ON BOARD DIAGNOSIS ITEM
Information display, speedometer and tachometer can be checked in self-diagnosis mode.
Scheme 28
Scheme 29
Scheme 30
- Turn ignition switch ON, and switch the trip meter to "trip A" or "trip B".
- Turn ignition switch to OFF.
- While pressing the meter control switch (1), turn the ignition switch ON.
- Make sure that the trip meter displays "0000.0".
- Press the meter control switch (1) at least 3 times. (Within 7 seconds after the ignition switch is turned ON).
- The combination meter is turned to self-diagnosis mode. All segments of the information display and shift position indicator (A) for CVT models are displayed. NOTE: Check combination meter power supply and ground circuit when the self-diagnosis mode of the combination meter does not start. replace combination meter if power supply and ground circuit are normal. If any of the segments are not displayed, replace combination meter.
- Each meter activates by pressing the meter control switch. NOTE: If any of the meters or gauges is not activated, replace combination meter. The figure is reference.
ACTIVE TEST
| Test Item | Description |
|---|---|
| ID REGIST WARNING | This test is able to check TPMS transmitter ID regist warning chime operation [On/Off]. |
| SEAT BELT WARN TEST | This test is able to check seat belt warning chime operation [On/Off]. |
| LIGHT WARN ALM | This test is able to check light warning chime operation [On/Off]. |
| Test Item | Description |
|---|---|
| IGN KEY WARN ALM | This test is able to check key warning chime operation [On/Off]. |
| SEAT BELT WARN TEST | This test is able to check seat belt warning chime operation [On/Off]. |
| LIGHT WARN ALM | This test is able to check light warning chime operation [On/Off]. |
VALUES ON THE DIAGNOSIS TOOL
| Monitor Item | Display content | Data monitor | |
|---|---|---|---|
| Condition | Reference value in normal operation | ||
| SPEED METER [mph or km/h] | Speed meter operation | While driving | Vehicle speed matches speed meter |
| SPEED OUTPUT [mph or km/h] | Vehicle speed | While driving | The speed output signal value via CAN communication is approx. value of vehicle speed. |
| ODO OUTPUT [mi or km] | ODO meter operation | Driving | Distance driven |
| TACHO METER [RPM] | Tacho meter operation | Engine running | The tacho meter is approx. value of engine speed via CAN communication. |
| FUEL METER [L] | Fuel level | Ignition ON | Fuel level is approx. value of fuel gauge. |
| W TEMP METER [°F] or [°C] | Engine coolant temperature | Engine running | Input value of engine coolant temperature signal via CAN communication. |
| ABS W/L | ABS warning lamp | When ABS warning lamp is ON | On |
| When ABS warning lamp is OFF | Off | ||
| VDC/TCS IND | VDC indicator lamp | When VDC indicator lamp is ON | On |
| When VDC indicator lamp is OFF | OFF | ||
| SLIP IND | Slip indicator lamp | When SLIP indicator lamp is ON | On |
| When SLIP indicator lamp is OFF | Off | ||
| BRAKE W/L | Brake warning lamp | When Brake warning lamp is ON | On (1) |
| When Brake warning lamp is OFF | Off | ||
| DOOR W/L | Door open warning lamp | When Door warning lamp is ON | On |
| When Door warning lamp is OFF | Off | ||
| HI-BEAM IND | HI-Beam indicator lamp | When High-beam indicator lamp is ON | On |
| When High-beam indicator lamp is OFF | Off | ||
| TURN IND | Turn signal indicator | When Turn signal indicator lamp is ON | On |
| When Turn signal indicator lamp is OFF | Off | ||
| FR FOG IND | Front fog lamp indicator | Front fog lamp indicator lamp ON | On |
| Front fog lamp indicator lamp OFF | Off | ||
| LIGHT IND | Light indicator | When Tail lamp indicator lamp is ON | On |
| When Tail lamp indicator lamp is OFF | Off | ||
| OIL W/L | Engine oil pressure warning light | When engine oil pressure warning lamp is ON | On |
| When engine oil pressure warning lamp is OFF | Off | ||
| MIL | MIL warning lamp | When Malfunction indicator lamp (MIL) is ON | On |
| When Malfunction indicator lamp (MIL) is OFF | Off | ||
| CRUISE IND | Cruise indicator lamp | When cruise indicator lamp is ON | On |
| When cruise indicator lamp is OFF | Off | ||
| O/D OFF IND | O/D OFF indicator | When O/D OFF indicator lamp is OFF | Off |
| When O/D OFF indicator lamp is ON | On | ||
| FUEL W/L | Low fuel warning | When low fuel warning is ON | On |
| When low fuel warning is Off | Off | ||
| AIR PRES W/L | Tire pressure warning lamp operation | When tire pressure warning lamp is ON | ON |
| When tire pressure warning lamp is OFF | Off | ||
| KEY G/Y W/L | Intelligent Key warning lamp operation | When Intelligent Key warning lamp is ON | ON |
| When Intelligent Key warning lamp is OFF | Off | ||
| EPS W/L | EPS warning lamp | EPS warning lamp ON | On |
| EPS warning lamp OFF | Off | ||
| CHAGE W/L | Charge warning lamp | Engine running | Off |
| SHIFT IND | Shift position indicator | The position of the shift position selector | [P, R, N, D, L] |
| FUEL CAP W/L | Loose fuel cap warning | Loose fuel filler cap warning is On | On |
| Loose fuel filler cap warning is OFF | Off | ||
| O/D OFF SW | O/D OFF switch | When O/D OFF switch is pressed to OFF | Off |
| When O/D OFF switch is pressed to ON | On | ||
| REAR DEF SW | Rear defogger switch | When rear defogger switch is pressed to ON | On |
| When rear defogger is pressed to OFF | Off | ||
| PKB SW | Parking brake switch | When parking brake is active | On |
| When parking brake is inactive | Off | ||
| BUCKLE SW | Seat belt buckle switch LH | When seat belt buckle LH is unfastened | On |
| When seat belt buckle LH is fastened | Off | ||
| BRAKE OIL SW | Brake fluid level switch | When brake fluid level switch ON | On |
| When brake fluid level switch OFF | Off | ||
| DISTANCE | Distance to empty | While driving | [mi or km] |
| FUEL LOW SIG | Low fuel warning | When low fuel warning is On | On |
| When low fuel warning is Off | Off | ||
| BUZZER | Buzzer operation | When Buzzer is ON | On |
| When Buzzer is OFF | Off | ||
| TPMS PRESS L | Low tire pressure warning | When check tire pressure warning message is On | On |
| When check tire pressure warning message is OFF | Off | ||
| (1) Displays "Off" if the brake warning lamp is illuminated when the valve check starts, the parking brake switch is turned ON or the brake fluid level switch is turned ON. | |||
| (1) | Displays "Off" if the brake warning lamp is illuminated when the valve check starts, the parking brake switch is turned ON or the brake fluid level switch is turned ON. |
Scheme 31
DTC Index
| Display contents of CONSULT | Diagnostic item is detected when... | Refer to |
|---|---|---|
| CAN COMM CIRCUIT [U1000] | When combination meter is not transmitting or receiving CAN communication signal for 2 seconds or more. | DTC/CIRCUIT DIAGNOSIS |
| CONTROL UNIT (CAN) [U1010] | When detecting error during the initial diagnosis of the CAN controller of combination meter. | U1010 CONTROL UNIT (CAN) |
| VEHICLE SPEED [B2205] | The abnormal vehicle speed signal is input from the ABS actuator and electric unit (control unit) for 2 seconds or more. | B2205 VEHICLE SPEED |
| ENGINE SPEED [B2267] | If ECM continuously transmits abnormal engine speed signals for 2 seconds or more. | B2267 ENGINE SPEED |
| WATER TEMP [B2268] | If ECM continuously transmits abnormal engine coolant temperature signals for 60 seconds or more. | B2268 WATER TEMP |
COMBINATION METER: Diagnosis Procedure
Regarding Wiring Diagram information, refer to " WIRING DIAGRAM ".
- CHECK FUSE Check that the following fuses are not blown. Power source Fuse No. Battery 8 Ignition switch ON or START 3 Ignition switch ACC or ON 18 Is the fuse blown? YES: GO TO 2. NO: Replace the blown fuse after repairing the affected circuit.
- POWER SUPPLY CIRCUIT CHECK Disconnect combination meter connector. Check voltage between combination meter harness connector M24, terminals 27, 28, 15 and ground. Terminals Ignition switch position (+) (-) OFF ACC ON START Connector Terminal M24 27 Ground Battery voltage Battery voltage Battery voltage Battery voltage 28 0V 0V Battery voltage Battery voltage 15 0V Battery voltage Battery voltage 0V Is the inspection result normal? YES: GO TO 3. NO: Repair or replace harness or connector.
- GROUND CIRCUIT CHECK Turn ignition switch OFF. Disconnect combination meter connector. Check continuity between combination meter harness connector M24, terminals 21, 22, 23 and ground. Terminals Continuity (+) (-) Connector Terminal M24 21 Ground Yes 22 23 Is the inspection result normal? YES: Inspection End. NO: Repair or replace harness or connector.
BCM (BODY CONTROL SYSTEM) (WITH INTELLIGENT KEY SYSTEM): Diagnosis Procedure
Regarding Wiring Diagram information, refer to " WIRING DIAGRAM ".
- CHECK FUSES AND FUSIBLE LINK Check that the following fuses and fusible link are not blown. Terminal No. Signal name Fuses and fusible link No. 57 Battery power supply 12 (10A) 70 G (40A) Is the fuse blown? YES: Replace the blown fuse or fusible link after repairing the affected circuit. NO: GO TO 2.
- CHECK POWER SUPPLY CIRCUIT Disconnect BCM connector M99. Check voltage between BCM connector M99 and ground. BCM Ground Voltage Connector Terminal M99 57 - Battery voltage 70 Is the inspection result normal? YES: GO TO 3. NO: Repair harness or connector.
- CHECK GROUND CIRCUIT Check continuity between BCM connector M99 and ground. BCM Ground Continuity Connector Terminal M99 67 - Yes Is the inspection result normal? YES: Inspection End. NO: Repair harness or connector.
BCM (BODY CONTROL SYSTEM) (WITHOUT INTELLIGENT KEY SYSTEM): Diagnosis Procedure
Regarding Wiring Diagram information, refer to " WIRING DIAGRAM ".
- CHECK FUSES AND FUSIBLE LINK Check that the following fuses and fusible link are not blown. Terminal No. Signal name Fuses and fusible link No. 37 Battery power supply 8 (10A) 42 12 (10A) 50 G (40A) 11 Ignition switch ACC or ON 18 (10A) 38 Ignition switch ON or START 2 (10A) Is the fuse blown? YES: Replace the blown fuse or fusible link after repairing the affected circuit. NO: GO TO 2.
- CHECK POWER SUPPLY CIRCUIT Turn ignition switch OFF. Disconnect BCM connectors. Check voltage between BCM connector and ground. BCM Ground Ignition switch position Connector Terminal - OFF ACC ON M18 11 0 V Battery voltage Battery voltage 37 Battery voltage 38 0 V 0 V M19 42 Battery voltage Battery voltage 50 Is the inspection result normal? YES: GO TO 3. NO: Repair harness or connector.
- CHECK GROUND CIRCUIT Check continuity between BCM connector and ground. BCM Ground Continuity Connector Terminal M19 55 - Yes Is the inspection result normal? YES: Inspection End. NO: Repair harness or connector.
Diagnosis Procedure
Regarding Wiring Diagram information, refer to " WIRING DIAGRAM ".
- CHECK POWER SUPPLY OF COMBINATION METER Check power supply of combination meter. Refer to " «COMBINATION METER: DIAGNOSIS PROCEDURE»(ref-675593-S18739808862014120500000) ". Is the inspection result normal? YES: Inspection End. NO: Repair power supply circuit of combination meter.
Regarding Wiring Diagram information, refer to " WIRING DIAGRAM ".
- CHECK COMBINATION METER INPUT SIGNAL Turn ignition switch ON. Check voltage between combination meter harness connector M24 terminal 9 and ground. Combination meter Ground Condition Voltage (Approx.) Connector Terminal M24 9 - When seat belt LH (driver seat) is fastened Battery voltage When seat belt LH (driver seat) is unfastened 0 V Is the inspection result normal? YES: Replace combination meter. Refer to " «UNIT REMOVAL AND INSTALLATION»(ref-675593-S23113115242014120500000) ". NO: GO TO 2.
- CHECK SEAT BELT BUCKLE SWITCH CIRCUIT Turn ignition switch OFF. Disconnect combination meter harness connector M24 and seat belt buckle switch LH (driver seat) harness connector B16. Check continuity between combination meter harness connector M24 terminal 9 and seat belt buckle switch LH (driver seat) harness connector B13 terminal 1. Combination meter Seat belt buckle switch LH (driver seat) Continuity Connector Terminal Connector Terminal M24 9 B13 1 Yes Check continuity between combination meter harness connector M24 terminal 9 and ground. Combination meter Ground Continuity Connector Terminal M24 9 - No Is the inspection result normal? YES: GO TO 3. NO: Repair or replace harness or connector.
- CHECK SEAT BELT BUCKLE SWITCH GROUND CIRCUIT Check continuity between seat belt buckle switch LH (driver seat) harness connector B13 terminal 2 and ground. Seat belt buckle switch LH (driver seat) Ground Continuity Connector Terminal B13 2 - Yes Is the inspection result normal? YES: Check the seat belt buckle switch LH. Refer to " «REMOVAL AND INSTALLATION»(ref-675573-S19333172352014120500000) ". NO: Repair or replace harness or connector.
Component Inspection
- CHECK SEAT BELT BUCKLE SWITCH LH Turn ignition switch OFF. Disconnect the seat belt buckle switch LH (driver seat). Check continuity between the seat belt buckle switch LH (driver seat) terminals 1 and 2. Terminal Condition Continuity 1 2 When seat belt is fastened No When seat belt is unfastened Yes Is the inspection result normal? YES: Inspection End. NO: Replace the seat belt buckle switch LH. Refer to " «REMOVAL AND INSTALLATION»(ref-675573-S19333172352014120500000) ".
Regarding Wiring Diagram information, refer to " WIRING DIAGRAM ".
- CONNECTOR INSPECTION Turn ignition switch OFF. Disconnect combination meter and parking brake switch connectors. Check connectors and terminals for deformation, disconnection, looseness or damage. Is the inspection result normal? YES: GO TO 2 NO: Repair or replace as necessary.
- CHECK PARKING BRAKE SWITCH Check parking brake switch. Refer to " «COMPONENT INSPECTION»(ref-675627-S27032540712014120500000) ". Is the inspection result normal? YES: GO TO 3. NO: Replace parking brake switch. Refer to " «REMOVAL AND INSTALLATION»(ref-675606-S29245309142014120500000) ".
- CHECK PARKING BRAKE SWITCH SIGNAL With CONSULT. Connect combination meter connector and parking brake switch connectors. Turn ignition switch ON. In DATA MONITOR select PARK BRAKE SW and check parking brake switch signal. Condition DATA MONITOR Actuate parking brake On Release parking brake Off Is the inspection result normal? YES: Refer to " «WORK FLOW»(ref-675627-S07145925032014120500000) ". NO: GO TO 4.
- CHECK PARKING BRAKE SWITCH CIRCUIT Turn ignition switch OFF. Disconnect combination meter and parking brake switch connectors. Check continuity between combination meter connector M24 terminal 10 and parking brake switch connector M17 terminal 1. Combination meter Parking brake switch Continuity Connector Terminal Connector Terminal M24 10 M17 1 Yes Check continuity between combination meter connector and ground. Combination meter - Continuity Connector Terminal M24 10 Ground No Is the inspection result normal? YES: Replace combination meter. Refer to " «UNIT REMOVAL AND INSTALLATION»(ref-675593-S23113115242014120500000) ". NO: Repair or replace malfunctioning components.
- CHECK PARKING BRAKE SWITCH Turn ignition switch OFF. Disconnect parking brake switch connector. Check continuity between parking brake switch terminal 1 and ground. Parking brake switch terminal - Condition Continuity 1 Ground Parking brake actuated Yes Parking brake released No Is the inspection result normal? YES: Inspection End. NO: Replace parking brake switch. Refer to " «REMOVAL AND INSTALLATION»(ref-675606-S29245309142014120500000) ".
Regarding Wiring Diagram information, refer to " WIRING DIAGRAM ".
- CHECK FUSE Check if the key switch 10A fuse [No. 8, located in the fuse block (J/B)] is blown. Is the fuse blown? YES: Replace the fuse after repairing the affected circuit. NO: GO TO 2.
- CHECK BCM INPUT SIGNAL Check voltage between BCM harness connector M18 terminal 37 and ground. Terminals Condition Voltage (Approx.) (+) (-) BCM connector Terminal M18 37 Ground Key is inserted Battery voltage Key is removed 0V Is the inspection result normal? YES: Inspection End. NO: GO TO 3.
- CHECK KEY SWITCH CIRCUIT Disconnect BCM connector M18 and key switch. Check continuity between BCM harness connector M18 terminal 37 and key switch harness connector M27 terminal 1. BCM Key switch Continuity Connector Terminal Connector Terminal M18 37 M27 1 Yes Check continuity between BCM harness connector M18 terminal 37 and ground. BCM Ground Continuity Connector Terminal M18 37 No Is the inspection result normal? YES: GO TO 4. NO: Repair or replace harness.
- CHECK KEY SWITCH POWER SUPPLY CIRCUIT Check voltage between key switch harness connector M27 terminal 2 and ground. Terminals Voltage (Approx.) (+) (-) Key switch Terminal M27 2 Ground Battery voltage Is the inspection result normal? YES: Replace key switch. NO: Repair or replace harness.
- CHECK KEY SWITCH Turn ignition switch OFF. Disconnect key switch. Check continuity between key switch terminals 1 and 2. Terminal Condition Continuity 1 2 When key is removed from key cylinder No When key is inserted into key cylinder Yes Is the inspection result normal? YES: Inspection End. NO: Replace key switch.
- CHECK PARKING BRAKE WARNING LAMP Start the engine. Check the operation of the brake warning lamp by operating the parking brake. Combination meter Condition Status Brake warning lamp When parking brake is applied ON When parking brake is released OFF Is the inspection result normal? YES: Replace combination meter. Refer to " «UNIT REMOVAL AND INSTALLATION»(ref-675593-S23113115242014120500000) ". NO: GO TO 2.
- CHECK PARKING BRAKE SWITCH Check the parking brake switch. Refer to " «COMPONENT INSPECTION»(ref-675627-S27032540712014120500000) ". Is the inspection result normal? YES: GO TO 3. NO: Replace parking brake switch. Refer to " «REMOVAL AND INSTALLATION»(ref-675606-S29245309142014120500000) ".
- CHECK PARKING BRAKE SWITCH SIGNAL CIRCUIT Check the parking brake switch signal circuit. Refer to " «DIAGNOSIS PROCEDURE»(ref-675627-S21835647252014120500000) ". Is the inspection result normal? YES: Replace combination meter. Refer to " «UNIT REMOVAL AND INSTALLATION»(ref-675593-S23113115242014120500000) ". NO: Repair harness or connector.
- CHECK SEAT BELT WARNING LAMP Turn ignition switch ON. Check operation of seat belt warning lamp in combination meter. Combination meter Condition Status Seat belt warning lamp When seat belt LH (driver seat) is fastened OFF When seat belt LH (driver seat) is unfastened ON Is the inspection result normal? YES: Replace combination meter. Refer to " «UNIT REMOVAL AND INSTALLATION»(ref-675593-S23113115242014120500000) ". NO: GO TO 2.
- CHECK SEAT BELT BUCKLE SWITCH LH SIGNAL CIRCUIT Check the seat belt buckle switch LH signal circuit. Refer to " «DIAGNOSIS PROCEDURE»(ref-675627-S08489601652014120500000) ". Is the inspection result normal? YES: GO TO 3. NO: Repair harness or connector.
- CHECK SEAT BELT BUCKLE SWITCH LH Check seat belt buckle switch LH. Refer to " «COMPONENT INSPECTION»(ref-675627-S13408821172014120500000) ". Is the inspection result normal? YES: Replace combination meter. Refer to " «UNIT REMOVAL AND INSTALLATION»(ref-675593-S23113115242014120500000) ". NO: Replace seat belt buckle switch LH. Refer to " «REMOVAL AND INSTALLATION»(ref-675573-S19333172352014120500000) ".
- CHECK COMBINATION METER INPUT SIGNAL Select the Data Monitor for the METER/M & A and check the BUZZER monitor value. Monitor Item Condition Status BUZZER Under the condition of buzzer input ON Except above OFF Is the inspection result normal? YES: Replace combination meter. Refer to " «UNIT REMOVAL AND INSTALLATION»(ref-675593-S23113115242014120500000) ". NO: GO TO 2.
- CHECK DRIVER SIDE DOOR SWITCH SIGNAL CIRCUIT Check the driver side door switch signal circuit. Refer to " «DIAGNOSIS PROCEDURE»(ref-675592-S06375615652014120500000) " (with Intelligent Key) or " «DIAGNOSIS PROCEDURE»(ref-675628-S23585915932014120500000) " (without Intelligent Key). Is the inspection result normal? YES: GO TO 3. NO: Repair or replace harness or connector.
- CHECK DRIVER SIDE DOOR SWITCH Check the driver side door switch. Refer to " «COMPONENT INSPECTION»(ref-675592-S33067981112014120500000) " (with Intelligent Key) or " «COMPONENT INSPECTION»(ref-675628-S25801973742014120500000) " (without Intelligent Key). Is the inspection result normal? YES: Replace the BCM. Refer to " «REMOVAL AND INSTALLATION»(ref-675612-S22326735462014120500000) " (with Intelligent Key) or " «REMOVAL AND INSTALLATION»(ref-675613-S40874896552014120500000) " (without Intelligent Key). NO: Replace driver side door switch. Refer to " «REMOVAL AND INSTALLATION»(ref-675592-S17287049292014120500000) " (with Intelligent Key) or " «REMOVAL AND INSTALLATION»(ref-675628-S18817581052014120500000) " (without Intelligent Key).
- CHECK BCM INPUT SIGNAL Connect CONSULT. Select the DATA MONITOR of BCM (BUZZER) and check the KEY ON SW monitor value. Refer to " «BUZZER: CONSULT FUNCTION (BCM - BUZZER)»(ref-675613-S00222603532014120500000) ". Is the inspection result normal? YES: Replace BCM. Refer to " «REMOVAL AND INSTALLATION»(ref-675613-S40874896552014120500000) ". NO: GO TO 2.
- CHECK KEY SWITCH SIGNAL CIRCUIT Check the key switch signal circuit. Refer to " «DIAGNOSIS PROCEDURE»(ref-675627-S25682588282014120500000) ". Is the inspection result normal? YES: Replace BCM. Refer to " «REMOVAL AND INSTALLATION»(ref-675613-S40874896552014120500000) ". NO: Check applicable parts, and repair or replace corresponding parts.
