Interior: Removal & Installation Nissan Note E12

INSTALLATION

Installation is in the reverse order of removal.

Scheme 54

Scheme 55

1. Remove door pull handle escutcheon using a suitable tool.
2. Release pawls using a suitable tool and remove storage tray (LH/RH).
3. Release the metal clip (A) behind the manual window crank handle using a suitable tool (B). Pull the manual window crank handle (1) outward from the front door finisher and remove handle.
4. Remove front door finisher.
5. Remove front door finisher bolt (A).
6. Release clips using a suitable tool (A) and remove front door finisher as shown below.

Installation is in the reverse order of removal.

Scheme 56

Scheme 57

Scheme 58

1. Release rear door corner finisher clip using a suitable tool.
2. Remove rear door pull handle escutcheon using a suitable tool.
3. Remove screw (B) from power window and door lock/unlock switch (RH) finisher.
4. Remove power window and door lock/unlock switch (RH) finisher (1) using a suitable tool (A).
5. Disconnect the harness connector from the power window and door lock/unlock switch (RH).
6. Remove rear door finisher bolt (A).
7. Release rear door finisher clips using a suitable tool (A) and remove rear door finisher as shown below.

Installation is in the reverse order of removal.

Scheme 59

Scheme 60

1. Release rear door corner finisher clip using a suitable tool.
2. Release storage tray pawls using a suitable tool and remove storage tray.
3. Release the metal clip (A) behind the manual window crank handle using a suitable tool (B). Pull the manual window crank handle (1) outward from the front door finisher and remove handle.
4. Remove rear door finisher bolt (A).
5. Release rear door finisher clips using a suitable tool (A) and remove rear door finisher as shown below.

Installation is in the reverse order of removal.

Scheme 61

Scheme 62

Scheme 63

1. Remove front pillar portion of front body side welt.
2. Pull front pillar finisher downward as shown below to release the front pillar finisher clip (bottom).
3. Cut and discard front pillar finisher tether clips.
4. Remove the remaining piece of the tether clip (B) using a suitable tool (A).

Scheme 64

1. Install new front pillar finisher tether clips (A) to the front pillar finisher by inserting clip end and rotating 90 degrees to fit. CAUTION: Do not reuse tether clips. Replace with new part after removal. Make sure to install tether clip to front pillar finisher before installing front pillar finisher. When installing tether clip to front pillar finisher, be sure to install by aligning to the cutout. Visually check the clip for deformation and damage during installation. Replace with new one if necessary. When installing front pillar finisher, check that clip and tether clips are securely placed into body panel holes.
2. Install the front pillar finisher to the front pillar.

Installation is in the reverse order of removal.

Installation is in the reverse order of removal.

REMOVAL

Scheme 65

Scheme 66

Scheme 67

1. Slide front seat to the full forward position.
2. Release pawls, using a suitable tool and remove the seat belt height adjuster finisher (1).
3. Remove front D-ring anchor bolt. CAUTION: Before removing D-ring anchor bolt note the positions of washers and spacers for correct installation.
4. Remove front body side welt and rear body side welt. Refer to " «BODY SIDE WELT: REMOVAL AND INSTALLATION»(ref-675611-S24193512452014120500000) ".
5. Remove center pillar lower finisher. Refer to " «CENTER PILLAR LOWER FINISHER: REMOVAL AND INSTALLATION»(ref-675611-S39475785432014120500000) ".
6. Release center pillar upper finisher upper clip using a suitable tool as shown below. CAUTION: When releasing molded in clip, follow the steps as shown below to prevent finisher or clip damage.
7. Release center pillar upper finisher lower clip using a suitable tool (A) and remove. CAUTION: Do not reuse center pillar upper finisher.

Installation is in the reverse order of removal.

Scheme 68

Removal and Installation

Scheme 69

Scheme 70

Scheme 71

Scheme 72

Scheme 73

1. Remove front seats. Refer to " «DRIVER SIDE: REMOVAL AND INSTALLATION»(ref-675605-S07451646572014120500000) " (Driver side) and " «PASSENGER SIDE: REMOVAL AND INSTALLATION»(ref-675605-S15787162872014120500000) " (Passenger side).
2. Remove rear seatback hinge. Refer to " «SEATBACK HINGE: REMOVAL AND INSTALLATION»(ref-675605-S34260182922014120500000) ".
3. Remove center console lower. Refer to " «REMOVAL AND INSTALLATION»(ref-675607-S08278490192014120500000) ".
4. Remove dash side finishers (LH/RH). Refer to " «DASH SIDE FINISHER: REMOVAL AND INSTALLATION»(ref-675611-S09815083292014120500000) ".
5. Remove center pillar lower finishers (LH/RH). Refer to " «CENTER PILLAR LOWER FINISHER: REMOVAL AND INSTALLATION»(ref-675611-S39475785432014120500000) ".
6. Disconnect negative and positive battery terminals, then wait at least three minutes. Refer to " «REMOVAL AND INSTALLATION (BATTERY)»(ref-675572-S35311355862014120500000) ". WARNING: Before servicing the SRS, turn the ignition switch off, disconnect both battery terminals then wait at least three minutes.
7. Disconnect the harness connector (A) from the seat belt retractor (1). WARNING: Do not drop the seat belt retractor. Always handle it with care. Always point pretensioner cylinder away from body when handling. CAUTION: For removing/installing the shoulder belt pre-tensioner harness connector, insert a thin screwdriver wrapped in tape into the notch, then lift the lock and remove the harness connector as shown below. Install the harness connector with the lock raised, and push the lock into the harness connector as shown below. After installing the harness connector, check that the lock is pushed in securely.
8. Remove seat belt lower anchor bolt. CAUTION: Before removing the seat belt lower anchor bolt, note the positions of washers and spacers for correct installation.
9. Remove diagnosis sensor unit. Refer to " «REMOVAL AND INSTALLATION»(ref-675573-S05882337292014120500000) ".
10. Remove shift selector. Refer to (5MT) or " «REMOVAL AND INSTALLATION»(ref-675588-S34071365272014120500000) " (CVT)
11. Remove A/C unit assembly bolt (C) and bracket (1) from vehicle.
12. Remove instrument panel lower bracket bolt (B) and screw (A) and reposition bracket as necessary to remove floor trim.
13. Release carpet hook clips with a suitable tool (A) and remove.
14. Release pawls using a suitable tool (A) and open the harness clips.
15. Remove floor trim.

Installation is in the reverse order of removal.

Scheme 74

Scheme 75

Scheme 76

1. Remove front pillar finishers (LH/RH). Refer to " «FRONT PILLAR FINISHER: REMOVAL AND INSTALLATION»(ref-675611-S41976096022014120500000) ".
2. Remove sun visor screws and sun visor S (LH/RH).
3. Remove map lamp (if equipped). Refer to " «REMOVAL AND INSTALLATION»(ref-675625-S07036640682014120500000) ".
4. Remove interior room lamp. Refer to " «REMOVAL AND INSTALLATION»(ref-675625-S25815495802014120500000) ".
5. Remove microphone (if equipped). Refer to " «REMOVAL AND INSTALLATION»(ref-675622-S38008906612014120500000) ".
6. Remove center pillar upper finishers (LH/RH). Refer to " «CENTER PILLAR UPPER FINISHER: REMOVAL AND INSTALLATION»(ref-675611-S31689585102014120500000) ".
7. Remove luggage side upper finishers (LH/RH). Refer to " «LUGGAGE SIDE UPPER FINISHER: REMOVAL AND INSTALLATION»(ref-675611-S35853506082014120500000) ".
8. Insert a suitable tool (A) at approximately a 30 degree angle into the sun visor holder notch on the front of the sun visor holder (1) and press in the locking tab (B) to release it. While holding in lock tab (B), rotate the sun visor holder (1) 90 degrees to release it from the headlining. CAUTION: Do not force the sun visor holder when removing as the locking tab may be damaged if the suitable tool is not positioned correctly. NOTE: If the sun visor holder (1) does not fully rotate, make sure that the suitable tool (A) is pressing in on the locking tab (B) and is not positioned under locking tab (B). Reinsert the suitable tool (A) as necessary to release the locking tab (B).
9. Release assist grip pawls and remove bolt (A) using a suitable tool and remove all assist grips.
10. Remove headlining clips.
11. Remove headlining through the back door. CAUTION: Do not reuse headlining.

Installation is in the reverse order of removal.

Scheme 77

Scheme 78

Scheme 79

Scheme 80

1. Remove luggage floor board (if equipped).
2. Remove luggage floor trim.
3. Remove luggage rear plate clips (A).
4. Release luggage rear plate clips using a suitable tool (A) and remove luggage rear plate as shown below.

Installation is in the reverse order of removal.

Scheme 81

1. Partially remove rear body side welt. Refer to " «BODY SIDE WELT: REMOVAL AND INSTALLATION»(ref-675611-S24193512452014120500000) ".
2. Remove luggage floor board (if equipped).
3. Remove luggage floor trim.
4. Remove seat back hinge. Refer to " «SEATBACK HINGE: REMOVAL AND INSTALLATION»(ref-675605-S34260182922014120500000) ".
5. Release rear parcel shelf finisher clips using a suitable tool and remove rear parcel shelf finisher (if equipped).
6. Remove luggage side lower finisher pawls using a suitable tool.
7. Release the harness connector from cargo room lamp (RH only) and remove luggage side lower finisher.

Installation is in the reverse order of removal.

Scheme 82

1. Remove luggage side lower finisher. Refer to " «LUGGAGE SIDE LOWER FINISHER: REMOVAL AND INSTALLATION»(ref-675611-S17810494292014120500000) ".
2. Remove seat belt lower anchor bolt.
3. Release luggage side upper finisher clips using a suitable tool and remove luggage side upper finisher.

Installation is in the reverse order of removal.

Scheme 83

1. Release back door inner finisher clips using a suitable tool and remove.

Installation is in the reverse order of removal.

1. Release pawls using a suitable tool and remove.

Installation is in the reverse order of removal.
