MULTIPLE SWITCH
The continuity of multiple switch is described in two ways as shown below.
Scheme 96
- The switch chart is used in schematic diagrams.
- The switch diagram is used in wiring diagrams.
Scheme 97
Description
| Number | Item | Description |
|---|---|---|
| 1 | Connector number | Alphabetic characters show to which harness the connector is placed. Numeric characters show the identification number of connectors. |
| 2 | Connector type | This means the connector number. Refer to , " HOW TO READ HARNESS LAYOUT ". |
| 3 | Terminal number | This means the terminal number of a connector. |
| 4 | Wire color | This shows a code for the color of the wire. |
| B = Black W = White R = Red G = Green L = Blue Y = Yellow LG = Light Green BG = Beige BR = Brown OR or O = Orange P = Pink PU or V (Violet) = Purple GY or GR = Gray SB = Sky Blue CH = Dark Brown DG = Dark Green | ||
| When the wire color is striped, the base color is given first, followed by the stripe color as shown below: Example: L/W = Blue with White Stripe | ||
| 5 | Connector | This means the connector information. This unit-side is described by the connector symbols. |
CONNECTOR INFORMATION DESCRIPTION
