ".
2. Remove the three clips and remove the floor connector duct.

Installation is in the reverse order of removal.

1. Remove the center console lower cover. Refer to «REMOVAL AND INSTALLATION»(ref-239968-S00271703642006080300000) .
2. Remove the clip and remove the floor distribution duct.

Installation is in the reverse order of removal.

1. Remove the floor carpet. Refer to «FLOOR TRIM»(ref-239945-S15474544062006080400000) .
2. Remove the floor duct.

Installation is in the reverse order of removal.

1. Remove the rear lower finisher assembly. Refer to «REMOVAL AND INSTALLATION»(ref-239945-S08042342842006080300000) .
2. Remove the headliner. Refer to «REMOVAL AND INSTALLATION»(ref-239945-S32551883882006080400000) . NOTE: The rear headliner duct connected to the rear overhead duct is part of the headlining trim panel and is replaced as an assembly. Refer to «HEADLINING»(ref-239945-S01250480182006080300000) .
3. Remove the bolt and two clips, and remove the rear overhead duct.

Installation is in the reverse order of removal.

1. Remove the rear lower finisher assembly. Refer to «REMOVAL AND INSTALLATION»(ref-239945-S08042342842006080300000) .
2. Reposition the floor carpet out of the way.
3. Remove the screw and clip, then remove the rear floor duct.

Installation is in the reverse order of removal.

1. Remove the interior trim panel as necessary that contains the grille to be removed. Refer to «BODY SIDE TRIM»(ref-239945-S22810569112006080300000) or «HEADLINING»(ref-239945-S01250480182006080300000) .
2. Remove the grille from the interior trim panel.

Installation is in the reverse order of removal.

Scheme 126

Scheme 127

Scheme 128

*1 CHECKING AND ADJUSTING

*2 Checking for Refrigerant Leaks

*3 Checking for Refrigerant Leaks

*4 PERFORMANCE TEST DIAGNOSES

*5 Contaminated Refrigerant

Scheme 129

Scheme 130

Note. Refer to " PRECAUTIONS FOR REFRIGERANT CONNECTION ".

Scheme 131

1. Discharge the refrigerant. Refer to " «HFC-134A (R-134A) SERVICE PROCEDURE»(ref-259754-S32572440232007080400000) ".
2. Remove the engine under cover and the splash shield.
3. Remove the drive belt. Refer to «DRIVE BELTS»(ref-239943-S33744599052006080300000) .
4. Remove the compressor mounting stud.
5. Disconnect the compressor connector.
6. Disconnect the high-pressure flexible hose and low-pressure flexible hose from the compressor. CAUTION: Cap or wrap the joint of the pipe with suitable material such as vinyl tape to avoid the entry of air.
7. Remove the compressor bolts and nut using power tools.

Installation is in the reverse order of removal.

Scheme 132

Note. For clarity, the compressor is shown out of the vehicle, but the compressor does not need to be removed to remove the compressor clutch.

Scheme 133

Scheme 134

Scheme 135

Scheme 136

1. Remove the engine under cover and the splash shield.
2. Remove the drive belt. Refer to «DRIVE BELTS»(ref-239943-S33744599052006080300000) .
3. Disconnect the compressor electrical connector.
4. Remove the center bolt while holding the clutch disc stationary using Tool as shown. Tool number : J-44614
5. Remove the clutch disc.
6. Remove the snap ring using external snap ring pliers or suitable tool.
7. Remove the pulley using Tool with a small adapter. Position the small adapter on the end of the drive shaft and the center of the puller on the small adapter. Tool number : KV99233130 (J-29884) CAUTION: To prevent deformation of the pulley groove, the puller claws should be hooked under the pulley groove and not into the pulley groove.
8. Remove the magnet coil harness clip using a screwdriver.
9. Remove the three magnet coil fixing screws and remove the magnet coil.

1. Remove the engine under cover.
2. Discharge the refrigerant. Refer to " «HFC-134A (R-134A) SERVICE PROCEDURE»(ref-259754-S32572440232007080400000) ". CAUTION: Cap or wrap the joint of the pipe with suitable material such as vinyl tape to avoid the entry of air.
3. Remove the low-pressure flexible hose. Refer to " «COMPONENTS»(ref-259754-S20132182412007080400000) ".

Installation is in the reverse order of removal.

Refer to " COMPONENTS ".

1. Remove the engine under cover.
2. Discharge the refrigerant. Refer to " «HFC-134A (R-134A) SERVICE PROCEDURE»(ref-259754-S32572440232007080400000) ".
3. Remove the high-pressure flexible hose. Refer to " «COMPONENTS»(ref-259754-S20132182412007080400000) ". CAUTION: Cap or wrap the joint of the pipe with suitable material such as vinyl tape to avoid the entry of air.

Installation is in the reverse order of removal.

Refer to " COMPONENTS ".

1. Reposition the IPDM E/R aside.
2. Remove the windshield washer fluid bottle filler neck.
3. Reposition the coolant reservoir tank aside.
4. Reposition the power steering fluid reservoir aside.
5. Discharge the refrigerant. Refer to " «HFC-134A (R-134A) SERVICE PROCEDURE»(ref-259754-S32572440232007080400000) ".
6. Remove the high-pressure pipe. Refer to " «COMPONENTS»(ref-259754-S20132182412007080400000) ". CAUTION: Cap or wrap the joint of the pipe with suitable material such as vinyl tape to avoid the entry of air.

Installation is in the reverse order of removal.

Refer to " COMPONENTS ".

Scheme 137

Scheme 138

Scheme 139

Scheme 140

Scheme 141

Scheme 142

Scheme 143

Scheme 144

Scheme 145

1. Discharge the refrigerant. Refer to " «HFC-134A (R-134A) SERVICE PROCEDURE»(ref-259754-S32572440232007080400000) ". WARNING: Avoid breathing the A/C refrigerant and oil vapor or mist. Exposure may irritate the eyes, nose and throat. If an accidental system discharge occurs, ventilate the work area before resuming removal.
2. Remove the cowl top cover. Refer to «COWL TOP»(ref-239945-S11576092792006080400000) .
3. Disconnect the ECM from the cowl top extension and reposition it out of the way.
4. Remove the two heater pump clips from the cowl top extension and reposition the heater pump out of the way. Refer to " «HEATER PUMP»(ref-259754-S17030050692007080400000) ".
5. Disconnect the heater hose clips from the cowl top extension and reposition the heater hose out of the way.
6. Remove the wiper motor and linkage. Refer to «WIPER MOTOR AND LINKAGE»(ref-239951-S24693712712006080300000) .
7. Remove the cowl top extension. Refer to «COWL TOP»(ref-239945-S11576092792006080400000) .
8. Carefully cut the high pressure pipe (1) using a suitable ratchet-type pipe cutter (A) as shown. CAUTION: Do NOT damage the hydraulic brake lines or any other surrounding parts when cutting the pipe. A small amount of refrigerant may discharge from the pipe when it is cut. Do not allow debris to fall into the cut ends of the pipe.
9. Carefully cut the low pressure pipe (1) using a suitable ratchet-type pipe cutter (A) as shown. CAUTION: Do NOT damage the hydraulic brake lines or any other surrounding parts when cutting the pipe. A small amount of refrigerant may discharge from the pipe when it is cut.
10. Disconnect the power brake booster vacuum hose from the intake manifold collector to allow removal of the cut A/C pipes.
11. Disconnect the high pressure pipe connection (1), low pressure pipe connection (2), and the A/C pipe clamp bolt (A) located near the RH front suspension strut tower (3) as shown.
12. Disconnect the high/low pressure pipe connector bolt (1) from the front expansion valve as shown. Air cleaner to electric throttle control actuator tube (2) Electric throttle control actuator (3) arrow : Front
13. Use a suitable tool to pry the pipe support clip (1) from the threaded stud on the dash panel as shown. arrow : Front
14. Remove the top section of the high/low pressure pipe (1) as shown. arrow : Front CAUTION: Cap or wrap the open pipe connections with a suitable material such as vinyl tape to avoid the entry of air, moisture and contamination.
15. Remove the lower section of the high/low pressure pipe. Access the lower section of the high/low pressure pipe from under the vehicle. Remove the high/low pressure pipe connection (1) bolt (A). Remove the A/C pipe clamp bolt (B) to release the A/C pipe clamp (2). NOTE: Reposition the rear heater pipe clamp (3) for additional clearance to remove the lower section of the high/low pressure pipe as necessary. Pry off the pipe support clip (1) secured to the dash panel threaded stud, using a suitable tool. Carefully remove the lower section of the high/low pressure pipe (1). CAUTION: Cap or wrap the open pipe connections with a suitable material such as vinyl tape to avoid the entry of air, moisture and contamination.

Note. The service replacement high/low pressure pipe is a two piece pipe assembly.

Scheme 146

Scheme 147

Scheme 148

Scheme 149

Scheme 150

1. Install and position the new lower high/low pressure pipe without tightening the connections. NOTE: To ease installation, first remove the A/C support clip from the lower section high/low pressure pipe and secure it to the dash panel threaded stud.
2. Install the new upper high/low pressure pipe through the engine compartment. Install the high/low pressure pipe to the front expansion valve and only hand tighten the connector bolt (1) as shown. Air cleaner to electric throttle control actuator tube (2) Electric throttle control actuator (3) arrow : Front Hand tighten the fittings between the upper and lower high pressure pipe (A) and the low pressure pipe (B) as shown. arrow : Front Hand tighten the high pressure pipe connection (1) and low pressure pipe connection (2) located near the RH front suspension strut tower (3) as shown. Install the A/C pipe clamp bolt (A) to the RH front suspension strut tower (3) as shown. Attach the high/low pressure pipe to the A/C support clip (secured to the dash panel threaded stud). Tighten the high pressure pipe connection (1) and low pressure pipe connection (2) located near the RH front suspension strut tower (3) as shown to specification.
3. Complete the installation of the lower high/low pressure pipe. CAUTION: Clean all of the A/C pipe fittings and connections. Replace the O-rings of the high/low-pressure pipe with new ones. Lubricate all the O-rings with NISSAN A/C System Oil Type S. Under the vehicle, tighten the high/low pressure pipe connection (1) bolt (A) as shown to specification. Install the A/C pipe clamp (2) and tighten the A/C pipe clamp bolt (B). As necessary, reposition the rear heater pipe clamp (3). Attach the other pipe support clip to the dash panel threaded stud. From the engine compartment, tighten the fittings between the upper and lower high pressure pipe (A) and the low pressure pipe (B) as shown to specification. arrow : Front CAUTION: Do NOT damage the hydraulic brake lines or any other surrounding parts when tightening the fittings.
4. Connect the power brake booster vacuum hose to the intake manifold collector.
5. Check that there is sufficient clearance between the lower high/low pressure pipe and the front stabilizer bar. Adjust the lower high/low pressure pipe as necessary.
6. Evacuate and recharge the A/C system and check the A/C system for leaks. Refer to " «HFC-134A (R-134A) SERVICE PROCEDURE»(ref-259754-S32572440232007080400000) ".
7. Install the remaining components in the reverse order of removal.

Scheme 151

1. Discharge the refrigerant. Refer to " «HFC-134A (R-134A) SERVICE PROCEDURE»(ref-259754-S32572440232007080400000) ".
2. Disconnect the refrigerant pressure sensor connector and remove the refrigerant pressure sensor from the condenser. CAUTION: Be careful not to damage the condenser fins.

Installation is in the reverse order of removal.

Refer to " COMPONENTS ".

Scheme 152

Scheme 153

1. Discharge the refrigerant. Refer to " «HFC-134A (R-134A) SERVICE PROCEDURE»(ref-259754-S32572440232007080400000) ".
2. Remove the radiator. Refer to «RADIATOR»(ref-239944-S31900986342006080400000) . CAUTION: Be careful not to damage the core surface of the condenser and the radiator.
3. Disconnect the high-pressure flexible hose and the high-pressure pipe from the condenser. CAUTION: Cap or wrap the joint of the pipe with suitable material such as vinyl tape to avoid the entry of air.
4. Disconnect the refrigerant pressure sensor connector.
5. Remove the refrigerant pressure sensor.
6. Carefully release retaining clips located on top driver side of condenser and rotate the condenser out of its mounts as shown.

Installation is in the reverse order of removal.

Refer to " COMPONENTS ".

Scheme 154

Scheme 155

Scheme 156

1. Remove the front heater and cooling unit assembly. Refer to " «FRONT HEATER AND COOLING UNIT ASSEMBLY»(ref-259754-S37931413032007080400000) ".
2. Remove the blower motor side cover.
3. Remove the front blower motor.
4. Remove the heater core and evaporator case bottom cover.
5. Remove the blower motor case.
6. Remove the two in-cabin microfilters.
7. Remove the evaporator.

Installation is in the reverse order of removal.

Scheme 157

Scheme 158

1. Remove the rear heater and cooling unit assembly from the vehicle. Refer to " «REAR HEATER AND COOLING UNIT ASSEMBLY»(ref-259754-S14450060882007080400000) ".
2. Remove the rear blower motor.
3. Remove the rear blower motor resistor.
4. Remove the rear air mix door motor.
5. Remove the rear duct and blend door assembly. Refer to " «DEFROSTER NOZZLE»(ref-259754-S34006048222007080400000) ".
6. Disassemble the rear heater and cooling unit assembly to remove the evaporator.

Installation is in the reverse order of removal.

Scheme 159

1. Discharge the refrigerant. Refer to " «HFC-134A (R-134A) SERVICE PROCEDURE»(ref-259754-S32572440232007080400000) ".
2. Remove the front heater and cooling unit assembly. Refer to " «FRONT HEATER AND COOLING UNIT ASSEMBLY»(ref-259754-S37931413032007080400000) ".
3. Remove the cooler grommet.
4. Remove the expansion valve.

Installation is in the reverse order of removal.

Expansion valve bolts : 4 N.m (0.4 kg-m, 35 in-lb)

A/C refrigerant pipe to expansion valve bolt : Refer to " COMPONENTS ".

1. Discharge the refrigerant. Refer to " «HFC-134A (R-134A) SERVICE PROCEDURE»(ref-259754-S32572440232007080400000) ".
2. Remove the rear RH interior side trim panel. Refer to «RIGHT SIDE AND REAR»(ref-239945-S00724663092006080400000) .
3. Disconnect the A/C refrigerant pipes from the expansion valve. CAUTION: Cap or wrap the A/C refrigerant pipe ends with a suitable material such as vinyl tape to avoid the entry of air and contaminants.
4. Remove the expansion valve.

Installation is in the reverse order of removal.

Expansion valve bolts : 4 N.m (0.4 kg-m, 35 in-lb)

A/C refrigerant pipe to expansion valve bolt : Refer to " COMPONENTS ".
