BELT ADJUSTMENT
Note. For water pump removal procedure, see appropriate article in ENGINE.
| Application | (1) Deflection In. (mm) |
|---|
| Axxess |
| Alternator | 1/4 (6) |
| A/C Compressor | 1/4 (6) |
| Power Steering Pump | 1/4 (6) |
| Maxima |
| Alternator | 5/16 (8) |
| A/C Compressor | 1/4 (6) |
| Power Steering Pump | 3/8 (9) |
| Pathfinder & Pickup |
| 4-Cylinder |
| Alternator | 5/16 (8) |
| A/C Compressor | 9/32 (7) |
| Power Steering Pump | 3/8 (9) |
| V6 |
| Alternator | 1/4 (6) |
| A/C Compressor | 5/16 (8) |
| Power Steering Pump | 13/32 (10) |
| Pulsar NX |
| Alternator | 9/32 (7) |
| A/C Compressor | 1/4 (6) |
| Power Steering Pump | 5/32 (4) |
| Sentra |
| Alternator | 9/32 (7) |
| A/C Compressor | 5/32 (4) |
| Power Steering Pump | 5/32 (4) |
| Stanza |
| Alternator | 1/4 (6) |
| A/C Compressor | 3/16 (5) |
| Power Steering Pump | 1/4 (6) |
| 240SX |
| Alternator | 9/32 (7) |
| A/C Compressor | 9/32 (7) |
| Power Steering Pump | 5/16 (8) |
| 300ZX |
| Alternator | 19/64 (7.5) |
| A/C Compressor | 5/16 (8) |
| Power Steering Pump | 29/64 (11.5) |
| (1) Deflection is with 22 lbs. (10 kg) pressure applied midway on longest run of a NEW belt. |
| (1) | Deflection is with 22 lbs. (10 kg) pressure applied midway on longest run of a NEW belt. |
| Application | Specification |
|---|
| Coolant Replacement Interval | 30,000 Miles |
| Coolant Capacity (1) |
| Axxess | 7.8 Qts. (7.4L) |
| Maxima | 8.8 Qts. (8.3L) |
| Pathfinder & Pickup |
| 4-Cylinder |
| 2WD | 8.6 Qts. (8.1L) |
| 4WD | 9.5 Qts. (9.0L) |
| V6 |
| 2WD | 11.4 Qts. (10.8L) |
| 4WD | 12.4 Qts. (11.7L) |
| Pulsar NX |
| Auto. Trans. | 5.9 Qts. (5.6L) |
| Man. Trans. | 5.4 Qts. (5.1L) |
| Sentra |
| Auto. Trans. |
| 2WD | 5.7 Qts. (5.4L) |
| 4WD | 6.2 Qts. (5.9L) |
| Man. Trans | 5.7 Qts. (5.4L) |
| Stanza | 7.7 Qts. (7.3L) |
| 240SX | 7.1 Qts. (6.7L) |
| 300ZX | 9.5 Qts. (9.0L) |
| Pressure Cap | 11-14 psi |
| Thermostat Opening Temperature |
| Maxima | 180°F (82°C) |
| All Other Models | 170°F (77°C) |
| (1) - Including heater core. |
| (1) | Including heater core. |
COOLING SYSTEM SPECIFICATIONS
Scheme 1
