Automatic HVAC System 1 illustration ~117 words

Scheme 163

Scheme 163: System Description
Switch positionDoor position
Ventilator doorMax. cool doorDefroster doorFoot doorUpper ventilator doorIntake doorAir mix door (Driver side)Air mix door (Passenger side)
AUTO switchINDICATOR LIGHT ONAUTOAUTO
MODE switchVENTFACEAAAA
B/LBI-LEVELBBAB
FOOTFOOTCBBC
D/FFLOOR/DEFROSTCBBBB
DEF switchDEFROSTINDICATOR LIGHT ONCCCAB
UPPER VENT switchONUPPER VENTINDICATOR LIGHT ONA-B
OFFINDICATOR LIGHT OFFC
Intake switchONRECIRC.INDICATOR LIGHT ONA (1)
OFFINDICATOR LIGHT OFFB (1)
Temperature control switch (Driver side)DUAL switch: OFF18.0°C (60°F)A
18.5°C <==> 31.5°C (61°F <==> 89°F)AUTO
32.0°C (90°F)B
Temperature control switch (Driver side)DUAL switch: ON18.0°C (60°F)A
18.5°C <==> 31.5°C (61°F <==> 89°F)AUTO
32.0°C (90°F)B
Temperature control switch (Passenger side)18.0°C (60°F)A
18.5°C <==> 31.5°C (61°F <==> 89°F)AUTO
32.0°C (90°F)B
ON/OFF switchCCBCB
(1) Inlet status is displayed by indicator when activating automatic control.
(1)Inlet status is displayed by indicator when activating automatic control.

SWITCH POSITION REFERENCE CHART

System Description

Discharge air flow
Mode position indicationConditionAir outlet/distribution
VENTFOOTDEF
FrontUpperRearFrontRear
FACEDUAL switch: OFF UPPER VENT switch : ON81%8%11%
BI-LEVEL41%10%17%24%8%
FOOT12%12%16%27%10%23%
FLOOR/DEFROST11%11%14%25%10%29%
DEFROST11%11%12%66%

AIR DISTRIBUTION REFERENCE CHART

Discharge air flow
Mode position indicationConditionAir outlet/distribution
VENTFOOTDEF
FrontUpperRearFrontRear
FACEDUAL switch: OFF UPPER VENT switch : OFF88%12%
BI-LEVEL47%18%26%9%
FOOT13%17%33%12%25%
FLOOR/DEFROST12%16%28%12%32%
DEFROST11%15%74%

AIR DISTRIBUTION REFERENCE CHART

IDENTIFICATION

Note. Vehicles with factory installed fluorescent dye have a green label. Vehicles without factory installed fluorescent dye have a blue label.

IDENTIFICATION LABEL FOR VEHICLE

Vehicles with factory installed fluorescent dye have an identification label on the front side of hood.

Switch positionDoor position
Ventilator doorMax. cool doorDefroster doorFoot doorUpper ventilator doorIntake doorAir mix door (Driver side)Air mix door (Passenger side)
AUTO switchINDICATOR LIGHT ONAUTOAUTO
MODE switchVENTFACEAAAA
B/LBI-LEVELBBAB
FOOTFOOTCBBC
D/FFLOOR/DEFROSTCBBBB
DEF switchDEFROSTINDICATOR LIGHT ONCCCAB
UPPER VENT switchONUPPER LEVELINDICATOR LIGHT ONA-B
OFFINDICATOR LIGHT OFFC
Intake switchONRECIRC.INDICATOR LIGHT ONA (1)
OFFINDICATOR LIGHT OFFB (1)
Temperature control dial (Driver side)DUAL switch: OFF18.0°C (60°F)A
18.5°C <==> 31.5°C (61°F <==> 89°F)AUTO
32.0°C (90°F)B
Temperature control dial (Driver side)DUAL switch: ON18.0°C (60°F)A
18.5°C <==> 31.5°C (61°F <==> 89°F)AUTO
32.0°C (90°F)B
Temperature control dial (Passenger side)18.0°C (60°F)A
18.5°C <==> 31.5°C (61°F <==> 89°F)AUTO
32.0°C (90°F)B
ON/OFF switchCCBCB
(1) Inlet status is displayed by indicator when activating automatic control.
(1)Inlet status is displayed by indicator when activating automatic control.

SWITCH POSITION DESCRIPTION CHART

Discharge air flow
Mode position indicationConditionAir outlet/distribution
VENTFOOTDEF
FrontUpperRearFrontRear
FACEDUAL switch: OFF UPPER VENT switch : ON81%8%11%
BI-LEVEL41%10%17%24%8%
FOOT12%12%16%27%10%23%
FLOOR/DEFROST11%11%14%25%10%29%
DEFROST11%11%12%66%

AIR DISTRIBUTION REFERENCE CHART

Discharge air flow
Mode position indicationConditionAir outlet/distribution
VENTFOOTDEF
FrontUpperRearFrontRear
FACEDUAL switch: OFF UPPER VENT switch : OFF88%12%
BI-LEVEL47%18%26%9%
FOOT13%17%33%12%25%
FLOOR/DEFROST12%16%28%12%32%
DEFROST11%15%74%

AIR DISTRIBUTION REFERENCE CHART

Note. Vehicles with factory installed fluorescent dye have a green label. Vehicles without factory installed fluorescent dye have a blue label.

Vehicles with factory installed fluorescent dye have an identification label on the front side of hood.
