Transfer Case (TX15B): Other Nissan Pathfinder III рестайлинг

DETAILED FLOW

1. CUSTOMER INFORMATION Interview the customer to obtain detailed information about the symptom. GO TO 2
2. INITIAL INSPECTION Perform an initial inspection of all accessible transfer case harnesses and connectors under the vehicle. GO TO 3
3. SELF-DIAGNOSIS Perform self-diagnosis. Refer to " «CONSULT FUNCTION (ALL MODE AWD/4WD)»(ref-519813-S27342433912012122900000) ". GO TO 4
4. SYMPTOM Check for symptoms. Refer to " «SYMPTOM TABLE»(ref-519813-S13159798682012122900000) ". GO TO 5
5. MALFUNCTIONING PARTS Repair or replace the applicable parts. GO TO 6
6. SYSTEM OPERATION Check system operation. GO TO 7
7. SELF-DIAGNOSIS Perform self-diagnosis. Are any DTCs displayed? YES: GO TO 5 NO: Inspection End.

Scheme 498

TRANSFER CONTROL DEVICE

Integrates actuator motor and actuator position switch.

Actuator Motor

Moves shift rods when signaled by transfer control unit.

Actuator Position Switch

Detects actuator motor position and then sends signal to transfer control unit.

WAIT DETECTION SWITCH

Detects if transfer case is in 4WD by the 2-4 shift fork position.

Note. If 4WD shift switch is switched to 4H or 4LO and the transfer case is not in 4WD completely, the wait detection system will operate.

4LO SWITCH

4LO switch detects if the transfer case is in 4LO by the position of the L-H shift fork.

ATP SWITCH

ATP switch detects if transfer case is in neutral by the position of the L-H shift fork.

Note. Transfer case may be in neutral when shifting between 4H-4LO.

TRANSFER CONTROL UNIT

1. Transfer control unit controls transfer control device and it directs shifts from 4H-4LO and 2WD-4WD.
2. Self-diagnosis can be done.

TRANSFER SHIFT HIGH AND LOW RELAYS

Transfer shift high and low relays apply power supply to transfer control device (actuator motor).

TRANSFER SHUT OFF RELAYS

Transfer shut off relays 1 and 2 apply power supply to transfer control unit.

Scheme 499

4WD Shift Switch

4WD shift switch is able to select from 2WD, 4H or 4LO.

4WD Shift Indicator Lamp

1. Displays driving conditions selected by the 4WD shift switch while engine is running. When the 4WD warning lamp is turned on, all 4WD shift indicator lamps will turn off.
2. Turns ON when ignition switch is turned ON, for purpose of lamp check. Turns OFF approximately for 1 second after the engine starts if system is normal. 4LO Indicator Lamp
3. Displays 4LO while engine is running. 4LO indicator lamp flashes if transfer gear does not shift completely into 4H <=>4LO. In this condition, the transfer case may be in neutral and the A/T parking mechanism may not operate.
4. Turns ON when ignition switch is turned ON, for purpose of lamp check. Turns OFF approximately for 1 second after the engine starts if system is normal.

4WD WARNING LAMP

Turns on or flashes when there is a malfunction in 4WD system.

Also turns on when ignition switch is turned ON, for purpose of lamp check. Turns OFF approximately for 1 second after the engine starts if system is normal.

4WD WARNING LAMP INDICATION

ATP WARNING LAMP

When the A/T selector lever is in "P" position, the vehicle may move if the transfer case is in neutral. ATP warning lamp is turned on to indicate this condition to the driver.

Scheme 500

CAN Communication

Refer to " DTC INDEX ".

Scheme 501

Scheme 502

Scheme 503

FUNCTION

CONSULT can display each diagnostic item using the following direct diagnostic modes.

DATA MONITOR

Operation Procedure

1. Connect "CONSULT."
2. Touch "DATA MONITOR".
3. Select from "SELECT MONITOR ITEM", screen of data monitor mode is displayed. NOTE: When malfunction is detected, CONSULT performs REAL-TIME DIAGNOSIS. Also, any malfunction detected while in this mode will be displayed at real time. x: Standard -: Not applicable Monitor Item (Unit) Selection Description ECU INPUT SIGNALS MAIN SIGNALS SELECTION FROM MENU VHCL/S SEN.FR [km/h] or [mph] x - x Wheel speed calculated by ABS actuator and electric unit (control unit). Signal input with CAN communication line. VHCL/S SEN.RR [km/h] or [mph] x - x Wheel speed calculated by TCM. Signal input with CAN communication line. ENGINE SPEED [rpm] x - x Engine speed is displayed. Signal input with CAN communication line. BATTERY VOLT [V] x - x Power supply voltage for transfer control unit. 2WD SWITCH [On/Off] x - x 4WD shift switch signal status is displayed. (4L means 4LO of 4WD shift switch.) 4H SWITCH [On/Off] x - x 4L SWITCH [On/Off] x - x 4L POSI SW [On/Off] x - x 4LO switch signal status is displayed. ATP SWITCH [On/Off] x - x ATP switch signal status is displayed. WAIT DETCT SW [On/Off] x - x Wait detection switch signal status is displayed. 4WD MODE [2H/4H/4L] - x x Control status of 4WD recognized by transfer control unit. (2WD, 4H or 4LO) VHCL/S COMP [km/h] or [mph] - x x Vehicle speed recognized by transfer control unit. SHIFT ACT 1 [On/Off] - x x Output condition to actuator motor (clockwise) SHIFT AC MON1 [On/Off] - - x Check signal for transfer control unit signal output SHIFT ACT 2 [On/Off] - x x Output condition to actuator motor (counterclockwise) SHIFT AC MON2 [On/Off] - - x Check signal for transfer control unit signal output SFT ACT/R MON [On/Off] - - x Operating condition of actuator motor relay (integrated in transfer control unit) SHIFT POS SW1 [On/Off] x - x Condition of actuator position switch 1 SHIFT POS SW2 [On/Off] x - x Condition of actuator position switch 2 SHIFT POS SW3 [On/Off] x - x Condition of actuator position switch 3 SHIFT POS SW4 [On/Off] x - x Condition of actuator position switch 4 4WD FAIL LAMP [On/Off] - x x Control status of 4WD warning lamp is displayed. 2WD IND [On/Off] - - x Control status of 4WD shift indicator lamp (rear) is displayed. 4H IND [On/Off] - - x Control status of 4WD shift indicator lamp (front and center) is displayed. 4L IND [On/Off] - - x Control status of 4LO indicator lamp is displayed.

ACTUATOR MOTOR

1. Remove transfer control device. Refer to " «REMOVAL AND INSTALLATION»(ref-519813-S00218219472012122900000) ".
2. Check operation by applying battery voltage to transfer control device (actuator motor) terminals 23 and 24. CAUTION: Be careful not to overheat the harness. Terminal Actuator motor 24 (Battery voltage) - 23 (Ground) Clockwise rotate 23 (Battery voltage) - 24 (Ground) Counterclockwise rotate
3. If the inspection results are abnormal replace the transfer control device (actuator motor).

TRANSFER RELAY

1. Turn ignition switch "OFF". (Stay for at least 5 seconds.)
2. Remove transfer shift high relay and transfer shift low relay 2. Refer to " «COMPONENT PARTS LOCATION»(ref-519813-S17114204902012122900000) ".
3. Apply 12V direct current between transfer shift high and low relay terminals 1 and 2.
4. Check continuity between relay terminals 3 and 4, and 3 and 5. Terminal Condition Continuity 3 - 4 12V direct current supply between terminals 1 and 2 No OFF Yes 3 - 5 12V direct current supply between terminals 1 and 2 Yes OFF No
5. If the inspection results are abnormal replace the transfer shift high or low relay.

FLASH CODE CHART

Note. If actuator position switch "or transfer control device" is displayed, first erase self-diagnostic results. (They may be displayed after installing transfer control unit or transfer assembly.)

Scheme 504

Scheme 505

Scheme 506

Scheme 507

Scheme 508

Scheme 509

Scheme 510

Scheme 511

Scheme 512

Precaution for Supplemental Restraint System (SRS) "AIR BAG" and "SEAT BELT PRE-TENSIONER"

The Supplemental Restraint System such as "AIR BAG" and "SEAT BELT PRE-TENSIONER", used along with a front seat belt, helps to reduce the risk or severity of injury to the driver and front passenger for certain types of collision. This system includes seat belt switch inputs and dual stage front air bag modules. The SRS system uses the seat belt switches to determine the front air bag deployment, and may only deploy one front air bag, depending on the severity of a collision and whether the front occupants are belted or unbelted.

Information necessary to service the system safely is included in the SRS AIRBAG and SEAT BELTS articles of this Service Information.

PRECAUTIONS WHEN USING POWER TOOLS (AIR OR ELECTRIC) AND HAMMERS

Precaution Necessary for Steering Wheel Rotation After Battery Disconnect

Note. This Procedure is applied only to models with Intelligent Key system and NATS (NISSAN ANTI-THEFT SYSTEM). Remove and install all control units after disconnecting both battery cables with the ignition knob in the "LOCK" position. Always use CONSULT to perform self-diagnosis as a part of each function inspection after finishing work. If DTC is detected, perform trouble diagnosis according to self-diagnostic results.

For models equipped with the Intelligent Key system and NATS, an electrically controlled steering lock mechanism is adopted on the key cylinder.

For this reason, if the battery is disconnected or if the battery is discharged, the steering wheel will lock and steering wheel rotation will become impossible.

If steering wheel rotation is required when battery power is interrupted, follow the procedure below before starting the repair operation.

Service Notice

1. After overhaul refill the transfer with new transfer fluid.
2. Check the fluid level or replace the fluid only with the vehicle parked on level ground.
3. During removal or installation, keep inside of transfer clear of dust or dirt.
4. Disassembly should be done in a clean work area.
5. Before proceeding with disassembly, thoroughly clean the transfer. It is important to prevent the internal parts from becoming contaminated by dirt or other foreign matter.
6. Check for the correct installation status prior to removal or disassembly. If matchmarks are required, be certain they do not interfere with the function of the parts when applied.
7. All parts should be carefully cleaned with a general purpose, non-flammable solvent before inspection or reassembly.
8. Check appearance of the disassembled parts for damage, deformation, and unusual wear. Replace them with a new ones if necessary.
9. Gaskets, seals and O-rings should replaced any time the transfer is disassembled.
10. In principle, tighten bolts or nuts gradually in several steps working diagonally from inside to outside. If tightening sequence is specified, use it.
11. Observe the specified torque when assembling.
12. Clean and flush the parts sufficiently and blow-dry them.
13. Be careful not to damage sliding surfaces and mating surfaces.
14. Use lint-free cloth or towels for wiping parts clean. Common shop rags can leave fibers that could interfere with the operation of the transfer.

Special Service Tool

The actual shapes of Kent-Moore tools may differ from those of special service tools illustrated here.

Tool number (Kent-Moore No.) Tool name Description ST33290001 (J-34286) Puller Removing front oil seal Removing rear oil seal Removing metal bushing KV38100500 (-) Drift Installing front oil seal Installing rear oil seal Installing rear bearing Installing front bearing 80 mm (3.15 in) dia . 60 mm (2.36 in) dia . KV40105310 (-) Drift Installing dust cover 89 mm (3.50 in) dia . 80.7 mm (3.17 in) dia . KV38100200 (-) Drift Removing sun gear assembly and planetary carrier assembly Removing input bearing Installing sun gear assembly and planetary carrier assembly 65 mm (2.56 in) dia . 49 mm (1.93 in) dia . ST30720000 (J-25405) Drift Installing input bearing Installing input oil seal Installing carrier bearing 77 mm (3.03 in) dia . 55 mm (2.17 in) dia . KV32102700 (-) Drift Installing mainshaft rear bearing 48 mm (1.89 in) dia . 41 mm (1.61 in) dia . KV40104830 (-) Drift Installing input oil seal 70 mm (2.76 in) dia . 63.5 mm (2.50 in) dia . ST35300000 (-) Drift Removing carrier bearing Installing metal bushing Removing front bearing 59 mm (2.32 in) dia . 45 mm (1.77 in) dia . ST30021000 (J-22912-01) Puller Removing carrier bearing Removing front bearing Removing rear bearing ST33710000 (-) Drift Removing needle bearing Removing metal bushing Removing rear bearing 89 mm (3.5 in) 30 mm (1.18 in) dia . 24 mm (0.94 in) dia . ST35325000 (-) Drift bar Removing metal bushing 215 mm (8.46 in) 25 mm (0.98 in) dia . M12 x 1.5P ST33220000 (-) Drift Installing needle bearing 37 mm (1.46 in) dia . 31 mm (1.22 in) dia . 22 mm (0.87 in) dia . ST27863000 (-) Drift Installing carrier bearing 75 mm (2.95 in) dia . 62 mm (2.44 in) dia . ST30901000 (J-26010-01) Drift Installing rear bearing Installing front bearing 79 mm (3.11 in) dia . 45 mm (1.77 in) dia . 35.2 mm (1.38 in) dia

Scheme 513

Scheme 514

Scheme 515

Scheme 516

Scheme 517

Scheme 518

Scheme 519

Scheme 520

Scheme 521

Commercial Service Tool

Tool name Description Puller Removing companion flange Removing mainshaft rear bearing Puller Removing mainshaft rear bearing Pin punch Removing retaining pin 6 mm (0.24 in) dia . Power tool Loosening bolts, screws and nuts

Scheme 522

Scheme 523

Scheme 524

PINION GEAR END PLAY

CLEARANCE BETWEEN SHIFT FORK AND SLEEVE
