PHYSICAL VALUES
BODY CONTROL MODULE CONNECTOR TERMINALS REFERENCE CHART Terminal No. (Wire color) Description Condition Value (Approx.) + - Signal name Input/Output 1 (W) Ground Battery power supply Input Ignition switch OFF Battery voltage 2 (GR) Ground P/W power supply (BAT) Output Ignition switch OFF Battery voltage 3 (L) Ground P/W power supply (RAP) Output Ignition switch ON Battery voltage 4 (P) Ground Interior room lamp power supply Output Interior room lamp battery saver is activated. (Cuts the interior room lamp power supply) 0 V Interior room lamp battery saver is not activated. (Outputs the interior room lamp power supply) Battery voltage 5 (G) Ground Passenger door UNLOCK Output Passenger door UNLOCK (Actuator is activated) Battery voltage Other than UNLOCK (Actuator is not activated) 0 V 7 (Y) Ground Step lamp Output Step lamp ON 0 V OFF Battery voltage 8 (V) Ground All doors LOCK Output All doors LOCK (Actuator is activated) Battery voltage Other than LOCK (Actuator is not activated) 0 V 9 (G) Ground Driver door UNLOCK Output Driver door UNLOCK (Actuator is activated) Battery voltage Other than UNLOCK (Actuator is not activated) 0 V 10 (P) Ground Rear RH door and rear LH door UNLOCK Output Rear RH door and rear LH door UNLOCK (Actuator is activated) Battery voltage Other than UNLOCK (Actuator is not activated) 0 V 11 (LG) Ground Battery power supply Input Ignition switch OFF Battery voltage 13 (B) Ground Ground - Ignition switch ON 0 V 14 (O) Ground Push-button ignition switch illumination ground Output Tail lamp OFF 0 V ON NOTE: When the illumination brightening/dimming level is in the neutral position 15 (L) Ground ACC indicator lamp Output Ignition switch OFF (LOCK and ON indicator lamps are not illuminated.) Battery voltage ACC 0 V 17 (G) Ground Turn signal RH Output Ignition switch ON Turn signal switch OFF 0 V Turn signal switch RH 6.5 V 18 (BR) Ground Turn signal LH Output Ignition switch ON Turn signal switch OFF 0 V Turn signal switch LH 6.5 V 19 (Y) Ground Room lamp timer control Output Interior room lamp OFF Battery voltage ON 0 V 23 (BR) Ground Back door open Output Back door OPEN (Back door opener actuator is activated) Battery voltage Other than OPEN (Back door opener actuator is not activated) 0 V 26 (G) Ground Rear wiper Output Rear wiper OFF (Stopped) 0 V ON (Operated) Battery voltage 34 (B) Ground Luggage room antenna (-) Output Ignition switch OFF When Intelligent Key is in the passenger compartment When Intelligent Key is not in the passenger compartment 35 (W) Ground Luggage room antenna (+) Output Ignition switch OFF When Intelligent Key is in the passenger compartment When Intelligent Key is not in the passenger compartment 38 (L) Ground Rear bumper antenna (-) Output When the back door request switch is operated with ignition switch OFF When Intelligent Key is in the antenna detection area When Intelligent Key is not in the antenna detection area 39 (BR) Ground Rear bumper antenna (+) Output When the back door request switch is operated with ignition switch OFF When Intelligent Key is in the antenna detection area When Intelligent Key is not in the antenna detection area 47 (L) Ground Ignition relay (IPDM E/R) control Output Ignition switch OFF or ACC Battery voltage ON 0 V 52 (R) Ground Starter relay control Output Ignition switch ON When selector lever is in P or N position Battery voltage When selector lever is not in P or N position 0.3 V Ignition switch OFF 0 V 60 (BR) Ground Push-button ignition switch (push switch) Input Push-button ignition switch (push switch) Pressed 0 V Not pressed Battery voltage 61 (R) Ground Back door request switch Input Back door request switch ON (Pressed) 0 V OFF (Not pressed) 1.0 V 64 (GR) Ground Warning buzzer Output Warning buzzer Sounding 0 V Not sounding Battery voltage 65 (O) Ground Rear wiper stop position Input Rear wiper In stop position 1.0 V Not in stop position 0 V 66 (Y) Ground Back door switch Input Back door switch OFF (When back door closes) 11.8 V ON (When back door opens) 0 V 67 (LG) Ground Back door opener switch Input Back door opener switch Pressed 0 V Not pressed 11.8 V 68 (W) Ground Rear RH door switch Input Rear RH door switch OFF (When rear RH door closes) 11.8 V ON (When rear RH door opens) 0 V 69 (R) Ground Rear LH door switch Input Rear LH door switch OFF (When rear LH door closes) 11.8 V ON (When rear LH door opens) 0 V 72 (B) Ground Room antenna (-) (Center console) Output Ignition switch OFF When Intelligent Key is in the passenger compartment When Intelligent Key is not in the passenger compartment 73 (W) Ground Room antenna (+) (Center console) Output Ignition switch OFF When Intelligent Key is in the passenger compartment When Intelligent Key is not in the passenger compartment 74 (Y) Ground Passenger door antenna (-) Output When the passenger door request switch is operated with ignition switch OFF When Intelligent Key is in the antenna detection area When Intelligent Key is not in the antenna detection area 75 (LG) Ground Passenger door antenna (+) Output When the passenger door request switch is operated with ignition switch OFF When Intelligent Key is in the antenna detection area When Intelligent Key is not in the antenna detection area 76 (V) Ground Driver door antenna (-) Output When the driver door request switch is operated with ignition switch OFF When Intelligent Key is in the antenna detection area When Intelligent Key is not in the antenna detection area 77 (P) Ground Driver door antenna (+) Output When the driver door request switch is operated with ignition switch OFF When Intelligent Key is in the antenna detection area When Intelligent Key is not in the antenna detection area 80 (SB) Ground NATS antenna amp. Input/Output During waiting Ignition switch is pressed while inserting Intelligent Key into the key slot. Just after pressing ignition switch. Pointer of tester should move. 81 (O) Ground NATS antenna amp. Input/Output During waiting Ignition switch is pressed while inserting Intelligent Key into the key slot. Just after pressing ignition switch. Pointer of tester should move. 82 (BR) Ground Ignition relay [fuse block (J/B)] control Output Ignition switch OFF or ACC 0 V ON Battery voltage 83 (P) Ground Remote keyless entry receiver communication Input/Output During waiting When operating either button on Intelligent Key 87 (R) Ground Combination switch INPUT 5 Input Combination switch All switches OFF (Wiper intermittent dial 4) 1.4 V Front fog lamp switch ON (Wiper intermittent dial 4) 1.3 V Rear wiper switch ON (Wiper intermittent dial 4) 1.3 V Any of the conditions below with all switches OFF Wiper intermittent dial 1 Wiper intermittent dial 2 Wiper intermittent dial 6 Wiper intermittent dial 7 1.3 V 88 (GR) Ground Combination switch INPUT 3 Input Combination switch All switches OFF (Wiper intermittent dial 4) 1.4 V Lighting switch HI (Wiper intermittent dial 4) 1.3 V Lighting switch 2ND (Wiper intermittent dial 4) 1.3 V Rear washer switch ON (Wiper intermittent dial 4) 1.3 V Any of the conditions below with all switches OFF Wiper intermittent dial 1 Wiper intermittent dial 2 Wiper intermittent dial 3 1.3 V 90 (P) Ground CAN - L Input/Output - - 91 (L) Ground CAN - H Input/Output - - 92 (R) Ground Key slot illumination Output Key slot illumination OFF 0 V Blinking 6.5 V ON Battery voltage 93 (P) Ground ON indicator lamp Output Ignition switch OFF (LOCK and ACC indicator lamps are not illuminated.) Battery voltage ON 0 V 95 (L) Ground ACC relay control Output Ignition switch OFF 0 V ACC or ON Battery voltage 96 (Y) Ground CVT shift selector (detention switch) power supply Output - Battery voltage 99 (V) Ground Selector lever P position switch Input Selector lever P position 0 V Any position other than P Battery voltage 100 (P) Ground Passenger door request switch Input Passenger door request switch ON (Pressed) 0 V OFF (Not pressed) 1.0 V 101 (W) Ground Driver door request switch Input Driver door request switch ON (Pressed) 0 V OFF (Not pressed) 1.0 V 102 (Y) Ground Blower fan motor relay control Output Ignition switch OFF or ACC 0 V ON Battery voltage 103 (L) Ground Remote keyless entry receiver power supply Output Ignition switch OFF Battery voltage 107 (O) Ground Combination switch INPUT 1 Input Combination switch (Wiper intermittent dial 4) All switches OFF 1.4 V Turn signal switch LH 1.3 V Turn signal switch RH 1.3 V Front wiper switch LO 1.3 V Front washer switch ON 1.3 V 108 (P) Ground Combination switch INPUT 4 Input Combination switch All switches OFF (Wiper intermittent dial 4) 1.4 V Lighting switch AUTO (Wiper intermittent dial 4) 1.3 V Lighting switch 1ST (Wiper intermittent dial 4) 1.3 V Rear wiper switch INT (Wiper intermittent dial 4) 1.3 V Any of the conditions below with all switches OFF Wiper intermittent dial 1 Wiper intermittent dial 5 Wiper intermittent dial 6 1.3 V 109 (SB) Ground Combination switch INPUT 2 Input Combination switch (Wiper intermittent dial 4) All switches OFF 1.4 V Lighting switch PASS 1.3 V Lighting switch 2ND 1.3 V Front wiper switch INT/AUTO 1.3 V Front wiper switch HI 1.3 V 110 (G) Ground Hazard switch Input Hazard switch ON 0 V OFF 1.1 V 112 (R) Ground Rain sensor serial link Input/Output Ignition switch ON 8.7 V 113 (O) Ground Optical sensor Input Ignition switch ON When bright outside of the vehicle Close to 5 V When dark outside of the vehicle Close to 0 V 116 (GR) Ground Stop lamp switch 1 Input - Battery voltage 118 (L) Ground Stop lamp switch 2 Input Stop lamp switch OFF (Brake pedal is not depressed) 0 V ON (Brake pedal is depressed) Battery voltage 119 (W) Ground Front door lock assembly driver side (Unlock sensor) Input Driver door LOCK status (unlock sensor switch OFF) 1.1 V UNLOCK status (unlock sensor switch ON) 0 V 121 (Y) Ground Key slot switch Input When Intelligent Key is inserted into key slot Battery voltage When Intelligent Key is not inserted into key slot 0 V 123 (G) Ground IGN feedback Input Ignition switch OFF or ACC 0 V ON Battery voltage 124 (R) Ground Passenger door switch Input Passenger door switch OFF (When passenger door closes) 11.8 V ON (When passenger door opens) 0 V 130 (BR) Ground Rear window defogger switch Input Ignition switch ON Rear window defogger switch OFF 1.1 V Rear window defogger switch ON 0 V 132 (G) Ground Power window switch communication Input/Output Ignition switch ON 10.2 V Ignition switch OFF or ACC Battery voltage 133 (W) Ground Push-button ignition switch illumination Output Push-button ignition switch illumination ON (When tail lamps OFF) 9.5 V ON (When tail lamps ON) NOTE: The pulse width of this wave is varied by the illumination brightening/dimming level. OFF 0 V 134 (R) Ground LOCK indicator lamp Output LOCK indicator lamp OFF (ACC and ON indicator lamps are not illuminated.) Battery voltage ON 0 V 137 (P) Ground Receiver and sensor ground Input Ignition switch ON 0 V 138 (V) Ground Receiver and sensor power supply Output Ignition switch OFF 0 V ACC or ON 5.0 V 139 (O) Ground Tire pressure receiver communication Input/Output Ignition switch ON Standby state When receiving the signal from the transmitter 140 (GR) Ground Selector lever P/N position Input Selector lever P or N position Battery voltage Except P and N positions 0 V 141 (O) Ground Security indicator Output Security indicator ON 0 V Blinking 11.3 V OFF Battery voltage 142 (L) Ground Combination switch OUTPUT 5 Output Combination switch (Wiper intermittent dial 4) All switches OFF 0 V Lighting switch 1ST 10.7 V Lighting switch HI Lighting switch 2ND Turn signal switch RH 143 (W) Ground Combination switch OUTPUT 1 Output Combination switch All switches OFF (Wiper intermittent dial 4) 0 V Front wiper switch HI (Wiper intermittent dial 4) 10.7 V Rear wiper switch INT (Wiper intermittent dial 4) Any of the conditions below with all switches OFF Wiper intermittent dial 1 Wiper intermittent dial 2 Wiper intermittent dial 3 Wiper intermittent dial 6 Wiper intermittent dial 7 144 (P) Ground Combination switch OUTPUT 2 Output Combination switch All switches OFF (Wiper intermittent dial 4) 0 V Front washer switch ON (Wiper intermittent dial 4) 10.7 V Rear wiper switch ON (Wiper intermittent dial 4) Rear washer switch ON (Wiper intermittent dial 4) Any of the conditions below with all switches OFF Wiper intermittent dial 1 Wiper intermittent dial 5 Wiper intermittent dial 6 145 (V) Ground Combination switch OUTPUT 3 Output Combination switch (Wiper intermittent dial 4) All switches OFF 0 V Front wiper switch INT/AUTO 10.7 V Front wiper switch LO Lighting switch AUTO 146 (Y) Ground Combination switch OUTPUT 4 Output Combination switch (Wiper intermittent dial 4) All switches OFF 0 V Front fog lamp switch ON 10.7 V Lighting switch 2ND Lighting switch PASS Turn signal switch LH 150 (SB) Ground Driver door switch Input Driver door switch OFF (When driver door closes) 11.8 V ON (When driver door opens) 0 V 151 (G) Ground Rear window defogger relay control Output Rear window defogger Active 0 V Not activated Battery voltage
