CHECK OF CAN SYSTEM TYPE (HOW TO USE CAN SYSTEM TYPE SPECIFICATION CHART)
Determine CAN system type based on vehicle equipment.
Note. This chart is used if CONSULT-III does not automatically recognize CAN system type. There are two styles for CAN system type specification charts. Depending on the number of available system types, either style A or style B may be used.
CAN System Type Specification Chart (Style A)
Note. CAN system type is easily checked with the vehicle equipment identification information shown in the chart.
Scheme 1
CAN System Type Specification Chart (Style B)
Note. CAN system type is easily checked with the vehicle equipment identification information shown in the chart.
Scheme 2
CAN System Specification Chart
Determine CAN system type from the following specification chart.
Note. Refer to " TROUBLE DIAGNOSIS PROCEDURE " for how to use CAN system specification chart.
| Body type | Wagon | |||||
|---|---|---|---|---|---|---|
| Axle | 2WD | AWD | ||||
| Engine | VQ35DE | |||||
| Transmission | CVT | |||||
| Brake control | VDC | |||||
| Automatic drive positioner | X | X | ||||
| Automatic back door system | X | X | ||||
| Color display | X | X | X | X | ||
| CAN system type | 1 | 2 | 3 | 4 | 5 | 6 |
| X: Applicable | ||||||
CAN SYSTEM SPECIFICATION CHART
