CONFIGURATION (BCM): Description

Vehicle specification needs to be written with CONSULT because it is not written after replacing BCM. Configuration has three functions as follows

FunctionDescription
"Before Replace ECU"Reads the vehicle configuration of current BCM. Saves the read vehicle configuration.
"After Replace ECU"Writes the vehicle configuration with manual selection.
"Select Saved Data List"Writes the vehicle configuration with saved data.
CAUTIONWhen replacing BCM, you must perform "Select Saved Data List" or "After Replace ECU" with CONSULT. Complete the procedure of "Select Saved Data List" or "After Replace ECU" in order. If you set incorrect "Select Saved Data List" or "After Replace ECU", incidents might occur. Configuration is different for each vehicle model. Confirm configuration of each vehicle model. Never perform "Select Saved Data List" or "After Replace ECU" except for new BCM.

WIPER INTERMITTENT DIAL POSITION SETTING (FRONT WIPER INTERMITTENT OPERATION)

BCM judges the wiper intermittent dial 1 - 7 by the status of INT VOLUME 1, 2, and 3 switches.

Wiper intermittent dial positionIntermittent operation delay intervalINT VOLUME switch ON/OFF status
INT VOLUME 1INT VOLUME 2INT VOLUME 3
1Short ↑ ↓ LongONONON
2ONONOFF
3ONOFFOFF
4OFFOFFOFF
5OFFOFFON
6OFFONON
7OFFONOFF

Scheme 62

Scheme 62: Component Parts Location

Scheme 63

Scheme 63: System Diagram

ECU IDENTIFICATION

The BCM part number is displayed.

Description

Refer to " CAN COMMUNICATION SIGNAL CHART ".

OPERATION PROCEDURE

  1. Connect both battery cables. NOTE: Supply power using jumper cables if battery is discharged.
  2. Use the Intelligent Key or mechanical key to turn the ignition switch to the "ACC" position. At this time, the steering lock will be released.
  3. Disconnect both battery cables. The steering lock will remain released and the steering wheel can be rotated.
  4. Perform the necessary repair operation.
  5. When the repair work is completed, return the ignition switch to the "LOCK" position before connecting the battery cables. (At this time, the steering lock mechanism will engage.)
  6. Perform a self-diagnosis check of all control units using CONSULT.
