Component Description
| No. | Part name | Description |
|---|---|---|
| 1. | Hazard switch | Hazard flasher request signal is output to the BCM. |
| 2. | Combination meter | Blinks the turn signal indicator lamp and outputs the turn signal operating sound with integrated buzzer according to the request from BCM (via CAN communication). Turns the tail lamp indicator lamp and high beam indicator lamp ON according to the request from BCM (via CAN communication). |
| 3. | Combination switch (lighting and turn signal switch) | Refer to " TURN SIGNAL AND HAZARD WARNING LAMP SYSTEM: SYSTEM DESCRIPTION ". |
| 4. | BCM | Controls the exterior lighting system. |
| 5. | Daytime light relays 1 and 2 (if equipped), front fog lamp relay) | Controls the integrated relay, and supplies voltage to the load according to the request from BCM (via CAN communication). |
| 6. | Stop lamp switch | Stop lamp signal is output to the rear combination lamps and high-mounted stop lamp. |
Scheme 1
LOW BEAM OPERATION
When the lighting switch is in 2nd position, the BCM receives input requesting the headlamps to illuminate. This input is communicated to the IPDM E/R across the CAN communication lines. The CPU of the IPDM E/R controls the headlamp low relay coil which supplies power to the low beam headlamps.
HIGH BEAM OPERATION/FLASH-TO-PASS OPERATION
With the lighting switch in the 2nd position and placed in HIGH position, the BCM receives input requesting the headlamp high beams to illuminate. The flash to pass feature can be used any time and also sends a signal to the BCM. This input is communicated to the IPDM E/R across the CAN communication lines. The CPU of the combination meter controls the ON/OFF status off the HIGH BEAM indicator. The CPU of the IPDM E/R controls the headlamp high relay coil which supplies power to the high beam headlamps.
The combination meter receives a high beam request signal (ON) through the CAN communication lines and turns the high beam indicator lamp ON.
DAYTIME RUNNING LIGHT SYSTEM: System Description
The headlamp system for Canada vehicles is equipped with a daytime light relay 1 that activates the high beam headlamps at approximately half illumination whenever the engine is operating and the lighting switch is in the OFF position. If the parking brake is applied before the engine is started the daytime lights will not be illuminated. The daytime lights will illuminate once the parking brake is released. With the lighting switch in the 2nd position the headlamps function the same as conventional light systems.
The BCM monitors inputs from the parking brake switch and the lighting switch to determine when to activate the daytime light system. The BCM sends a daytime light request to the IPDM E/R via the CAN communication lines.
The IPDM E/R grounds the daytime light relay 1 which in turn, provides power to the ground side of the LH high beam lamp. Power flows backward through the LH high beam lamp to the IPDM E/R, through fuse 35, fuse 34 and to the RH high beam lamp and on to ground. The high beam lamps are wired in series which causes them to illuminate at a reduced intensity.
Scheme 2
FRONT FOG LAMP OPERATION
When the combination switch (lighting and turn signal switch) is in front fog lamp ON position and also in 1ST or 2ND position (headlamp is ON), the BCM detects FR FOG ON and the HEAD LAMP 1 or 2 ON. The BCM sends a front fog lamp request ON signal through the CAN communication lines to the IPDM E/R. The IPDM E/R then turns ON the front fog lamp relay sending power to the front fog lamps.
Scheme 3
TURN SIGNAL OPERATION
When the turn signal switch is in LH or RH position with the ignition switch in ON position, the BCM detects the TURN RH or TURN LH ON request. The BCM outputs the flasher output signal to the respective turn signal lamp. The BCM sends a turn indicator signal ON request through the CAN communication lines to the combination meter. The combination meter then activates the appropriate turn signal indicator and audible buzzer.
HAZARD LAMP OPERATION
When the hazard switch is in ON position, the BCM detects the hazard switch signal ON. The BCM outputs the flasher output signal (right and left). The BCM sends a hazard indicator signal ON request through the CAN communication lines to the combination meter. The combination meter then activates the hazard indicator and audible buzzer.
REMOTE KEYLESS ENTRY OPERATION
The remote keyless entry receiver transmits hazard lamp signal to BCM, then BCM controls hazard lamps. Refer to " REMOTE KEYLESS ENTRY SYSTEM: SYSTEM DESCRIPTION ".
Scheme 4
PARKING, LICENSE PLATE AND TAIL LAMPS OPERATION
When the combination switch (lighting and turn signal switch) is in 1st position, BCM detects the LIGHTING SWITCH 1st POSITION ON. The BCM sends a parking light ON request through the CAN communication lines to the IPDM E/R. The IPDM E/R then activates the tail lamp relay which sends power to the parking and instrument illumination circuits.
Description
In auto active test, the IPDM E/R sends a drive signal to the following systems to check their operation.
- Front wiper (LO, HI)
- Parking lamp
- License plate lamp
- Tail lamp
- Front fog lamp
- Headlamp (LO, HI)
- A/C compressor (magnet clutch)
- Cooling fan
Operation Procedure
Note. Never perform auto active test in the following conditions. Passenger door is open CONSULT is connected
- Close the hood and lift the wiper arms from the windshield. (Prevent windshield damage due to wiper operation) NOTE: When auto active test is performed with hood opened, sprinkle water on windshield beforehand.
- Turn the ignition switch OFF.
- Turn the ignition switch ON, and within 20 seconds, press the driver door switch 10 times. Then turn the ignition switch OFF.
- Turn the ignition switch ON within 10 seconds. After that the horn sounds once and the auto active test starts.
- After a series of the following operations is repeated 3 times, auto active test is completed.
Note. When auto active test has to be cancelled halfway through test, turn the ignition switch OFF. When auto active test is not activated, door switch may be the cause. Check door switch. Refer to " COMPONENT FUNCTION CHECK ".
ECU IDENTIFICATION
The IPDM E/R part number is displayed.
The IPDM E/R (intelligent power distribution module engine room) controls the headlamp high relay based on inputs from the BCM via the CAN communication lines. When the headlamp high relay is energized, power flows through fuses 34 and 35, located in the IPDM E/R. Power then flows to the front combination lamp LH and RH high beams.
The IPDM E/R (intelligent power distribution module engine room) controls the headlamp low relay based on inputs from the BCM via the CAN communication lines. When the headlamp low relay is energized, power flows through fuses 40 and 41, located in the IPDM E/R.
(Without daytime light system) power then flows to the front combination lamp LH and RH low beams.
(With daytime light system) power then flows to the front combination lamp LH low beam and the daytime light relay 2 which becomes energized and then power is sent to the front combination lamp RH low beam.
The IPDM E/R (intelligent power distribution module engine room) controls the tail lamp relay based on inputs from the BCM via the CAN communication lines. When the tail lamp relay is energized, power flows through fuse 37, located in the IPDM E/R. Power then flows through the tail lamp relay to the front and rear combination lamps, license plate lamps.
The BCM monitors inputs from the combination switch (high beam and turn signal switch) to determine when to activate the turn signals. The BCM outputs voltage direction to the left and right turn signals during turn signal operation or both during hazard warning operation. The BCM sends a turn signal indicator request to the combination meter via the CAN communication lines.
The BCM performs the fast flasher operation (fail-safe) if any bulb or harness of the turn signal lamp circuit is open.
Note. Turn signal lamp blinks at normal speed when using the hazard warning lamp.
The headlamps (both sides) do not switch to high beam when the combination switch (lighting and turn signal switch) is in the HI or PASS setting.
The headlamps (both sides) do not turn ON in any combination switch (lighting and turn signal switch) setting.
The parking, license plate and tail lamps do not turn ON in any combination switch (lighting and turn signal switch) position.
The front fog lamps do not turn ON in any setting.
