Precaution for Supplemental Restraint System (SRS) "AIR BAG" and "SEAT BELT PRE-TENSIONER"
The Supplemental Restraint System such as "AIR BAG" and "SEAT BELT PRE-TENSIONER", used along with a front seat belt, helps to reduce the risk or severity of injury to the driver and front passenger for certain types of collision. Information necessary to service the system safely is included in the SRS AIRBAG and SEAT BELTS article of this Service Information.
| WARNING | To avoid rendering the SRS inoperative, which could increase the risk of personal injury or death in the event of a collision which would result in air bag inflation, all maintenance must be performed by an authorized NISSAN/INFINITI dealer. Improper maintenance, including incorrect removal and installation of the SRS, can lead to personal injury caused by unintentional activation of the system. For removal of Spiral Cable and Air Bag Module, see the SRS AIRBAG . Do not use electrical test equipment on any circuit related to the SRS unless instructed to in this Service Information. SRS wiring harnesses can be identified by yellow and/or orange harnesses or harness connectors. |
PRECAUTIONS WHEN USING POWER TOOLS (AIR OR ELECTRIC) AND HAMMERS
| WARNING | When working near the Airbag Diagnosis Sensor Unit or other Airbag System sensors with the Ignition ON or engine running, DO NOT use air or electric power tools or strike near the sensor(s) with a hammer. Heavy vibration could activate the sensor(s) and deploy the air bag(s), possibly causing serious injury. When using air or electric power tools or hammers, always switch the Ignition OFF, disconnect the battery and wait at least three minutes before performing any service. |
Special Service Tool
The actual shapes of Kent-Moore tools may from those of special service tools illustrated here.
Tool number (Kent-Moore No.) Tool name Description KV991J0070 (J-45695) Coolant refill tool Refilling engine cooling system EG17650301 (J-33984-A) Radiator cap tester adapter Adapting radiator cap tester to radiator cap and radiator filler neck 28 (1.10) dia. 31.4 (1.236) dia. 41.3 (1.626) dia. Unit: mm (in)
Scheme 24
Scheme 25
Commercial Service Tool
Tool name Description Power tool Loosening nuts, screws and bolts Radiator cap tester Checking radiator and radiator cap
Scheme 26
Scheme 27
Scheme 28
Scheme 29
Scheme 30
CHECKING COOLING SYSTEM HOSES
Check hoses for the following
- Improper attachment
- Leaks
- Cracks
- Damage
- Loose connections
- Chafing
- Deterioration
CHECKING RESERVOIR LEVEL
- Check that the reservoir tank engine coolant level is within the MAX (A) to MIN (B) range when the engine is cool.
- Adjust the engine coolant level if necessary. CAUTION: Refill the engine cooling system with the specified coolant or equivalent. Refer to " «RECOMMENDED FLUIDS AND LUBRICANTS»(ref-675584-S23480474382014120500000) ".
Scheme 31
CHECKING COOLING SYSTEM FOR LEAKS
| WARNING | Do not remove the radiator cap when the engine is hot. Serious burns could occur from high-pressure engine coolant escaping from the radiator. Wrap a thick cloth around the cap. Slowly push down and turn it a quarter turn to allow built-up pressure to escape. Carefully remove the cap by pushing it down and turning it all the way. |
| CAUTION | Perform this step when the engine is cold. Do not spill engine coolant on drive belt. |
To check for leaks, apply pressure to the cooling system using suitable tool (A) and Tool (B).
Tool number (B): EG17650301 (J-33984-A)
Testing pressure: Refer to " RADIATOR: INSPECTION ".
Scheme 32
Water Inlet
After installation, attach the water inlet clip (A) on the oil level gauge guide (1) positioned at location (B) as shown below.
Scheme 33
Radiator
| Unit: kPa (kg/cm 2 , psi) | ||
|---|---|---|
| Cap relief pressure | Standard | 88 (0.90, 12.8) |
| Radiator leak test pressure | 156 (1.59, 22.6) | |
Standard
| Valve opening temperature | 80.5 - 83.5°C (177 - 182°F) |
|---|---|
| Maximum valve lift | 8.0 mm/95°C (0.315 in/203°F) |
| Valve closing temperature | 77°C (171°F) |
