1. Refer to ATC Automatic Air Conditioner «SELF-DIAGNOSIS FUNCTION»(ref-234022-S02315709702006052800000) for details.

Scheme 371

1. The initial trouble diagnosis screen will be shown, and items "Display Diagnosis", "Vehicle Signals", "History of Errors" and "Navigation" will become selective.
2. Select each switch on "CONFIRMATION/ADJUSTMENT" screen to display the relevant diagnosis screen.

Scheme 372

1. When RGB signal error occurred in the RGB system, tone of the color bar will change as follows. R (red) signal error: Screen looks bluish G (green) signal error: Screen looks reddish B (blue) signal error: Screen looks yellowish
2. When the color of the screen looks unusual, Refer to «COLOR OF RGB IMAGE IS NOT PROPER (ONLY NAVI SCREEN)»(ref-234029-S10884481832006052800000) .

Scheme 373

Scheme 374

1. A comparison check can be made of each actual vehicle signal and the signals recognized by the system. CAUTION: In case of confirming light signal, set D/N mode to ON/OFF of light switch (normal setting). OFF: D (Day mode) ON: N (Night mode) Unless above setting, light signal (ON/OFF) may not be accurately displayed.
2. If vehicle speed is NG, Refer to «VEHICLE SPEED SIGNAL CHECK FOR NAVI CONTROL UNIT»(ref-234029-S09973708502006052800000) .
3. If light is NG, Refer to «ILLUMINATION SIGNAL CHECK FOR NAVI CONTROL UNIT»(ref-234029-S03974011852006052800000) .
4. If IGN is NG, Refer to «IGNITION SIGNAL CHECK FOR NAVI CONTROL UNIT»(ref-234029-S24970234602006052800000) .
5. If reverse is NG, Refer to «REVERSE SIGNAL CHECK FOR NAVI CONTROL UNIT»(ref-234029-S10414433362006052800000) .

Scheme 375
