Engine Mechanical (Except Crosscabriolet): Adjustments Nissan Murano Z51 рестайлинг 2

Tension Adjustment

Refer to " DRIVE BELT ".

Scheme 10

1. Remove front wheel and tire (RH).
2. Remove splash guard (RH). Refer to " «FENDER PROTECTOR: EXPLODED VIEW»(ref-593941-S20400464212014012200000) ".
3. Hold the hexagonal part in center of drive belt auto-tensioner pulley with a box wrench securely. Then move the wrench handle in the direction of arrow (loosening direction of drive belt). CAUTION: Avoid placing hand in a location where pinching may occur if the holding tool accidentally comes off. Never loosen the hexagonal part in center of drive belt auto-tensioner pulley (Never turn it counterclockwise). If turned counterclockwise, the complete drive belt auto-tensioner must be replaced as a unit, including the pulley.
4. Insert a rod approximately 6 mm (0.24 in) in diameter such as short-length screwdriver into the hole (A) of the retaining boss to fix drive belt auto-tensioner pulley.
5. Loosen drive belt from water pump pulley in sequence, and remove it.

Scheme 11

1. Hold the hexagonal part in center of drive belt auto-tensioner pulley with a box wrench securely. Then move the wrench handle in the direction of arrow (loosening direction of drive belt). CAUTION: Avoid placing hand in a location where pinching may occur if the holding tool accidentally comes off. Never loosen the hexagonal part in center of drive belt auto-tensioner pulley (Never turn it counterclockwise). If turned counterclockwise, the complete drive belt auto-tensioner must be replaced as a unit, including the pulley.
2. Insert a rod approximately 6 mm (0.24 in) in diameter such as short-length screwdriver into the hole (A) of retaining boss to fix drive belt auto-tensioner pulley.
3. Hook drive belt onto all pulleys except for drive belt auto-tensioner pulley, and then onto drive belt auto-tensioner pulley finally. CAUTION: Confirm drive belt is completely set to pulleys. Check for engine oil, working fluid and engine coolant are not adhered to drive belt and each pulley groove.
4. Release drive belt auto-tensioner, and apply tension to drive belt.
5. Turn crankshaft pulley clockwise several times to equalize tension between each pulley.
6. Confirm tension of drive belt at indicator is within the possible use range. Refer to " «EXPLODED VIEW»(ref-593939-S31762119422014012200000) ".
