Precautions for Supplemental Restraint System (SRS) "AIR BAG" and "SEAT BELT PRE-TENSIONER"
The Supplemental Restraint System such as "AIR BAG" and "SEAT BELT PRE-TENSIONER", used along with a front seat belt, helps to reduce the risk or severity of injury to the driver and front passenger for certain types of collision. This system includes seat belt switch inputs and dual stage front air bag modules. The SRS system uses the seat belt switches to determine the front air bag deployment, and may only deploy one front air bag, depending on the severity of a collision and whether the front occupants are belted or unbelted. Information necessary to service the system safely is included in the SUPPLEMENTAL RESTRAINT SYSTEM -- PATHFINDER and SEAT BELTS -- PATHFINDER
| WARNING | To avoid rendering the SRS inoperative, which could increase the risk of personal injury or death in the event of a collision which would result in air bag inflation, all maintenance must be performed by an authorized NISSAN/INFINITI dealer. Improper maintenance, including incorrect removal and installation of the SRS, can lead to personal injury caused by unintentional activation of the system. For removal of Spiral Cable and Air Bag Module, see the SUPPLEMENTAL RESTRAINT SYSTEM -- PATHFINDER . Do not use electrical test equipment on any circuit related to the SRS unless instructed to in this article. SRS wiring harnesses can be identified by yellow and/or orange harnesses or harness connectors. |
Identifying Adjustable Accelerator Pedal Components And Torque Specification. Scheme 2
Identifying Non Adjustable Accelerator Pedal Components And Torque Specification. Scheme 3
| CAUTION | Before removal and installation, the adjustable accelerator and brake pedals must be in the frontmost position, if equipped. This is to align the base position of the accelerator and brake pedals. Do not disassemble the accelerator pedal assembly. Do not remove the accelerator pedal position sensor from the accelerator pedal bracket. Do not disassemble the accelerator pedal adjusting mechanism. Avoid damage from dropping the accelerator pedal assembly during handling. Keep the accelerator pedal assembly away from water. |
Scheme 4
Scheme 5
- Move the accelerator and brake pedals to the frontmost position.
- Turn the ignition switch OFF and disconnect the negative battery terminal.
- Disconnect the adjustable pedal electric motor electrical connector.
- Disconnect the adjustable pedal electric motor memory electrical connector, if equipped.
- Disconnect the accelerator position sensor electrical connector. Pull the connector lock back to unlock the connector from the accelerator pedal position sensor as shown. Pull up on the connector to disconnect it from the accelerator pedal position sensor as shown. (Scheme 4): Identifying Accelerator Pedal Position Sensor Connector (Adjustable Accelerator Pedal)
- Disconnect the adjustable brake pedal cable from the adjustable accelerator pedal. Release the two lock tabs, then pull the adjustable brake pedal cable to disconnect it from the adjustable accelerator pedal. (Scheme 5): Identifying Adjustable Brake Pedal Cable From Adjustable Accelerator Pedal
- Remove the two upper and one lower accelerator pedal nuts.
- Remove the adjustable accelerator pedal assembly. CAUTION: Do not disassemble the accelerator pedal assembly. Do not remove the accelerator pedal position sensor from the accelerator pedal bracket. Do not disassemble the accelerator pedal adjusting mechanism. Avoid damage from dropping the accelerator pedal assembly during handling. Keep the accelerator pedal assembly away from water.
ADJUSTABLE AND NON-ADJUSTABLE ACCELERATOR PEDAL
ADJUSTABLE AND NON-ADJUSTABLE ACCELERATOR PEDAL Unit: mm (in) Accelerator pedal - total pedal applied stroke "A" 48 (1.89)
