AUTOMATIC DRIVE POSITIONER SYSTEM LINKED OPERATION
Door mirror control is included in automatic drive positioner system. Refer to automatic drive positioner system for more details.
Refer to " AUTOMATIC DRIVE POSITIONER SYSTEM : SYSTEM DESCRIPTION ".
Scheme 1
Component Description
| Component | Function | |
|---|---|---|
| Automatic drive positioner control unit | Door mirror is supplied with power after receiving the input of the MIRROR SWITCH and CHANGEOVER SWITCH. | |
| Door mirror remote control switch | Mirror switch | It transmits mirror face adjust operation to AUTOMATIC DRIVE POSITIONER CONTROL UNIT. |
| Changeover switch | It transmits the LH/RH control of door mirror that supplies power to AUTOMATIC DRIVE POSITIONER CONTROL UNIT. | |
| Door mirror | It makes mirror face operate from side to side and up and down via integrated motor. | |
| BCM | The ignition switch signal (ACC/ON) is transmitted to driver seat control unit via CAN communication. | |
| Driver seat control unit | The ignition switch signal (ACC/ON) is transmitted to automatic drive positioner control unit via UART communication. | |
DOOR MIRROR SYSTEM COMPONENTS FUNCTION CHART
System Description
The sensor built in inside mirror detects the headlight of the vehicle behind and automatically changes the light transmission to decrease the brightness.
| Component | Function |
|---|---|
| Auto anti-dazzling inside mirror | It automatically changes the light transmittance according to the brightness of the light from the headlight of the vehicle behind. |
COMPONENTS FUNCTION CHART
Diagnosis Description
The auto drive positioner system can be checked and diagnosed for component operation with CONSULT-III.
MIRROR SWITCH : Description
It operates angle of the door mirror face.
It transmits mirror face adjust operation to AUTOMATIC DRIVE POSITIONER CONTROL UNIT.
CHANGEOVER SWITCH : Description
Changeover switch is integrated into door mirror remote control switch.
Changeover switch has three positions (L, N and R).
It changes door mirror motor operation by transmitting control signal to automatic drive positioner control unit.
| Component | Function |
|---|---|
| Door mirror remote control switch | It supplies power to mirror motor through mirror switch and changeover switch. |
| Door mirror | It makes mirror face operate from side to side and up and down with the mirror control switch operation. |
DOOR MIRROR SYSTEM COMPONENTS FUNCTION CHART
The sensor built in inside mirror detects the headlight of the vehicle behind and automatically changes the light transmission to decrease the brightness.
| Component | Function |
|---|---|
| Auto anti-dazzling inside mirror | It automatically changes the light transmittance according to the brightness of the light from the headlight of the vehicle behind. |
COMPONENTS FUNCTION CHART
