Precautions for Supplemental Restraint System (SRS) "AIR BAG" and "SEAT BELT PRE-TENSIONER"
The Supplemental Restraint System such as "AIR BAG" and "SEAT BELT PRE-TENSIONER", used along with a front seat belt, helps to reduce the risk or severity of injury to the driver and front passenger for certain types of collision. This system includes seat belt switch inputs and dual stage front air bag modules. The SRS system uses the seat belt switches to determine the front air bag deployment, and may only deploy one front air bag, depending on the severity of a collision and whether the front occupants are belted or unbelted. Information necessary to service the system safely is included in the SUPPLEMENTAL RESTRAINT SYSTEM -- PATHFINDER and SEAT BELTS -- PATHFINDER
| WARNING | To avoid rendering the SRS inoperative, which could increase the risk of personal injury or death in the event of a collision which would result in air bag inflation, all maintenance must be performed by an authorized NISSAN/INFINITI dealer. Improper maintenance, including incorrect removal and installation of the SRS, can lead to personal injury caused by unintentional activation of the system. For removal of Spiral Cable and Air Bag Module, see the SUPPLEMENTAL RESTRAINT SYSTEM -- PATHFINDER . Do not use electrical test equipment on any circuit related to the SRS unless instructed to in this article. SRS wiring harnesses can be identified by yellow and/or orange harnesses or harness connectors. |
For automatic drive positioner adjustable pedal, refer to " AUTOMATIC DRIVE POSITIONER ".
TERMINAL AND REFERENCE VALUE FOR PEDAL ADJUSTING CONTROL UNIT
| Terminal | Wire Color | Item | Condition | Voltage (V) (Approx.) |
|---|---|---|---|---|
| 1 | B | Ground | 0 | |
| 3 | SB | A/T device (park position switch) signal | A/T selector lever in other than P position | Battery voltage |
| A/T selector lever in P position | 0 | |||
| 4 | W/G | Ignition switch (ON or START) | Ignition switch (ON or START position) | Battery voltage |
| 5 | W | Battery power supply | Battery voltage | |
| 7 | GR | Pedal adjusting switch power supply output | Ignition switch ON A/T selector lever in other than P position | 0 |
| Ignition switch OFF or ACC A/T selector lever in any position | ||||
| Ignition switch ON A/T selector lever in P position | Battery voltage |
TERMINAL AND REFERENCE VALUE CHART
WORK FLOW
- Check the symptom and customer's requests.
- Perform the preliminary check. Refer to " «PRELIMINARY CHECK»(ref-272572-S33059208182007112100000) ".
- According to the trouble diagnosis chart, repair or replace the cause of the malfunction. Refer to " «TROUBLE DIAGNOSIS CHART BY SYMPTOM»(ref-272572-S02968891212007112100000) ".
- Does adjustable pedal system operate normally? YES: GO TO 5. NO: GO TO 3 .
- Inspection End.
PRELIMINARY CHECK
- CHECK ADJUSTABLE PEDAL MECHANISM Check the following. Movable part of accelerator pedal or brake pedal is deformed, or there is foreign material in it. Accelerator pedal or brake pedal is deformed or broken. OK or NG OK: Preliminary check is OK. NG: Repair or replace the malfunctioning part and check again.
