CIRCUIT BREAKER (PASSENGER COMPARTMENT)
Located to the left of the steering column, behind and to the left of the fuse box. (Scheme 3)and (Scheme 4).
Scheme 3
FUSE BLOCK (PASSENGER COMPARTMENT)
The fuse block is located under the left side of the dash panel. (Scheme 4) If a fuse is blown, locate the cause before replacing the fuse. Spare fuses are contained in the fuse block. If an electrical failure occurs and the fuses are in good condition, check the fusible links located in the engine compartment and replace as necessary. Use only fuse/fusible link with correct amperage rating when replacing blown fuse or melted fusible link.
Scheme 4
Scheme 5
- 1 - 15 Amp HEATER, A/C
- 2 - 15 Amp HEATER, A/C
- 3 - Blank BLANK
- 4 - 15 Amp AUDIO
- 5 - 10 Amp WIP/R
- 6 - 7.5 Amp A/C, FICD
- 7 - 7.5 Amp ABS
- 8 - 10 Amp VSS, MIL/DL,VSSMTR, NONDTC, ABS, SRS, CHARGE, DTRL, BACK/L, ILL, INT/L, METER, WARN, ASCD
- 9 - 10 Amp COMPASS, MIRROR
- 10 - 10 Amp AUDIO, P/ANT, THEFT, MULTI
- 11 - 10 Amp SHIFT, HEATER, A/C, H/LAMP, DTRL, TAIL/L, F/FOG, ILL, INT/L, CHIME, DEF, SROOF, ASCD, WINDOW, THEFT, NATS
- 12 - 7.5 Amp TURN
- 13 - 15 Amp CIGAR
- 14 - 10 Amp ABS, STOP/L, ASCD
- 15 - 20 Amp TURN, MULTI
- 16 - 10 Amp EGRC1, VENT/V, AAC/V, TP/SW, SW/V, EGRC/V, BYPS/V, MIL/DL, TPS, NONDEC, H/LAMP, DTRL, TAIL/L, F/FOG, ILL
- 17 - 15 Amp F/PUMP
- 18 - 10 Amp MAIN, PNP/SW, BA/FTS, NONDTC, START, BACK/L, WARN, ASCD
- 19 - 20 Amp WIPER
- 20 - 15 Amp TURN, MULTI
- 21 - 10 Amp START, DEF
- 22 - 10 Amp SRS
- 23 - Blank BLANK
- 24 - 7.5 Amp MIL/DL, MAIN, BA/FTS, A/C, H/LAMP, DTRL, TAIL/L, F/FOG, ILL, INT/L, METER, CHIME, DEF, P/ANT, SROOF, WINDOW, D/LOCK, MULTI, THEFT, NATS, TRNMT
- 25 - 10 Amp FRO2LH, FRO2RH, RRO2LH, RRO2RH, FUELRH, RO2H-L, RO2H-R, FO2H-L, FO2H-R, FUELLH
- 26 - 7.5 Amp DTRL, S/SIG
- 27 - Blank
- 28 - 10 Amp HSEAT
- 29 - 20 Amp WIP/R, CIGAR
RELAY BOX 1 (UNDERHOOD)
Located on top of left front strut tower. see scheme 4and (Scheme 6).
Scheme 6
Scheme 7
RELAY BOX 2 (UNDERHOOD)
see scheme 4and (Scheme 8).
