Seats: Overhaul Nissan Note E12

Seats 11 illustrations ~751 words

ASSEMBLY

Assembly is in the reverse order of disassembly.

Scheme 20

Scheme 20: ASSEMBLY
Scheme 20: ASSEMBLY
  1. Tighten the side air bag module nuts to specification. Refer to " «DRIVER SIDE: EXPLODED VIEW»(ref-675605-S33522313702014120500000) ".
  2. Tighten the chute rod nuts to specification. Refer to " «DRIVER SIDE: EXPLODED VIEW»(ref-675605-S33522313702014120500000) ".
  3. Install new hog rings on the seatback trim in original positions.
  4. Use only one hog ring in each designated location.
  5. Make sure hog rings are correctly fastened around both the seatback trim and seatback pad wires.
  6. Use NISSAN standard hog rings and tools to assemble.
CAUTIONDo not reuse the side air bag module nuts. Do not reuse the chute rod nuts. Inspect seatback pad, seatback trim and seatback trim chutes. Replace if damaged. Smooth out all wrinkles during assembly. Always route side air bag module harness in original location. Replace any deformed or damaged clips with same type and color. Always install clips in the original location in the harness. When installing the side air bag module, make sure there are no wrinkles and the chute is not folded, twisted or pinched. After the work is completed, perform self-diagnosis to check that no malfunction is detected. Refer to " DESCRIPTION ".

Assembly is in the reverse order of disassembly.

  1. Install new hog rings on the seat cushion trim in original positions.
  2. Use only one hog ring in each designated location.
  3. Make sure hog rings are correctly fastened around both the seat cushion trim and seat cushion pad wires.
  4. Use NISSAN standard hog rings and tools to assemble.
CAUTIONSmooth out all wrinkles during assembly. Always route side air bag module harness in original location. Replace any deformed or damaged clips with same type and color. Always install clips in the original location in the harness. After the work is completed, perform self-diagnosis to check that no malfunction is detected. Refer to " DESCRIPTION ".

Scheme 21

Scheme 21: PASSENGER SIDE: Exploded View
Scheme 21: PASSENGER SIDE: Exploded View

Assembly is in the reverse order of disassembly.

  1. Tighten the side air bag module nuts to specification. Refer to " «PASSENGER SIDE: EXPLODED VIEW»(ref-675605-S42865245732014120500000) ".
  2. Tighten the chute rod nuts to specification. Refer to " «PASSENGER SIDE: EXPLODED VIEW»(ref-675605-S42865245732014120500000) ".
  3. Install new hog rings on the seatback trim in original positions.
  4. Use only one hog ring in each designated location.
  5. Make sure hog rings are correctly fastened around both the seatback trim and seatback pad wires.
  6. Use NISSAN standard hog rings and tools to assemble.
CAUTIONDo not reuse the side air bag module nuts. Do not reuse the chute rod nuts. Inspect seatback pad, seatback trim and seatback trim chutes. Replace if damaged. Smooth out all wrinkles during assembly. Always route side air bag module harness in original location. Replace any deformed or damaged clips with same type and color. Always install clips in the original location in the harness. When installing the side air bag module, make sure there are no wrinkles and the chute is not folded, twisted or pinched. After the work is completed, perform self-diagnosis to check that no malfunction is detected. Refer to " DESCRIPTION ".

Assembly is in the reverse order of disassembly.

  1. Install new hog rings on the seat cushion trim in original positions.
  2. Use only one hog ring in each designated location.
  3. Make sure hog rings are correctly fastened around both the seat cushion trim and seat cushion pad wires.
  4. Use NISSAN standard hog rings and tools to assemble.
CAUTIONSmooth out all wrinkles during assembly. Always route side air bag module harness in original location. Replace any deformed or damaged clips with same type and color. Always install clips in the original location in the harness. After the work is completed, perform self-diagnosis to check that no malfunction is detected. Refer to " DESCRIPTION ".

Scheme 22

Scheme 22: Exploded View
Scheme 22: Exploded View

Scheme 23

Scheme 23
Scheme 23

Scheme 24

Scheme 24: Seat Cushion
Scheme 24: Seat Cushion

DISASSEMBLY

  1. Remove the seat cushion. Refer to " «SEAT CUSHION: REMOVAL AND INSTALLATION»(ref-675605-S34945010482014120500000) ".
  2. Remove the hog rings on the bottom side of seat cushion.
  3. Remove the hog rings on the top side of seat cushion and separate the seat cushion trim from the seat cushion pad. NOTE: Remove all pieces of hog rings and discard them.

Assembly is in the reverse order of disassembly.

  1. Install new hog rings on the seat cushion trim in original positions.
  2. Use only one hog ring in each designated location.
  3. Make sure hog rings are correctly fastened around both the seat cushion trim and seat cushion pad wires.
  4. Use NISSAN standard hog rings and tools to assemble.

Scheme 25

Scheme 25: Seatback (LH)
Scheme 25: Seatback (LH)

Scheme 26

Scheme 26
Scheme 26

Scheme 27

Scheme 27
Scheme 27

Scheme 28

Scheme 28
Scheme 28
  1. Remove the seatback (LH). Refer to " «SEATBACK: REMOVAL AND INSTALLATION»(ref-675605-S33946689432014120500000) ".
  2. Remove the headrest.
  3. Release clips and remove latch finisher.
  4. Release pawls and remove the seat belt guide finisher.
  5. Remove nut and the seat belt guide.
  6. Rotate the seatback latch release knob counterclockwise as shown below (<==) and remove.
  7. Remove the armrest (1) (if equipped). Remove clip (A) using a suitable tool, then the armrest bracket finisher (RH) (2) as shown below (<==). Remove nuts (B), then the armrest.
  8. Release hook fasteners (A), then J-hook retainer (B).
  9. Unzip the seatback trim zipper (C), then release J-clip retainers (D).
  10. Release the headrest holder locks as shown below and remove. CAUTION: Before removing the headrest holder, check its orientation (front/rear and right/left).
  11. Remove the seatback trim and seatback pad from the seatback frame.
  12. Remove bolts and the seatback latch.
  13. Remove the hog rings and separate the seatback trim (1) from the seatback pad. NOTE: Remove all pieces of hog rings and discard them.

Scheme 29

Scheme 29
Scheme 29

Scheme 30

Scheme 30
Scheme 30
  1. Remove the seatback (RH). Refer to " «SEATBACK: REMOVAL AND INSTALLATION»(ref-675605-S33946689432014120500000) ".
  2. Remove the headrest.
  3. Release clips and remove latch finisher.
  4. Rotate the seatback latch release knob counterclockwise as shown below (<==) and remove.
  5. Release hook fasteners (A), then J-hook retainer (B).
  6. Unzip the seatback trim zipper (C), then release J-clip retainers (D).
  7. Release the headrest holder locks as shown below and remove. CAUTION: Before removing the headrest holder, check its orientation (front/rear and right/left).
  8. Remove the seatback trim and seatback pad from the seatback frame.
  9. Remove bolts and the seatback latch.
  10. Remove the hog rings and separate the seatback trim (1) from the seatback pad. NOTE: Remove all pieces of hog rings and discard them.

Assembly is in the reverse order of disassembly.

  1. Install new hog rings on the seatback trim in original positions.
  2. Use only one hog ring in each designated location.
  3. Make sure hog rings are correctly fastened around both the seatback trim and seatback pad wires.
  4. Use NISSAN standard hog rings and tools to assemble.
