Starting & Charging System: Specifications Nissan Pathfinder III

Charging System 2 illustrations ~101 words

MINIMUM SPECIFICATION OF CRANKING VOLTAGE REFERENCING COOLANT TEMPERATURE

Engine coolant temperatureVoltage V
30°C to -20°C (-22°F to -4°F)8.4
19°C to -10°C (-2°F to 14°F)8.9
9°C to 0°C (16°F to 32°F)9.3
More than 1°C (More than 34°F)9.7

MINIMUM SPECIFICATION OF CRANKING VOLTAGE REFERENCING COOLANT TEMPERATURE

Power Generation Variable Voltage Control System Diagram. Scheme 1

Fig. 24: Identifying Starting System Components And Torque Specification
Scheme 24: Identifying Starting System Components And Torque Specification

Scheme 2

Scheme 2: REMOVAL
Scheme 2: REMOVAL
  1. Disconnect the negative battery terminal.
  2. Remove engine undercover, using power tools.
  3. Remove exhaust manifold cover from exhaust manifold (right bank) to gain access to starter cover bolts. Refer to " «REMOVAL»(ref-272538-S31337224082007112100000) ".
  4. Remove starter cover bolts and starter cover.
  5. Disconnect terminal "1" connector and terminal "2" nut. see scheme 25: Identifying Terminal 1 Connector And Terminal 2 Nut
  6. Remove the two starter bolts, using power tools.
  7. Remove the starter.
