Steering Column: Diagnosis Nissan Pathfinder II

Steering Column 6 illustrations ~114 words

Inspection

  1. If steering wheel does not rotate smoothly, check column bearings for wear. Ensure bearings are lubricated with grease. Check jacket tube for deformation. If vehicle has been in a light collision, check length dimension of steering column and upper joint. See «STEERING COLUMN DIMENSIONS»(ref-4604-S39089766022000070600000) table. (Scheme 1)- (Scheme 6)
  2. If length dimension measurement is not within specification or bearings are faulty, replace steering column as an assembly. see scheme 11 Check tilt wheel mechanism operation. See «TILT WHEEL MECHANISM OPERATION»(ref-4604-S27305381292000070600000) table. Replace steering column if tilt wheel does not operate properly.
Application(1) Length Dimension - In. (mm)
Altima "A"20.70-20.79 (525.8-528.1)
Frontier & Xterra "L"33.98-34.12 (863.1-866.7)
Maxima "L"20.70-20.79 (525.8-528.1)
Pathfinder
Column Upper Shaft "L 1 "27.57-27.73 (700.3-704.3)
Column Lower Shaft "L 2 "7.01-7.09 (178.0-180.0)
Column Upper Joint "L 3 " (2)16.96-17.04 (430.8-432.8)
Quest "L"19.90-19.96 (505.5-507.0)
Sentra "L"21.10-21.18 (535.9-538.0)
(1) Use specified measuring points. See appropriate illustration. (Scheme 1)- (Scheme 5). (2) Steering column upper joint is located between steering transfer gear assembly and steering column lower shaft.
(1)Use specified measuring points. See appropriate illustration. (Scheme 1)- (Scheme 5).
(2)Steering column upper joint is located between steering transfer gear assembly and steering column lower shaft.

STEERING COLUMN DIMENSIONS

Models(1) In. (mm)
Altima, Maxima & Sentra
Zero-To-"A"0.59 (15.0)
Zero-To-"B"0.59 (15.0)
Frontier & Xterra
Zero-To-"A"0.79 (20.0)
Zero-To-"B"0.39 (10.0)
Pathfinder
Zero-To-"A"0.83 (21.0)
Zero-To-"B"0.35 (9.0)
Quest
Zero-To-"A"0.59 (15.0)
Zero-To-"B"0.98 (25.0)
(1) Use specified measuring points. (Scheme 6)
(1)Use specified measuring points. (Scheme 6)

TILT WHEEL MECHANISM OPERATION

Scheme 1

Scheme 1

Scheme 2

Scheme 2

Scheme 3

Scheme 3

Scheme 4

Scheme 4

Scheme 5

Scheme 5

Scheme 6

Scheme 6
