Accelerator Control System: Overview Nissan Pathfinder III рестайлинг

Engine Control Systems 3 illustrations ~249 words

OPERATION PROCEDURE

  1. Connect both battery cables. NOTE: Supply power using jumper cables if battery is discharged.
  2. Use the Intelligent Key or mechanical key to turn the ignition switch to the "ACC" position. At this time, the steering lock will be released.
  3. Disconnect both battery cables. The steering lock will remain released and the steering wheel can be rotated.
  4. Perform the necessary repair operation.
  5. When the repair work is completed, return the ignition switch to the "LOCK" position before connecting the battery cables. (At this time, the steering lock mechanism will engage.)
  6. Perform a self-diagnosis check of all control units using CONSULT.

Scheme 1

Scheme 1: ADJUSTABLE ACCELERATOR PEDAL
Scheme 1: ADJUSTABLE ACCELERATOR PEDAL
CAUTIONBefore removal and installation, the adjustable accelerator and brake pedals must be in the front most position, if equipped. This is to align the base position of the accelerator and brake pedals. Do not disassemble the accelerator pedal assembly. Do not remove the accelerator pedal position sensor from the accelerator pedal bracket. Do not disassemble the accelerator pedal adjusting mechanism. Avoid damage from dropping the accelerator pedal assembly during handling. Keep the accelerator pedal assembly away from water.

Scheme 2

Scheme 2: REMOVAL
Scheme 2: REMOVAL

Scheme 3

Scheme 3
Scheme 3
  1. Move the accelerator and brake pedals to the front most position.
  2. Disconnect the negative battery terminal.
  3. Disconnect the adjustable pedal electric motor electrical connector.
  4. Disconnect the adjustable pedal electric motor memory electrical connector (if equipped).
  5. Disconnect the accelerator position sensor electrical connector. Pull the connector lock back to unlock the connector from the accelerator pedal position sensor as shown in illustration below. Pull up on the connector to disconnect it from the accelerator pedal position sensor as shown in illustration below.
  6. Disconnect the adjustable brake pedal cable from the adjustable accelerator pedal. Release the two lock tabs, then pull the adjustable brake pedal cable to disconnect it from the adjustable accelerator pedal.
  7. Remove the two upper and one lower accelerator pedal nuts.
  8. Remove the adjustable accelerator pedal assembly.
